MSC7112-01GS-2K datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> MSC7112-01GS-2K

MSC7112-01GS-2K: DescriptionFluorescent Display Controller, 16 X 12 Segments, CMOS, PQFP44, 0.80 MM PITCH, PLASTIC, QFP-44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size243KB，18 Pages; ManufacturerOKI; Websitehttp://www.oki.com

Download Datasheet Parametric Compare View All

MSC7112-01GS-2K Overview

Fluorescent Display Controller, 16 X 12 Segments, CMOS, PQFP44, 0.80 MM PITCH, PLASTIC, QFP-44

MSC7112-01GS-2K Parametric

Parameter Name	Attribute value
Maker	OKI
Parts packaging code	QFP
package instruction	QFP,
Contacts	44
Reach Compliance Code	unknown
Address bus width
maximum clock frequency	0.5 MHz
show configuration	16 X 12 SEGMENTS
External data bus width	1
JESD-30 code	R-PQFP-G44
length	10.5 mm
Number of terminals	44
Maximum operating temperature	75 °C
Minimum operating temperature	-20 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Not Qualified
Maximum seat height	2.25 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL EXTENDED
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
width	9.5 mm
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, FLUORESCENT

Preview

Download Datasheet

View All

MSC7112-01GS-2K Related Products

	MSC7112-01GS-2K	MSC7112-01SS	MSC7112-01GS-K	MSC7110-01SS	MSC7110-01GS-2K	MSC7110-01GS-K
Description	Fluorescent Display Controller, 16 X 12 Segments, CMOS, PQFP44, 0.80 MM PITCH, PLASTIC, QFP-44	Fluorescent Display Controller, 16 X 12 Segments, CMOS, PDIP42, 0.600 INCH, 1.778 MM PITCH, PLASTIC, SDIP-42	Segment LED Driver, 12 X 16 Segments, CMOS, PQFP44, 9 X 10 MM, 0.80 MM PITCH, PLASTIC, QFP-44	Segment LED Driver, 16 X 12 Segments, CMOS, PDIP42, 0.600 INCH, 1.78 MM PITCH, PLASTIC, SDIP-42	Fluorescent Display Controller, 16 X 12 Segments, CMOS, PQFP44, 0.80 MM PITCH, PLASTIC, QFP-44	Segment LED Driver, 16 X 12 Segments, CMOS, PQFP44, 9 X 10 MM, 0.80 MM PITCH, PLASTIC, QFP-44
Maker	OKI	OKI	OKI	OKI	OKI	OKI
Parts packaging code	QFP	DIP	QFP	DIP	QFP	QFP
package instruction	QFP,	SDIP,	QFP,	SDIP,	QFP,	QFP,
Contacts	44	42	44	42	44	44
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
maximum clock frequency	0.5 MHz	0.5 MHz	0.5 MHz	0.5 MHz	0.5 MHz	0.5 MHz
show configuration	16 X 12 SEGMENTS	16 X 12 SEGMENTS	12 X 16 SEGMENTS	16 X 12 SEGMENTS	16 X 12 SEGMENTS	16 X 12 SEGMENTS
External data bus width	1	1	1	1	1	1
JESD-30 code	R-PQFP-G44	R-PDIP-T42	R-PQFP-G44	R-PDIP-T42	R-PQFP-G44	R-PQFP-G44
length	10.5 mm	38.1 mm	10.5 mm	38.1 mm	10.5 mm	10.5 mm
Number of terminals	44	42	44	42	44	44
Maximum operating temperature	75 °C	75 °C	75 °C	75 °C	75 °C	75 °C
Minimum operating temperature	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	SDIP	QFP	SDIP	QFP	QFP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	2.25 mm	5.08 mm	2 mm	5.08 mm	2.25 mm	2 mm
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	NO	YES	NO	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED
Terminal form	GULL WING	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING
Terminal pitch	0.8 mm	1.778 mm	0.8 mm	1.778 mm	0.8 mm	0.8 mm
Terminal location	QUAD	DUAL	QUAD	DUAL	QUAD	QUAD
width	9.5 mm	15.24 mm	9.5 mm	15.24 mm	9.5 mm	9.5 mm
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, FLUORESCENT	DISPLAY CONTROLLER, FLUORESCENT	DISPLAY CONTROLLER, SEGMENT LED DRIVER	DISPLAY CONTROLLER, SEGMENT LED DRIVER	DISPLAY CONTROLLER, FLUORESCENT	DISPLAY CONTROLLER, SEGMENT LED DRIVER
Base Number Matches	-	1	1	1	1	1
