BCU87-SMD datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> BCU87-SMD

BCU87-SMD: Description3000mA, 50V, PNP, Si, SMALL SIGNAL TRANSISTOR; CategoryDiscrete semiconductor The transistor; File Size122KB，6 Pages; ManufacturerSEMELAB

Download Datasheet Parametric View All

BCU87-SMD Overview

3000mA, 50V, PNP, Si, SMALL SIGNAL TRANSISTOR

BCU87-SMD Parametric

Parameter Name	Attribute value
Maker	SEMELAB
package instruction	SMALL OUTLINE, R-PSSO-F3
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	COLLECTOR
Maximum collector current (IC)	3 A
Collector-emitter maximum voltage	50 V
Configuration	SINGLE
Minimum DC current gain (hFE)	100
JESD-30 code	R-PSSO-F3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	SINGLE
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	150 MHz

Preview

Download Datasheet

View All

BCU86-SMD

BCU87-SMD

MECHANICAL DATA

Dimensions in mm

4 .5

1 .6

1 .5

NPN/PNP EPITAXIAL PLANAR

SILICON TRANSISTOR

Ideal For High current Switching

Application

4 .2 5 m a x .

2 .5

FEATURES

• LOW V

CE(SAT)

0 .4 0

0 .5 0

1 .5

3 .0

1 .0

0 .4 0

• HIGH CURRENT CAPACITY AND WIDE ASO

• FAST SWITCHING SPEED

APPLICATIONS

SOT89

• VOLTAGE REGULATORS

• RELAY DRIVERS

• LAMP DRIVERS

• ELECTRICAL EQUIPMENT

ABSOLUTE MAXIMUM RATINGS

(Tcase = 25°C unless otherwise stated)

CBO

CEO

EBO

stg

Collector – Base voltage

Collector – Emitter voltage (I

= 0)

Emitter – Base voltage

Collector current

Collector Current (Pulse)

Collector Dissipation

(Mounted on Ceramic Board (250mm

2 x 0.8mm)

Junction Temperature

Storage Temperature

Telephone +44(0)1455 554711.

Fax +44(0)1455 558843.

E-mail:

magnatec@semelab.co.uk

Website:

http://www.semelab.co.uk

BCU86

60V

50V

500mW

1.5W

150°C

BCU87

– 60V

– 50V

– 6V

– 3A

– 6A

–55 to 150°C

Prelim.9/98

Magnatec.
