PLANAR SPLITTERS FROM GOULD FIBER OPTICS
Gould’s high reliability and superior performance Planar Splitters are the
component choice to combine or split optical power in optical fiber networks and
systems. They are designed to meet the technical requirements of a broad range of
applications at a competitive price/performance ratio.
Both 1xN & 2XN Planar Splitters
come in three class grades:
•
A-Grade
(best grade) planar splitters feature ultra-low Insertion Loss and
(1)
superior Uniformity to fit and function in very demanding systems or networks.
•
S- Grade
(standard grade) planar splitters yield excellent overall performance.
•
U- Grade
(ultra-broadband grade) planar splitters offer best-in-class per-
formances in a wider operating wavelength range (1260 to 1650nm).
Planar Splitters
can be purchased with different pig tailing and/or packaging
configurations in order to respond to all types of applications. They are extremely easy to
handle and integrate into conventional cassettes, splicing enclosures and rack mounted
modules, such as LGX™. A wide selection of connectors is available as an option.
(1) Valid under any combination of polarization, environmental and mechanical configuration.
◗
Key Strengths
•
•
•
•
•
•
•
Very low Insertion Loss
Superior Uniformity
Low Back Reflection
Ultra Low PDL
Highly reliable and
Compact packaging
Extended bandwidth up to 1650 nm (E-band included)
Tel: 410.987.5600, FAX: 410.987.1201, EMAIL:
info@gouldfo.com
WEB: www.gouldfo.com
PLANAR SPLITTERS FROM GOULD FIBER OPTICS
◗
Performance of packaged 1XN splitters.
A- grade
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
PDL
(2)
(dB)
Return Loss
(2)
(dB)
Directivity
(2)
(dB)
Fiber type
Input/output fiber length
Operating temperature
(3)
Storage temperature
Packaging dimensions
1x3
1x4
1x5
1260-1360 / 1480-1580 nm
6
7.3
8.3
0.4
0.5
0.6
1x3
6.4
0.6
1x3
6.9
Pr
0.8
1x4
7.5
0.6
1x4
8
0.8
1x5
8.5
0.8
1x5
1x6
9.1
0.7
1x6
9.4
0.8
1x6
1x8
10.5
0.8
1x10
11.6
0.9
1x12
12.4
1
1x16
13.8
1
1x16
14
1.1
1x16
14.5
1.4
1x24
15.5
1.2
1x24
15.9
1.5
1x24
16.4
Pr
1.7
1x32
17.1
1.3
1x32
17.5
1.5
1x32
18.5
1.7
1x64
20.5
2
1x64
21
2.5
1x64
22
Pr
3
S- grade
1x8
1x10
1x12
1260-1360 / 1480-1580 nm
10.9
11.9
12.9
1
1
1.1
1x8
U- grade
1x10
1x12
1260-1650 nm
8.9
9.8
11.4
12.4
13.4
1
1.2
1.4
Pr
1
Pr
1.2
COMMON SPECIFICATIONS
< 0.2dB
> 55dB
SMF
2.5m +/- 0.5m
-40°C to +85°C
67 x 7.5 x 5.6 mm
70 x 13 x 5.6 mm
70 x 13 x 5.6 mm
(1) Data valid under any combination of polarization, environmental and mechanical conditions.
(2) Without connectors.
(3) 900µm tubing pigtailing option has an operating temperature range from -25°C to +70°C.
◗
Performance of packaged 2XN splitters.
A- grade
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
Optical data
Wavelength
Max. Insertion Loss
(1,2)
(dB)
Uniformity
(1,2)
(dB)
2x4
7.6
1.4
2x4
7.8
1.5
2x4
8.5
1.9
2x8
11
1.6
2x8
11.2
1.8
2x8
11.9
2.2
2x16
1260-1360 / 1480-1580 nm
14.6
2.4
2x32
17.8
3
2x32
18
3.3
2x32
1260-1650 nm
15.5
3
19
3.6
S- grade
2x16
1260-1360 / 1480-1580 nm
14.8
2.6
U- grade
2x16
Tel: 410.987.5600, FAX: 410.987.1201, EMAIL:
info@gouldfo.com
WEB: www.gouldfo.com
PLANAR SPLITTERS FROM GOULD FIBER OPTICS
COMMON SPECIFICATIONS
PDL
(2)
(dB)
Return Loss
(2)
(dB)
Directivity
(2)
(dB)
Fiber type
Input/output fiber
length
Operating
temperature
(3)
Storage temperature
Packaging dimensions
< 0.2
> 55
SMF
2.5 m +/- 0.5 m
-40°C to +85°C
67x7.5x5.6mm
70x13x5.6mm
70x13x5.6mm
(1) Data valid under any combination of polarization, environmental and mechanical conditions.
(2) Without connectors.
(3) 900µm tubing pigtailing option has an operating temperature range from -25°C to +70°C.
◗
Applications
•
•
•
•
•
•
•
PON - FTTx networks
Outside Plant equipments
OADM and ROADM
CATV
DWDM and CWDM systems
Sensors
Instrumentation
◗
Environmental Testing
Components are designed in full compliance with
Telcordia GR1209
and
GR1221.
◗
Ordering Information:
PLNR
Grade
A – Best grade
S – Standard grade
U – Ultra-broadband
grade
Input Output
AA – 250 micron
BB – 900 micron
Loose tube
CC – 2 mm
Package
Connector
0 – None
1 – MU
2 – ST
3 – FC
4 – SC
5 – LC
6 – FC/APC
7 – SC/APC
9 – LC/APC
Spilt Ratio
18 – 1X8
28 – 2X8
51 – 1X16
52 – 2X16
54 – 1X32
55 – 2X32
Lead Length
25 – 2.5 m
For custom options and additional information, please contact us.
Tel: 410.987.5600, FAX: 410.987.1201, EMAIL:
info@gouldfo.com
WEB: www.gouldfo.com
