BZX55C16T50R datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZX55C16T50R

BZX55C16T50R: DescriptionZener Diode, 16V V(Z), 5%, 0.5W, Silicon, Unidirectional, DO-35,; CategoryDiscrete semiconductor diode; File Size327KB，6 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BZX55C16T50R Overview

Zener Diode, 16V V(Z), 5%, 0.5W, Silicon, Unidirectional, DO-35,

BZX55C16T50R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Fairchild
package instruction	O-PALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	40 Ω
JEDEC-95 code	DO-35
JESD-30 code	O-PALF-W2
Number of components	1
Number of terminals	2
Maximum operating temperature	200 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Nominal reference voltage	16 V
surface mount	NO
technology	ZENER
Terminal form	WIRE
Terminal location	AXIAL
Maximum voltage tolerance	5%
Working test current	5 mA

Preview

Download Datasheet

View All

BZX55C 3V3 - BZX55C 33 Series

BZX55C 3V3 - 33 Series Half Watt Zeners

Absolute Maximum Ratings*

Symbol

STG

TA = 25°C unless otherwise noted

Tolerance: C = 5%

Parameter

Storage Temperature Range

Maximum Junction Operating Temperature

Lead Temperature (1/16” from case for 10

seconds)

Total Device Dissipation

Derate above 25°C

Surge Power**

Value

-65 to +200

+ 200

+ 230

500

4.0

Units

°C

mW/°C

These ratings are limiting values above which the serviceability of the diode may be impaired.

Non-recurrent square wave PW= 8.3 ms, TA= 50 degrees C.

NOTES:

These ratings are based on a maximum junction temperature of 200 degrees C.

These are steady state limits. The factory should be consulted on applications involving pulsed

or low duty cycle operations.

DO-35

COLOR BAND DENOTES CATHODE

Electrical Characteristics

Device

MIN

BZX55C 3V3

BZX55C 3V6

BZX55C 3V9

BZX55C 4V3

BZX55C 4V7

BZX55C 5V1

BZX55C 5V6

BZX55C 6V2

BZX55C 6V8

BZX55C 7V5

BZX55C 8V2

BZX55C 9V1

BZX55C 10

BZX55C 11

BZX55C 12

BZX55C 13

BZX55C 15

BZX55C 16

BZX55C 18

BZX55C 20

BZX55C 22

BZX55C 24

BZX55C 27

BZX55C 30

BZX55C 33

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.4

7.0

7.7

8.5

9.4

10.4

11.4

12.4

13.8

15.3

16.8

18.8

20.8

22.8

25.1

28.0

31.0

TA = 25°C unless otherwise noted

(V)

MAX

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

11.6

12.7

14.1

15.6

17.1

19.1

21.1

23.3

25.6

28.9

32.0

35.0

(Ω)

Ω

8.0

7.0

(mA)

(Ω)

Ω

(mA)

(V)

(µA)

2.0

1.0

0.5

0.1

5.0

600

550

450

200

150

110

170

220

1.0

2.0

3.0

5.0

6.2

6.8

7.5

8.2

9.1

(µA)

150°C

2.0

(%/°C)

- 0.060

- 0.055

- 0.050

- 0.040

- 0.020

+0.010

+0.025

+0.032

+0.040

+0.045

+0.048

+0.050

+0.055

+0.060

+0.065

0.070

0.075

0.080

0.085

(mA)

ZRM

115

105

Foward Voltage = 1.0 V Maximum @ I

= 100 mA for all BZX 55 series

2001

Fairchild Semiconductor Corporation

BZX55 Series Rev. A1
