HSMS-270B-TR1G

Description
UNIDIRECTIONAL, SILICON, TVS DIODE, ROHS COMPLIANT, SC-70, 3 PIN
CategoryDiscrete semiconductor    diode
File Size112KB,9 Pages
ManufacturerAVAGO
Websitehttp://www.avagotech.com/
Environmental Compliance
Download Datasheet Parametric View All

HSMS-270B-TR1G Online Shopping

Suppliers Part Number Price MOQ In stock
HSMS-270B-TR1G - - View Buy Now

HSMS-270B-TR1G Overview

UNIDIRECTIONAL, SILICON, TVS DIODE, ROHS COMPLIANT, SC-70, 3 PIN

HSMS-270B-TR1G Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerAVAGO
Parts packaging codeSC-70
package instructionR-PDSO-G3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresLOW CAPACITANCE
Minimum breakdown voltage15 V
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeTRANS VOLTAGE SUPPRESSOR DIODE
Maximum forward voltage (VF)0.55 V
JESD-30 codeR-PDSO-G3
JESD-609 codee3
Humidity sensitivity level1
Maximum non-repetitive peak forward current1 A
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Maximum output current0.75 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
polarityUNIDIRECTIONAL
Maximum power dissipation0.825 W
Certification statusNot Qualified
Maximum repetitive peak reverse voltage15 V
surface mountYES
technologySCHOTTKY
Terminal surfaceMatte Tin (Sn)
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
HSMS-2700, 2702, 270B, 270C, 270P
High Performance Schottky Diode
for Transient Suppression
Data Sheet
Description
The HSMS-2700 series of Schottky diodes, commonly
referred to as clipping /clamping diodes, are optimal for
circuit and waveshape preservation applications with
high speed switching. Ultra-low series resistance, R
S
,
makes them ideal for protecting sensitive circuit elements
against higher current transients carried on data lines.
With picosecond switching, the HSMS-270x can respond
to noise spikes with rise times as fast as 1 ns. Low ca-
pacitance minimizes waveshape loss that causes signal
degradation.
Features
Ultra-low Series Resistance for Higher Current
Handling
Picosecond Switching
Low Capacitance
Lead-free
Applications
RF and computer designs that require circuit protection,
high-speed switching, and voltage clamping.
HSMS-270x DC Electrical Specifications, T
A
= +25°C
[1]
Part
Number
HSMS-
-2700
-270B
-2702
-270C
-270P
J2
JP
Package
Marking
Code
[2]
J0
Lead
Code
0
B
2
C
P
Configuration
Single
Package
SOT-23
SOT-323
(3-lead SC-70)
SOT-23
Maximum
Forward
Voltage
V
F
(mV)
Minimum
Breakdown Typical
Voltage
Capacitance
V
BR
(V)
C
T
(pF)
Typical
Series
Resistance
R
S
(Ω)
Maximum
Eff. Carrier
Lifetime
τ
(ps)
550
[3]
15
[4]
6.7
[5]
0.65
100
[6]
Series
Bridge Quad
SOT-323
(3-lead SC-70)
SOT-363
(6-lead SC-70)
Notes:
1. T
A
= +25°C, where T
A
is defined to be the temperature at the package pins where contact is made to the circuit board.
2. Package marking code is laser marked.
3. I
F
= 100 mA; 100% tested
4. I
R
= 100
μA;
100% tested
5. V
F
= 0; f =1 MHz
6. Measured with Karkauer method at 20 mA; guaranteed by design.
Package Lead Code Identification (Top View)
SINGLE
3
SERIES
3
BRIDGE QUAD
6
5 4
1
0, B
2
1
2, C
2
1
2
3
