REVISION BG
DO NOT
SCALE FROM
THIS PRINT
QTH-XXX-XX-X-D-XXX
No OF POSITIONS
-030, -060, -090,
*-120, *-150 (PER ROW)
* (SEE NOTE 11)
LEAD STYLE
-01: .1680[4.267]
-02: .2861[7.264]
-03: .4043[10.269]
-04: .6001[15.246]
-05: .7181[18.240]
-06: .8361[21.237]
-07: .9542[24.237]
-08: 1.1511[29.238]
-09: .5224[13.269]
-10: .5618[14.269]
= SEE TABLE 6, SHT 3
PLATING SPECIFICATION
-F: 3 µ'' SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
(USE T-1SXX-XX-F & T-1GXX-XX-F) (SEE NOTE 7)
-L: 10 µ'' SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
(USE T-1SXX-XX-L & T-1GXX-XX-L)
-H: 30 µ'' GOLD IN CONTACT AREA,
3 µ'' GOLD ON TAIL
(USE T-1SXX-XX-H & T-1GXX-XX-G)
-C: 50 µ'' SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
(USE T-1SXX-XX-C, T-1GXX-XX-L)
OPTION
-LC: LOCKING CLIPS
(USE LC-08-TM-01, SEE FIG 2, SHT 2))
-A: ALIGNMENT PINS
(USE QTH-30-XX-D-XX-A FOR -01 & -02)
(FOR -03 THRU -10 SEE TABLE 6, SHT 3)
-K: POLYIMIDE FILM (USE K-DOT-.276-.375-.005)
(AVAILABLE ON -01 THRU -04, -09 & -10 ONLY)
(SEE FIG 4, SHT 2)
-TR: TAPE & REEL (-090 POS MAX)
(-060 POS MAX W/ -GP OPTION)
(N/A ON -05 THRU -08)
(SEE FIG 12, SHT 6)
-GP: GUIDE POSTS
(AVAILABLE ON -01 & -02 ONLY)
(USE QTH-30-XX-D-XX-X-GP)
(SEE FIG 8, SHT 4)
-FL: FRICTION LOCKS (SEE FIG 8, SHT 4)
(NOT AVAILABLE WITH -GP)
-RT1: RETENTION OPTION (SEE FIG 10, SHT 5)
(ONLY AVAILABLE ON -01 LEAD STYLE)
(MUST USE -A OPTION)
(USE QTH-30-01-D-XX-A-RT1 & T-1R36-01-F)
(NOT AVAILABLE WITH -LC, -GP, OR -FL)
-L: LATCHING OPTION (SEE FIG 11, SHT 5)
(ONLY AVAILABLE ON -01 LEAD STYLE)
(USE QTH-30-01-D-XX-L)
(NOT AVAILABLE WITH -LC, -GP, -FL, OR -RT1)
(-060 POS MAX)
ROW SPECIFICATION
-D: DOUBLE (USE QTH-30-XX-D-XX
& QTHH-30-XX-D-XX)
C
"A"
.7875 20.003 (TYP)
29 EQ SPCS @
.0197[.500]
= .571 14.50
(TYP)
01
.235 5.97
REF
.155 3.9 REF
(SEE NOTE 12)
02
.644 16.4 REF
.047 1.19 REF
"A"
QTH-30-XX-D-XX-A
.008 0.2 REF
.155±.003 3.94±0.08
(SEE NOTE 12)
T-1SXX-XX-X
(SEE TABLE 1)
"B"
- .002
+.003 [.08]
C
[.03]
(SEE NOTE 5 & 8)
"C" REF
SEE TABLE 3
.038 0.95 REF
"A"
.745 18.9 REF
"D" REF
T-1G1-XX-X
(SEE NOTE 8)
.015 0.4 REF
.031 0.8 REF
.080 2.03 REF
.280 7.11
.098 2.49 REF
(SEE NOTE 10)
SECTION "A"-"A"
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 6 OZ FOR –01 & -02, 8 OZ FOR –03 THRU –10.
3. MINIMUM GROUND PLANE RETENTION: 1 LB.
4. PARTS TO BE MOLDED TO POSITION.
5. MAXIMUM VARIANCE OF .002 [0.05]. APPLIES TO SIGNAL OR GROUNDS
INDEPENDENT OF THE GROUND OR SIGNAL PINS RESPECTIVELY.
6. LEAD STYLES -03 THRU -10: TOP BODY (QTH) CANNOT HAVE -A OPTION.
7. -L PLATING CAN BE SUBSTITUTED FOR -F PLATING.
8. GROUND PLANE PRESS HEIGHT MUST BE .003 [0.07] LESS THAN THE MAXIMUM HEIGHT
OR .002 [0.05] GREATER THAN THE MINIMUM HEIGHT OF SIGNAL PIN.
9. T-1R36 RETENTION TO BODY TO BE 1.0 LBF.
10. CUT OFF BURR NOT TO EXCEED .003 [0.08] IN ANY DIRECTION, BURR PLUS TAB
HEIGHT NOT TO EXCEED .006 [0.15].
11. FOR NEW APPLICATIONS REQUIRING THESE POSITIONS, PLEASE CONTACT SAMTEC
INTERCONNECT PROCESSING GROUP.
12. PIN CAN EXTEND PAST WALL .003 [0.08] MAX.
.035 0.89 REF
-A: ALIGNMENT PIN OPTION
(STYLE -01 & -02 ONLY)
(QTH-090-01-X-D-A SHOWN)
PROPRIETARY NOTE
FIG 1
THIS SHEET
CPC
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.XX: .01[0.3]
2
.XXX: .005[0.13]
.XXXX: .0020[0.051]
DECIMALS
ANGLES
*
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
DO NOT SCALE DRAWING
C1, C2, C3,
MATERIAL:
C4, C5
INSULATOR: LCP UL94V-0, COLOR: BLACK
SHEET SCALE: 1.75:1
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
TERMINAL & GROUND PLANE: PHOS BRONZE
.5mm DOUBLE ROW HS TERMINAL ASSEMBLY
DWG. NO.
QTH-XXX-XX-X-D-XXX
09-14-2010
SHEET
1
OF
6
F:\DWG\MISC\MKTG\QTH-XXX-XX-X-D-XXX-MKT.SLDDRW
BY:
DEAN P
REVISION BG
QTH-30-XX-D-XX
C
L
.055 1.40
LC-08-TM-01
.010 0.25 REF
"D"
(SEE TABLE 2, SHT 1)
.056 1.42 REF
.0800 2.032
-LC LOCKING CLIP OPTION
(QTH-090-01-X-D-LC SHOWN)
(SAME AS FIG 1, EXCEPT AS SHOWN)
FIG 2
QTHH-30-XX-D-XX-A
QTH-30-02-D-XX (SEE NOTE 6)
C
L
-A: ALIGNMENT PIN OPTION
(QTH-090-05-X-D-A SHOWN)
(SAME AS FIG 1, EXCEPT AS SHOWN)
(STYLES -03 THRU -09, SEE TABLE 6, SHT 3)
.035 0.89 REF
"D" REF
(SEE TABLE 2, SHT 1)
FIG 3
.038 1.0
REF
.080 2.03 REF
"R" REF
"S"±.020 [0.51]
.020±.020 0.51±0.51
THIS SHEET
CPC
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
"T"
.276 7.01
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
-K: POLYIMIDE FILM PAD OPTION
(USE K-DOT-.276-.375-.005)
F:\DWG\MISC\MKTG\QTH-XXX-XX-X-D-XXX-MKT.SLDDRW
FIG 4
C4, C13,
C14
DO NOT SCALE DRAWING
.5mm DOUBLE ROW HS TERMINAL ASSEMBLY
DWG. NO.
SHEET SCALE: 1.75:1
QTH-XXX-XX-X-D-XXX
09-14-2010
SHEET
2
OF
6
BY:
DEAN P
REVISION BG
DETAIL 'H'
SCALE 8 : 1
.003 0.08 MAX
TAB HEIGHT
.006 0.15 MAX BURR
+ TAB HEIGHT
QTH-30-02-D-XX (SEE NOTE 6)
"B"
T-1S60-XX-X
.278 7.07 REF
'H'
C
.155±.003 3.94±0.08
"E"
- .001
(SEE NOTE 5 & 8)
SEE TABLE 2, SHT 1
+.003 [.08]
[.03]
.118 3.00 REF
.010 0.25 REF
"B"
T-1G1-XX-X
QTHH-30-01-D-XX
.037 0.94 REF
.0800 2.032
C
L
.055 1.40
SEE NOTE 10
(SEE NOTE 8)
.053 1.33
.281 7.14
.265 6.73 REF
(QTH-090-03-X-D-LC SHOWN)
(SAME AS FIG 1, EXCEPT AS SHOWN)
"D"
"C"
T-1S60-XX-X
.155±.003 3.94±0.08
.155±.003 3.94±0.08
FIG 5
SECTION "B"-"B"
T-1S61-XX-X
C
+.003 [.08]
"E"
- .001 [.03]
C
"E"
- .001
+.003 [.08]
[.03]
(SEE NOTE 5 & 8)
(SEE NOTE 5 & 8)
"C"
.432 10.97
REF
QTHH-30-03-D-XX
T-1G1-XX-X
SEE TABLE 2, SHT 1
(SEE NOTE 8)
SEE NOTE 10
.600 15.24
REF
QTHH-030-04-D-XX
"D"
T-1G17-XX-X
SEE TABLE 2, SHT 1
(SEE NOTE 8)
SEE NOTE 10
(QTH-090-05-X-D SHOWN)
(SAME AS FIG 5, EXCEPT AS SHOWN)
FIG 6
SECTION "C"-"C"
SCALE 1.25 : 1
(QTH-090-07-X-D SHOWN)
(SAME AS FIG 5, EXCEPT AS SHOWN)
THIS SHEET
FIG 7
SECTION "D"-"D"
SCALE 1.25 : 1
*
CPC
*
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
C1, C2, C4,
C5
DO NOT SCALE DRAWING
.5mm DOUBLE ROW HS TERMINAL ASSEMBLY
DWG. NO.
SHEET SCALE: 1:0.571429
QTH-XXX-XX-X-D-XXX
09-14-2010
SHEET
3
OF
6
F:\DWG\MISC\MKTG\QTH-XXX-XX-X-D-XXX-MKT.SLDDRW
BY:
DEAN P
REVISION BG
"F" REF
"H"
.233 5.91
REF
C
L
SEE TABLE 8
"G" REF
.125 3.18 REF
(QTH-090-01-X-D-GP SHOWN)
(SAME AS FIG 1, EXCEPT AS SHOWN)
(AVAILABLE ON -01 & -02 ONLY)
FIG 8
.008 0.20
REF
.070 1.78 REF (TYP)
.015 0.38 REF
.015 0.38 REF
QTH-30-XX-D-XX-X-FL
'E'
'F'
.012 0.30
REF
DETAIL 'E'
SCALE 12 : 1
DETAIL 'F'
SCALE 12 : 1
THIS SHEET
CPC
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
-FL: FRICTION LOCKS
(NOT AVAILABLE WITH -GP OPTION)
(SAME AS FIG 1, EXCEPT AS SHOWN)
FIG 9
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
C6
DO NOT SCALE DRAWING
.5mm DOUBLE ROW HS TERMINAL ASSEMBLY
DWG. NO.
SHEET SCALE: 2:1
QTH-XXX-XX-X-D-XXX
09-14-2010
SHEET
4
OF
6
F:\DWG\MISC\MKTG\QTH-XXX-XX-X-D-XXX-MKT.SLDDRW
BY:
DEAN P
REVISION BG
C
L
QTH-30-01-D-XX-X-RT1
"J" REF
C
C
"K"±.004[.01]
.190 4.83
.069 1.76
REF
.100 2.54 REF
.070 1.78
REF
T-1R36-01-F (2 PLCS)
(QTH-090-01-X-D-A-RT1 SHOWN)
(NOT AVAILABLE WITH -LC, -GP, OR -FL OPTIONS)
(AVAILABLE ON -01 ONLY)
(SAME AS FIG 1, EXCEPT AS SHOWN)
"L" REF
FIG 10
.062 1.57 REF
(* = NOT RELEASED)
C
"M"
QTH-30-01-D-XX-L
C
L
.020 0.50 REF
WT-56-01-T
T-1S39-01-XXX
"N"
C
.010 0.25
REF (TYP)
.053±.002 1.35±0.05
C
.025 0.64
REF
L: LATCHING OPTION
(QTH-060-01-X-D-L SHOWN)
(AVAILABLE ON -01 LEAD STYLE ONLY)
(NOT AVAILABLE WITH -LC, -GP, -FL, OR -RT1 OPTIONS)
(SAME AS FIG 1, EXCEPT AS SHOWN)
FIG 11
THIS SHEET
CPC
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
C7, C8, C9,
C10,
C11,C15
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
.5mm DOUBLE ROW HS TERMINAL ASSEMBLY
SHEET SCALE: 2:1
QTH-XXX-XX-X-D-XXX
09-14-2010
SHEET
5
OF
6
F:\DWG\MISC\MKTG\QTH-XXX-XX-X-D-XXX-MKT.SLDDRW
BY:
DEAN P
