Pressure sensors
Absolute pressure transducers
Preliminary data
Description
The transducers are based on piezoresistive silicon pressure sensors
from our own clean room.
The robust stainless steel casing is accentuated
through its excellent mechanical decoupling.
Features
Piezoresistive MEMS technology
Measured media:
Air, non-aggressive gases (gas humidity 0 ... 85% r.h., without dew)
Unsuitable for substances which react with glass, silicon, gold,
aluminum, stainless steel, silicone glue or silicone gel.
Whetstone bridge with mV output, proportional to pressure
and ratiometric to supply voltage
RoHS-compatible, halogen-free
TO39 package for PCB mounting
Dimensional drawings
Type TH (M5 thread connection)
AT2 series
TO39
5
4
pressure port
Ø0.45
Ø12.6
Ø11.6
6.2
6.5
4
08
Ø5.
3
2
1
All dimensions in mm
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document.
Page 2 of 7
2009-08-03
Ø9.2
M5
Pressure sensors
Absolute pressure transducers
Preliminary data
Technical data
Absolute maximum ratings
Parameter
Temperature ranges
Storage temperature range
Operating temperature range
Soldering temperature
Supply voltage /-current
Supply voltage
DC break down voltage
Parameter
V
DD
V
is
Symbol
5)
6)
AT2 series
Symbol
Conditions
Min.
Typ.
Max.
Unit
T
st
T
a
T
solder
1)
2)
–40
–30
+125
+85
+240
°
C
°
C
°
C
<5 s
(no reflow soldering)
10
500
Min.
Typ.
Max.
V
V
Unit
Conditions
Offset / bridge resistance @ T
a
= 25 ° V
DD
= 5 V
C,
Bridge resistance
Offset
R
S
V
0
(Pin 2-4)
7)
2.6
–30
3.3
0
4.0
+30
kΩ
mV
Data in temperature range @ T
a
= –30 ... 85 ° V
DD
= 5 V
C,
Temperature hysteresis
Temperature coefficients of the
bridge resistance
Temperature coefficients of the
sensitivity
Temperature coefficient of offset
α
Rs
β
Rs
α
S
β
S
TCV
0
13)
12)
10)
11)
±0.1
2.0
3
–2.5
3
2.3
5
–2.2
5
±4
±0.5
2.6
8
–1.9
8
% FS
10 /K
10 /K
10 /K
10 /K
-6
2
-3
-6
2
-3
µV/VK
Data dependent on rated pressure
@ T
a
= 25 °C, V
DD
= 5 V
Rated pressure p
r
bar
1.600
2.500
4.000
6.000
10.00
16.00
25.00
3)
TCV
0
13)
Sensitivity S
Min.
mV/bar
45
36
23
15
9
6.4
4.1
Typ.
mV/bar
70
49
31
21
12
7.8
5
8)
Nonlinearity L
Typ.
% FS
Max.
% FS
9)
Overpressure p
ov
Min.
bar
4
5
6
4)
Max.
µV/VK
±10
±10
±10
±10
±10
±10
±10
Max.
mV/bar
95
60
38
25
15
9
5.9
±0.2
±0.3
9
15
24
37.5
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document.
Page 3 of 7
2009-08-03
Pressure sensors
Absolute pressure transducers
Preliminary data
Terminal assignment
2 VDD+
Pin
1
2
3
Symbol
n.c.
V
DD+
V
out–
V
DD–
V
out+
Terminal assignment
Do not connect
Supply voltage
Output voltage
Supply voltage
Output voltage
AT2 series
5 Vout+
3 Vout–
4
5
The polarity of V
out
applies to positive pressure.
Negative pressure or a reversed supply voltage
results in a reversed polarity of the output voltage V
out
.
4 VDD–
Rated pressures and ordering codes
Rated pressure p
r
bar
1.600
2.500
4.000
6.000
10.00
16.00
25.00
Product type
ATA 1.600 MA0 HG
ATA 2.500 MA0 HG
ATA 4.000 MA0 HG
ATA 6.000 MA0 HG
ATA 10.00 MA0 HG
ATA 16.00 MA0 HG
ATA 25.00 MA0 HG
Ordering code
B58610T4600A001
B58610T4600A002
B58610T4600A003
B58610T4600A004
B58610T4600A005
B58610T4600A006
B58610T4600A007
