PJD1616CGT datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> PJD1616CGT

PJD1616CGT: DescriptionSmall Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92; CategoryDiscrete semiconductor The transistor; File Size251KB，3 Pages; ManufacturerPromax-Johnton Electronic Corporation

Download Datasheet Parametric Compare View All

PJD1616CGT Overview

Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92

PJD1616CGT Parametric

Parameter Name	Attribute value
Maker	Promax-Johnton Electronic Corporation
package instruction	CYLINDRICAL, O-PBCY-T3
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum collector current (IC)	0.5 A
Collector-emitter maximum voltage	60 V
Configuration	SINGLE
Minimum DC current gain (hFE)	200
JEDEC-95 code	TO-92
JESD-30 code	O-PBCY-T3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	160 MHz
Maximum off time (toff)	1020 ns
Maximum opening time (tons)	70 ns

Preview

Download Datasheet

View All

' ;/(

! "

#$ "

#$ ! "

%&'(

)%&'%!(

$!!$* $&+,

-%&$&#* %

"#* %

#!2%33/4

+,+

$&?

6 !

$&?

6 !

//1/

' ;/(

%55%&

#$%55%&

)%& $&

))6 ! #$+& "

) #$ % $& "

)6 ! #$ % $& "

+%*% * $ &

%& $&6 &78$797%

'&(

'! (

!"!

;.2

;

;.2

;

;/#

;<#

;/#

;25; =

;

'55(;1

%&+&$#

"$#

: $#

%!!?/!2%334

9: '(

PJD1616CGT Related Products

	PJD1616CGT	PJD1616CYX	PJD1616CYT	PJD1616CLT	PJD1616CX	PJD1616CT	PJD1616CLX	PJD1616CGX
Description	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon, TO-92	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon	Small Signal Bipolar Transistor, 0.5A I(C), 60V V(BR)CEO, 1-Element, NPN, Silicon
package instruction	CYLINDRICAL, O-PBCY-T3	SMALL OUTLINE, R-PDSO-G3	CYLINDRICAL, O-PBCY-T3	CYLINDRICAL, O-PBCY-T3	SMALL OUTLINE, R-PDSO-G3	CYLINDRICAL, O-PBCY-T3	SMALL OUTLINE, R-PDSO-G3	SMALL OUTLINE, R-PDSO-G3
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum collector current (IC)	0.5 A	0.5 A	0.5 A	0.5 A	0.5 A	0.5 A	0.5 A	0.5 A
Collector-emitter maximum voltage	60 V	60 V	60 V	60 V	60 V	60 V	60 V	60 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Minimum DC current gain (hFE)	200	135	135	300	81	81	300	200
JESD-30 code	O-PBCY-T3	R-PDSO-G3	O-PBCY-T3	O-PBCY-T3	R-PDSO-G3	O-PBCY-T3	R-PDSO-G3	R-PDSO-G3
Number of components	1	1	1	1	1	1	1	1
Number of terminals	3	3	3	3	3	3	3	3
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	RECTANGULAR	ROUND	ROUND	RECTANGULAR	ROUND	RECTANGULAR	RECTANGULAR
Package form	CYLINDRICAL	SMALL OUTLINE	CYLINDRICAL	CYLINDRICAL	SMALL OUTLINE	CYLINDRICAL	SMALL OUTLINE	SMALL OUTLINE
Polarity/channel type	NPN	NPN	NPN	NPN	NPN	NPN	NPN	NPN
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	YES	NO	NO	YES	NO	YES	YES
Terminal form	THROUGH-HOLE	GULL WING	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING
Terminal location	BOTTOM	DUAL	BOTTOM	BOTTOM	DUAL	BOTTOM	DUAL	DUAL
transistor applications	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz	160 MHz
Maximum off time (toff)	1020 ns	1020 ns	1020 ns	1020 ns	1020 ns	1020 ns	1020 ns	1020 ns
Maximum opening time (tons)	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns	70 ns
