PLATINUM THIN FILM RTD ELEMENTS
• AVAILABLE IN 100, 500, 1000, AND 2000 OHM
RESISTANCE VALUES
• STANDARD IEC 751, ASTME1137 & NON-STANDARD
TOLERANCES AVAILABLE
• WIDE CHOICE OF SIZES
• 2, 3, AND 4 WIRE EXTENSION LEADS AVAILABLE
• CUSTOM-ENGINEERED TEMPERATURE PROBE
ASSEMBLIES
Sensor Scientific, Inc. Platinum Thin Film RTD Elements are fabricat-
ed using state-of-the-art thin film processing techniques, resulting in
an element of exceptional quality and stability. The wide choice of
resistance, tolerance, and size options allows for complete design
flexibility.
RTD elements are available with extension leads, and incorporated in
complete temperature probe assemblies. Please contact Sensor
Scientific for additional information.
Assemblies:
Generally, thin film RTD elements are incorporated into some type of
assembly for protection. Extension leads may be attached via solder-
ing, crimping, brazing or welding. The attachment method must be
capable of withstanding the intended
maximum operating temperature.
The following precautions must be taken when incorporating the
element into an assembly:
1) Avoid straining the element leads.
2) If extension leads are attached via soldering or brazing, all flux
residue must be removed.
3) The resistance of extension leads must be taken into consideration.
Resistance value at 0°C calibrated 1mm from end of lead wire.
4) If elements are encapsulated in a potting compound, insure that
the compound will not induce pressure loads, resulting in a strain-
gage effect.
Resistance
at 0 Deg. C.
ohms
100
100
100
100
100
100
100
500
500
500
1000
1000
1000
1000
2000
Resistance value at 0°C
calibrated 1mm from end of
lead wire. DIN = IEC751
L
Length
mm
5.0 +/- 0.2
5.0 +/- 0.2
2.3 +/- 0.2
5.0 +/- 0.2
10.0 +/- 0.2
5.0 +/- 0.2
1.6+/- 0.15
5.0 +/- 0.2
10.0 +/- 0.2
5.0 +/- 0.2
4.0 +/- 0.2
10.0 +/- 0.2
5.0 +/- 0.2
1.6+/- 0.15
10.0 +/- 0.2
ll
- Tolerance
W
Width
mm
1.0 +/- 0.2
1.5 +/- 0.2
2.0 +/- 0.2
2.0 +/- 0.2
2.0 +/- 0.2
4.0 +/- 0.2
1.25 +/- 0.1
2.0 +/- 0.2
2.0 +/- 0.2
4.0 +/- 0.2
2.0 +/- 0.2
2.0 +/- 0.2
4.0 +/- 0.2
1.25 +/- 0.1
2.0 +/- 0.2
01=1/10 DIN B at 0°C
02 = 1/5 DIN B at 0°C
03 = 1/4 DIN B at 0°C
04 = 1/3 DIN B at 0°C
0A = 1/2 DIN B (DIN A) at 0°C
H
Height
mm
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.00 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.3 +/- 0.2
1.00 +/- 0.2
1.3 +/- 0.2
0B = DIN B
05 = ASTM B
06 = 3/2 DIN B at 0°C
07 = 2 DIN B at 0°C
08 = 5 DIN B at 0°C
09 = 10 DIN B at 0°C
Part Number
P01lln1
P01lln2
P01lln3
P01lln4
P01lln5
P01lln6
P01llM7
P05lln1
P05lln2
P05lln3
P10lln1
P10lln2
P10lln3
P10llM4
P20lln4
n
- Temperature Range
L = -50 to + 400 Deg C
M= -50 to + 550 Deg C
H= -50 to + 600 Deg C
Call us toll-free at 800-524-1610 (in the US) — or check us out on the web at www.sensorsci.com
6 Kings Bridge Road - Fairfield, New Jersey 07004 • sales@sensorsci.com • Phone: (973) 227-7790 - Fax: (973) 227-8063
Reference Table For Pt RTD Elements
°C
-200
-190
-180
-170
-160
-150
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
+10
+20
+30
+40
+50
+60
+70
+80
+90
+100
+110
+120
+130
+140
Ω
°C
+160
+170
+180
+190
+200
+210
+220
+230
+240
+250
+260
+270
+280
+290
+300
+310
+320
+330
+340
+350
+360
+370
+380
+390
+400
+410
+420
+430
+440
+450
+460
+470
+480
+490
+500
Ω
°C
+510
+520
+530
+540
+550
+560
+570
+580
+590
+600
Ω
284.30
287.62
290.92
294.21
297.49
300.75
304.01
307.25
310.49
313.71
18.52
22.83
27.10
31.34
35.54
39.72
43.88
48.00
52.11
56.19
60.26
64.30
68.33
72.33
76.33
80.31
84.27
88.22
92.16
96.09
100.00
103.90
107.79
111.67
115.54
119.40
123.24
127.08
130.90
134.71
138.51
142.29
146.07
149.83
153.58
161.05
164.77
168.48
172.17
175.86
179.53
183.19
186.84
190.47
194.10
197.71
201.31
204.90
208.48
212.05
215.61
219.15
222.68
226.21
229.72
233.21
236.70
240.18
243.64
247.09
250.53
253.96
257.38
260.78
264.18
267.56
270.93
274.29
277.64
280.98
The permissible deviations for platinum resistance elements
are determined by the following equations (in accordance with
IEC 751,2: 1995- 07 [DIN EN 60751: 1996-07]):
Permissible deviation in °C = ±(0.15 + 0.002 [t]) for Class A
Permissible deviation in °C = ±(0.3 + 0.005 [t]) for Class B
Where [t] is the temperature value (in °C)
Deviations in °C apply to all nominal resistances; deviations in
Ω
only to 100
Ω.
For nominal resistance values other than 100
Ω
the deviation
values in
Ω
must be multiplied by the factor R0 X 10
-2
.
Other tolerances are available
Reference
Tables are
available in
5°C and 1°C
increments
upon request
Nominal Resistance: 100 ohms @ 0°C
For Nominal resistance values other than 100
Ω
@ °C resistance
values from the table are corrected using the equation R 0 X10
-2
where R0 =
nominal resistance at 0°C.
• Mean temperature coefficient between 0 and 100°C = 3.85 x 10
-3
x K
-1
(in
accordance with IEC 751,2:1995-07 [DIN EN 60751;1996-07])
• Calculation of Resistance values:
Equations acc. to IEC 751,2: 1995-07 (DIN EN 60751: 1996-07)
Temperature range from -200 to 0°C:
R† + R0 (1 +A† +B†
2
+ C(† - 100°C) †
3
]
Temperature range from 0 to +850°C:
R† + R0 (1 + A† + B†
2
)
Where: A = 3.9083 x 10
-3
°C
-1
; B=-5.775 x 10
-7
°C
-2
; C=-4.183 x 10
-12
°C
-4
R† is the resistance in
Ω
at temperature †
† is the temperature in °C
• Resistance values from -200 to -250°C were obtained by our own fixed
point measurement
6 Kings Bridge Road - Fairfield, New Jersey 07004 • sales@sensorsci.com • Phone: (973) 227-7790 - Fax: (973) 227-8063
