Preview

DJ80A-300L-480F10: Description1-OUTPUT 500W DC-DC REG PWR SUPPLY MODULE; CategoryPower/power management The power supply circuit; File Size123KB，2 Pages; ManufacturerEmerson Embedded Power

Download Datasheet Parametric Compare View All

DJ80A-300L-480F10 Overview

1-OUTPUT 500W DC-DC REG PWR SUPPLY MODULE

DJ80A-300L-480F10 Parametric

Parameter Name	Attribute value
Maker	Emerson Embedded Power
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Certification	UL; CSA; VDE; CE
Efficiency (main output)	88%
Maximum input voltage	400 V
Minimum input voltage	240 V
Nominal input voltage	300 V
JESD-30 code	R-XXMA-X22
Maximum grid adjustment rate	2%
Maximum load regulation	2.5%
Number of functions	1
Output times	1
Number of terminals	22
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Maximum output voltage	56.64 V
Minimum output voltage	40.8 V
Nominal output voltage	48 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Protect	THERMAL; CURRENT; OUTPUT OVER VOLTAGE; INPUT LOW VOLTAGE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	UNSPECIFIED
Terminal location	UNSPECIFIED
Maximum total power output	500 W
Fine-tuning/adjustable output	YES

Preview

Download Datasheet

View All

DJ80A-300L-480F10 Related Products

	DJ80A-300L-480F10	DJ80A-300L-240F20	DJ80A-300L-480F08
Description	1-OUTPUT 500W DC-DC REG PWR SUPPLY MODULE	1-OUTPUT 500W DC-DC REG PWR SUPPLY MODULE	1-OUTPUT 400W DC-DC REG PWR SUPPLY MODULE
Reach Compliance Code	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	400 V	400 V	400 V
Minimum input voltage	240 V	240 V	240 V
Nominal input voltage	300 V	300 V	300 V
JESD-30 code	R-XXMA-X22	R-XXMA-X22	R-XXMA-X22
Maximum load regulation	2.5%	2.5%	2.5%
Number of functions	1	1	1
Output times	1	1	1
Number of terminals	22	22	22
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-20 °C	-20 °C	-20 °C
Maximum output voltage	56.64 V	28.32 V	56.64 V
Minimum output voltage	40.8 V	21.6 V	40.8 V
Nominal output voltage	48 V	24 V	48 V
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO
technology	HYBRID	HYBRID	HYBRID
Temperature level	OTHER	OTHER	OTHER
Terminal form	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Terminal location	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Maximum total power output	500 W	500 W	400 W
Fine-tuning/adjustable output	YES	YES	YES
Maker	Emerson Embedded Power	-	Emerson Embedded Power
Certification	UL; CSA; VDE; CE	-	UL; CSA; VDE; CE
Maximum grid adjustment rate	2%	-	2%
Protect	THERMAL; CURRENT; OUTPUT OVER VOLTAGE; INPUT LOW VOLTAGE	-	THERMAL; CURRENT; OUTPUT OVER VOLTAGE; INPUT LOW VOLTAGE
