HS1-0547RH-Q: Description8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28, CERDIP-28; CategoryAnalog mixed-signal IC The signal circuit; File Size281KB，6 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

HS1-0547RH-Q Overview

8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28, CERDIP-28

HS1-0547RH-Q Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	DIP, DIP28,.6
Contacts	28
Reach Compliance Code	not_compliant
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-GDIP-T28
JESD-609 code	e0
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	8
Number of functions	1
Number of terminals	28
Nominal off-state isolation	50 dB
On-state resistance matching specifications	126 Ω
Maximum on-state resistance (Ron)	1800 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Encapsulate equivalent code	DIP28,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
power supply	+-15 V
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Maximum seat height	5.92 mm
Maximum signal current	0.008 A
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	1000 ns
Maximum connection time	1000 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
total dose	10k Rad(Si) V
width	15.24 mm

Preview

Download Datasheet

View All

HS-0546RH, HS-0547RH

Data Sheet

August 2001

File Number

3544.3

Radiation Hardened Single 16/Differential

8 Channel CMOS Analog Multiplexers with

Active Overvoltage Protection

tle

S-

ia-

if-

ti-

The HS-0546RH and HS-0547RH are radiation hardened

analog multiplexers with Active Overvoltage Protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active protection

circuitry assures that signal fidelity is maintained even under

fault conditions that would destroy other multiplexers. Analog

inputs can withstand constant 70V peak-to-peak levels with

±15V

supplies and digital inputs will sustain continuous faults

up to 4V greater than either supply. In addition, signal sources

are protected from short circuiting should multiplexer supply

loss occur: each input presents 1kΩ of resistance under this

condition. These features make the HS-0546RH and

HS-0547RH ideal for use in systems where the analog inputs

originate from external equipment or separately powered

circuitry. Both devices are fabricated with 44V dielectrically

isolated CMOS technology. The HS-0546 is a 16 channel

device and the HS-0547 is an 8 channel differential version. If

input overvoltage protection is not needed, the HS-0506 and

HS-0507 multiplexers are recommended.

Specifications for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed here must be used when ordering.

Detailed Electrical Specifications for these devices are

contained in SMD 5962-95693. A “hot-link” is provided

on our homepage for downloading.

http://www.intersil.com

Features

• Electrically Screened to SMD # 5962-95693

• QML Qualified per MIL-PRF-38535 Requirements

• Gamma Dose . . . . . . . . . . . . . . . . . . . . . . 1 x 10

RAD(Si)

• No Latch-Up

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply . . . . . . . . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switch

• Analog Signal Range.

. . . . . . . . . . . . . . . . . . . . . . . . . . . ±15V

• Access Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0µs

Applications

• Data Acquisition Systems

• Control Systems

• Telemetry

Ordering Information

ORDERING NUMBER

5962D9569301V9A

5962D9569301VXA

5962D9569301VXC

5962D9569302V9A

5962D9569302VXA

5962D9569302VXC

INTERNAL

MKT. NUMBER

HS0-0546RH-Q

HS1-0546RH-Q

HS1B-0546RH-Q

HS0-0547RH-Q

HS1-0547RH-Q

HS1B-0547RH-Q

TEMP. RANGE

(

-55 to 125

ec-

)

tho

Pinouts

HS-0546RH GDIP1-T28 (CERDIP) OR CDIP2-T28 (SBDIP)

TOP VIEW

SUPPLY

NC 2

NC 3

IN 16 4

IN 15 5

IN 14 6

IN 13 7

IN 12 8

IN 11

28 OUT

27 -V

SUPPLY

26 IN 8

25 IN 7

24 IN 6

23 IN 5

22 IN 4

21 IN 3

20 IN 2

19 IN 1

18 ENABLE

17 ADDRESS A0

16 ADDRESS A1

15 ADDRESS A0

HS-0547RH GDIP1-T28 (CERDIP) OR CDIP2-T28 (SBDIP)

TOP VIEW

SUPPLY

OUT B

28 OUT A

27 -V

SUPPLY

26 IN 8A

25 IN 7A

24 IN 6A

23 IN 5A

22 IN 4A

21 IN 3A

20 IN 2A

19 IN 1A

18 ENABLE

17 ADDRESS A0

16 ADDRESS A1

15 ADDRESS A2

NC 3

IN 8B 4

IN 7B 5

IN 6B 6

IN 5B 7

IN 4B 8

IN 3B 9

IN 2B 10

IN 1B 11

GND 12

REF

NC 14

IN 10 10

IN 9 11

GND 12

REF

ADDRESS A3 14

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

Intersil and Design is a trademark of Intersil Americas Inc.
