High Reliability Slotted Optical Switch
OPB870, OPB871, OPB872 (TX, TXV)
L
Features:
•
•
•
•
•
•
0.125” (3.175 mm) slot width
Choice of aperture (0.050” or 0.010” width)
PCBoard mounting
TX and TXV devices processed to MIL-PRF-19500
S level processing available
Hermetically sealed components
T
N
Product Photo Here
P
Description:
Each
OPB870, OPB871
and
OPB872 (TX, TXV)
phototransistor device provides the flexibility of a custom device
from a standard product line. Building from a standard housing with a 0.125” (3.175 mm) wide slot and
0.425” ( mm) leads for PCBoard mounting, a user can choose aperture width, opaque or IR transmissive housing
shell material and mounting tab configuration.
Housings are made from an opaque grade of injection-molded plastic to minimize sensitivity to both visible and
near-infrared light. Discrete shells exposed on the parallel faces inside each device’s throat are made from either
IR transmissive plastic (for applications where dust protection is needed) or from opaque plastic with aperture
openings (for applications that require maximum protection against ambient light).
TX and TXV devices are processed to OPTEK’s military screening program patterned after MIL-PRF-19500.
Please refer to Application Bulletins 208 and 210 for additional design information and reliability (degradation) data.
Contact your local representative or OPTEK for more information.
Applications:
•
•
•
•
•
•
Non-contact object sensing
Assembly line automation
Machine automation
Equipment safety
Machine safety
Military and harsh environments
RoHS
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue B 10/2011
Page 1 of 6
High Reliability Slotted Optical Switch
OPB870, OPB871, OPB872 (TX, TXV)
Part Number Guide — OPB870, OPB871, OPB872 (TX, TXV)
OPB 8 X X X X X T X V
TX and TXV processed to MIL-PRF-19500
Optek Assembly
Phototransistor Output Family
Sensor Aperture:
1 —
0.010” (0.254 mm)
5 —
0.050” (1.270 mm)
Emitter Aperture:
1 —
0.010” (0.254 mm)
5 —
0.050” (1.270 mm)
Mounting Configurations:
N —
No mounting tabs
L —
Emitter side mounting tab only
T —
Two mounting tabs
P —
Phototransistor side mounting tab only
Discrete Shell Material:
7 —
Base mount opaque
Plastic discrete shell
PC mountable leads
Electrical Specification Variations:
0
= Electrical Parameter A (lead spacing = 0.320”)
1
= Electrical Parameter B (lead spacing = 0.320”)
2
= Electrical Parameter C (lead spacing = 0.320”)
Note:
Assemblies with dual 0.010” apertures are
currently available only with electrical
E / Clear Top
Denotes LED
S / Black Top
Denotes Sensor
1
3
2
4
Pin # Emitter Pin # Transistor/Diode
1
2
Anode
Cathode
3
4
Collector / Anode
Emitter / Cathode
DIMENSIONS ARE IN:
[MILLIMETERS]
INCHES
CONTAINS POLYSULFONE
To avoid stress cracking, we suggest using ND Industries’
Vibra-Tite
for thread-locking.
Vibra-Tite
evaporates fast without causing structural failure in OPTEK’s molded plastics.
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Issue B 10/2011
Page 2 of 6
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
High Reliability Slotted Optical Switch
OPB870, OPB871, OPB872 (TX, TXV)
Absolute Maximum Ratings
(T
A
= 25° C unless otherwise noted)
Storage Temperature
(1)
Operating Temperature
(1)
Lead Soldering Temperature
(3)
-65° C to +150° C
-65° C to +125° C
240° C
Input LED
Forward DC Current
Peak Forward Current (1µs pulse width, 300 pps)
Reverse DC Voltage
Power Dissipation
(2)
50 mA
1.0 A
2.0 V
100 mW
Output Phototransistor/Diode
Collector-Emitter Voltage
Emitter-Collector Voltage
Collector DC Current
Power Dissipation
Notes:
(1)
(2)
(3)
(4)
Derate linearly 1.00 mW/° C above 25° C.
Cleaning agents methanol and isopropanol are recommended. Spray or wipe; do not submerge.
RMA flux is recommended. Duration can be extended to 10 seconds maximum when flow soldering.
All parameters were tested using pulse technique.
50 V
7.0 V
30 mA
100 mW
(2)
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue B 10/2011
Page 3 of 6
High Reliability Slotted Optical Switch
OPB870, OPB871, OPB872 (TX, TXV)
Electrical Characteristics
(T
A
= 25°C unless otherwise noted)
SYMBOL
Input Transistor/Diode
V
F
I
R
Forward Voltage
Reverse Current
1.00
1.20
0.80
-
-
-
-
-
1.70
1.90
1.60
10
V
µA
I
F
= 20.0 mA
I
F
= 20.0 mA, T
A
= -55ºC
I
F
= 20.0 mA, T
A
= -100ºC
V
R
= 2.0 VDC
PARAMETER
MIN
TYP
MAX UNITS
TEST CONDITIONS
Output Transistor
V
(BR)CEO
V
(BR)ECO
I
C(off)
Coupled
I
C(ON)
On-State Collector Current
(4)
Parameter A
OPB870
OPB870
OPB870
Parameter B
OPB871
OPB871
OPB871
Parameter C
OPB872
OPB872
OPB872
Collector-Emitter Saturation Voltage
OPB870
OPB871
OPB872
Output Rise Time
OPB870
OPB871
OPB872
Output Fall Time
OPB870
OPB871
OPB872
500
200
200
-
-
-
-
-
-
V
CE
= 10.0 V, I
F
= 20.0 mA
V
CE
= 10.0 V, I
F
= 20.0 mA, T
A
= -55ºC
V
CE
= 10.0 V, I
F
= 20.0 mA, T
A
= 100ºC
Collector-Emitter Breakdown Voltage
Emitter-Collector Breakdown Voltage
Collector-Emitter Dark Current
50
7.0
-
-
-
-
-
-
100
100
V
V
nA
µA
I
C
= 1.0 mA, I
F
= 0
I
E
= 100 µA, I
F
= 0
V
CE
= 10.0 V, I
F
= 0
V
CE
= 10.0 V, I
F
= 0, T
A
= 100ºC
µA
1000
400
400
-
-
-
-
-
-
µA
V
CE
= 5.0 V, I
F
= 10.0 mA
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= -55ºC
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= 100ºC
V
CE
= 0.4 V, I
F
= 20.0 mA
V
CE
= 0.4 V, I
F
= 20.0 mA, T
A
= -55ºC
V
CE
= 0.4 V, I
F
= 20.0 mA, T
A
= 100ºC
I
C
= 400 µA, I
F
= 20.0 mA
I
C
= 800 µA, I
F
= 10.0 mA
I
C
= 1800 µA, I
F
= 20.0 mA
1800
800
800
-
-
-
-
-
-
-
-
-
-
-
-
0.30
0.30
0.30
µA
V
CE(SAT)
V
t
r
-
-
-
-
-
-
15.0
20.0
20.0
µs
V
CC
= 10.0 V
I
F
= 20.0 mA
R
L
= 1000Ω
t
f
-
-
-
-
-
-
15.0
20.0
20.0
µs
V
CC
= 10.0 V
I
F
= 20.0 mA
R
L
= 1000Ω
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Issue B 10/2011
Page 4 of 6
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
High Reliability Slotted Optical Switch
OPB870, OPB871, OPB872 (TX, TXV)
Aperture Configuration 51 -
Middle of
to Emitter
OPB370N51 - Flag in
Flag Next
Slot
1.20
Top to Bottom
1.00
1.00
1.20
Aperture Configuration 51
Next to Sensor
OPB370N51 - Flag
- Flag Next to Sensor
Top to Bottom
Typical I
C(ON)
Response (mA)
0.80
Left to Right
0.60
Right to Left
Typical I
C(ON)
Response (mA)
0.80
Left to Right
Right to Left
0.60
0.40
0.40
0.20
0.20
0.00
0.00
0.05
0.10
0.15
0.20
0.25
0.00
0.00
0.05
0.10
0.15
0.20
0.25
Displacement Distance (inches)
Displacement Distance (inches)
Aperture Configuration 51
in
Flag in Middle of Slot
OPB370N51 - Flag
-
Middle of Slot
1.20
Top to Bottom
1.00
0
Top to Bottom
Typical I
C(ON)
Response (mA)
0.80
Left to Right
0.60
Right to Left
Emitter
Left to Right
Right to Left
0.40
Sensor
0
Width
0.20
0.00
0.00
0.05
0.10
0.15
0.20
0.25
Displacement Distance (inches)
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue B 10/2011
Page 5 of 6
