SAB-C167CR-L33MHA+ datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAB-C167CR-L33MHA+

SAB-C167CR-L33MHA+: DescriptionMicrocontroller, 16-Bit, 33MHz, CMOS, PQFP144, PLASTIC, MQFP-144; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，91 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric View All

SAB-C167CR-L33MHA+ Overview

Microcontroller, 16-Bit, 33MHz, CMOS, PQFP144, PLASTIC, MQFP-144

SAB-C167CR-L33MHA+ Parametric

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	QFP,
Contacts	144
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Has ADC	YES
Address bus width	24
bit size	16
maximum clock frequency	33 MHz
DAC channel	NO
DMA channel	NO
External data bus width	16
JESD-30 code	S-PQFP-G144
length	28 mm
Number of I/O lines	111
Number of terminals	144
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	SQUARE
Package form	FLATPACK
Certification status	Not Qualified
Maximum seat height	2.75 mm
speed	33 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	QUAD
width	28 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Data Sheet, V3.3, Feb. 2005

C167CR

C167SR

16-Bit Single-Chip Microcontroller

Microcontrollers

N e v e r

s t o p

t h i n k i n g .

C167CR

C167SR

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.1

2.2

2.3

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

3.15

4.1

4.2

4.3

4.4

4.4.1

4.4.2

4.4.3

4.4.4

Summary of Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General Device Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Pin Configuration and Definition for P-MQFP-144-8 . . . . . . . . . . . . . . . . . . 8

Pin Configuration and Definition for P-BGA-176-2 . . . . . . . . . . . . . . . . . . 17

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Bus Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare (CAPCOM) Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PWM Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Purpose Timer (GPT) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A/D Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Serial Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CAN-Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Oscillator Watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Special Function Registers Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical Parameters

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Analog/Digital Converter Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Definition of Internal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Clock Drive XTAL1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Testing Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Bus Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package Outlines

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Data Sheet

V3.3, 2005-02
