Bussmann
®
Industrial HRC Fuse Link
31 x 112mm, BS88, IEC 269-1
Offset Bolted Tags
DEO
Time-Current Characteristic Curve
(Full Size Curves Available)
125
160
200
200M250
200M315
1,000
CURRENT
RATING
100
Dimensional Data:
A
B
C
D
F
G
H
TIME IN SECONDS
J
CATALOG SYMBOL: DEO
INDUSTRIAL HRC FUSE
OFFSET BOLTED TAGS
PACKAGE QUANTITY: 5
80kA INTERRUPTING RATING
MOUNTS ON BH-0111 MODULAR FUSEBLOCK
10
1
.1
E
CURRENT IN AMPERES
Electrical Characteristics
Catalog
Number
DEO125
DEO160
DEO200
DEO200M250
DEO200M315
Ampere
Rating
125
160
200
200M250
200M315
I
2
T (Amp
2
Seconds)
Pre-
Total At
Arcing
240V
29,500
57,000
120,000
200,000
265,000
50,000
97,000
205,000
340,000
45,000
Total At
415V
71,000
135,000
290,000
480,000
635,000
Nom
Watts
Loss
11
13
14
18
22
Dimensions (Inches/mm)
Rated
Voltage
A
B
C
D
E
F
G
H
J
415AC
110.0
93.7
47.0
9.0
10.0
19.0
0.13
3.2
31.0
29.5
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled.This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been select-
ed, it should be tested by the user in all possible applications.
12-17-98
SB98107
Rev. A
Form No. DEO
Page 1 of 1
BIF Doc #4117
10,000
1,000
100
10
.01
