REVISION K
NOTES:
C3
K
1.
C
REPRESENTS A CRITICAL DIMENSION.
TEFLON CABLE OPTION
2. BURR ALLOWANCE: .003[.08] MAX.
3. PARTS TO BE MOLDED TO POSITION.
*
-T: TEFLON
4. MINIMUM PULLOUT FORCE: 5 lbs[22.24 N].
(LEAVE BLANK FOR STANDARD
5. CONTACT MUST BE INSERTED UNTIL RETENTION FEATURE LOCKS INTO PLACE.
PVC INSULATION)
6. ALL FINISHED GOODS ARE TO BE LAYER PACKAGED IN SHIPPING.
7. ONLY AVAILABLE IN TIN PLATING.
No OF POSITIONS
8. ALL PARTS TO PASS ELECTRICAL TEST UPON ASSEMBLY (INCLUDING HI-POT
TESTAT 1000 VOLTS DC). AFTER FINAL ELECTRICAL TEST, LABEL EACH ASSEMBLY WITH 1 LABEL-ET.
-02 THRU -10
9. APPLICATIONS INVOLVING SEVERE BENDING REQUIRE 6" MINIMUM
WIRE GAUGE (AWG)
CABLE LENGTH.
[SEE TABLE 1]
10. FOR CRIMP DIMENSIONS AND WIRE PROCESSING SEE DWL-01-XXXX-X-XX.XX-XX-XX FOR
-16, -18, -206, -203, -22, -24
PVC APPLICATIONS OR DWLX-01-XXXX-X-XX.XX-XX-XX FOR PTFE APPLICATIONS.
11. NOTE DELETED.
PMSSX-XX-XXXX-XX-XX.XX-X-XXX
OPTION
[MUST BE USED ON -D END OPTION
ONLY & APPLIES TO END 2 HOUSING]
-LUS: LATCH UP, STRAIGHT
(SEE FIG. 3, SHEET 2)
-LDS: LATCH DOWN, STRAIGHT
(SEE FIG. 4, SHEET 2)
END OPTION
-S: SINGLE END
-D: DOUBLE END
(MUST CHOOSE LUS OR LDS OPTIONS)
ASSEMBLED LENGTH
SPECIFY IN INCHES (03.00 INCH MINIMUM)
[USE DWCX-XX-XX-XXX]
12. FOR LENGTHS LESS THAN 12 IN, TOLERANCE SHALL
BE ±.125[3.18]. FOR OTHER LENGTHS, TOLERANCES SHALL BE ±2%.
(No OF POS x .165[4.19])
+ .040[1.02]) REF
02
01
13. AVAILABLE TO EXISTING CUSTOMERS ONLY. DO NOT DESIGN IN AS OF REVISION H.
WIRE COLOR
LEAVE BLANK FOR ALL BLACK WIRE
C: COLOR CODED WIRE
(SEE COLOR SEQUENCE TABLE, SHEET 2)
(NOT AVAILABLE WITH TEFLON OPTION)
LEAD STYLE
-SP: STANDARD POWER (C-169-XX-SP-T)
-HP: HIGH POWER (C-169-XX-HP-T)
(SEE NOTE 13)
.313 7.95 REF
DO NOT
SCALE FROM
THIS PRINT
.213 5.41 REF
IPBD-XX-S
*
NOT RELEASED FOR PRODUCTION
PMSSX-05-XX-XX-XX.XX-D-LUS SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
FIG. 2
"A"
.770 19.56
REF
C-169-XX-XX-T
(SEE TABLE 1)
.485 12.32
REF
K
C1
XX.XX
(SEE NOTE 12)
DWLX-01-XXXX-S-XX.XX-XX-XX
(SEE TABLE 1)
C2
XX.XX
(SEE NOTE 12)
IPBD-XX-S
FIG. 1
"A"
PMSSX-05-XX-XX-XX.XX-S SHOWN
SECTION "A"-"A"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1:1
*
*
F:\DWG\MISC\MKTG\PMSSX-XX-XXXX-XX-XX.XX-X-XXX-MKT.SLDDRW
HOUSING: VALOX 457, COLOR: NATURAL
CONTACT: PHOS BRONZE
CABLE; INSULATION: SEE CALLOUT
WIRE: SEE CABLE PRINT
(NOT LEAD FREE)
.165[4.19] SOCKET DISCREET CABLE ASSEMBLY
BY:
DEAN P
PMSSX-XX-XXXX-XX-XX.XX-X-XXX
04/14/2005
SHEET
1
OF
2
REVISION K
FIG. 3
PMSSX-05-XX-XX-XX.XX-D-LUS SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
FIG. 4
PMSSX-05-XX-XX-XX.XX-D-LDS SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
LATCH-
END 2
LATCH-
END 1
LATCH-
END 1
[LATCH UP]
-LUS
LATCH-
END 2
[LATCH DOWN]
-LDS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 0.875:1
.165[4.19] SOCKET DISCREET CABLE ASSEMBLY
PMSSX-XX-XXXX-XX-XX.XX-X-XXX
04/14/2005
SHEET
2
OF
2
F:\DWG\MISC\MKTG\PMSSX-XX-XXXX-XX-XX.XX-X-XXX-MKT.SLDDRW
BY:
DEAN P
