N74F2953A-T datasheet, PDF - EEWORLD Datasheet

N74F2953A-T: DescriptionIC F/FAST SERIES, 8-BIT REGISTERED TRANSCEIVER, INVERTED OUTPUT, PQCC28, PLASTIC, SOT-261-2, LCC-28, Bus Driver/Transceiver; Categorylogic logic; File Size143KB，14 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

N74F2953A-T Overview

IC F/FAST SERIES, 8-BIT REGISTERED TRANSCEIVER, INVERTED OUTPUT, PQCC28, PLASTIC, SOT-261-2, LCC-28, Bus Driver/Transceiver

Parameter Name	Attribute value
Maker	NXP
Parts packaging code	QLCC
package instruction	QCCJ,
Contacts	28
Reach Compliance Code	unknown
Other features	IOL = 24MA @ VOL = 0.5V & IOH = 3MA @ VOH = 2.4V FOR PORT A
series	F/FAST
JESD-30 code	S-PQCC-J28
length	11.5062 mm
Load capacitance (CL)	50 pF
Logic integrated circuit type	REGISTERED BUS TRANSCEIVER
Number of digits	8
Number of functions	1
Number of ports	2
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
Output characteristics	3-STATE
Output polarity	INVERTED
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Maximum supply current (ICC)	175 mA
propagation delay (tpd)	9 ns
Certification status	Not Qualified
Maximum seat height	4.57 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	TTL
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
width	11.5062 mm

INTEGRATED CIRCUITS

74F2952

Registered transceiver, non-inverting

(3-State)

74F2953

Registered transceiver, inverting (3-State)

Product specification

IC15 Data Handbook

1989 Sep 22

Philips

Semiconductors

	N74F2953A-T	N74F2952A-T
Description	IC F/FAST SERIES, 8-BIT REGISTERED TRANSCEIVER, INVERTED OUTPUT, PQCC28, PLASTIC, SOT-261-2, LCC-28, Bus Driver/Transceiver	IC F/FAST SERIES, 8-BIT REGISTERED TRANSCEIVER, TRUE OUTPUT, PQCC28, PLASTIC, SOT-261-2, LCC-28, Bus Driver/Transceiver
Maker	NXP	NXP
Parts packaging code	QLCC	QLCC
package instruction	QCCJ,	QCCJ,
Contacts	28	28
Reach Compliance Code	unknown	unknown
Other features	IOL = 24MA @ VOL = 0.5V & IOH = 3MA @ VOH = 2.4V FOR PORT A	IOL = 24MA @ VOL = 0.5V & IOH = 3MA @ VOH = 2.4V FOR PORT A
series	F/FAST	F/FAST
JESD-30 code	S-PQCC-J28	S-PQCC-J28
length	11.5062 mm	11.5062 mm
Load capacitance (CL)	50 pF	50 pF
Logic integrated circuit type	REGISTERED BUS TRANSCEIVER	REGISTERED BUS TRANSCEIVER
Number of digits	8	8
Number of functions	1	1
Number of ports	2	2
Number of terminals	28	28
Maximum operating temperature	70 °C	70 °C
Output characteristics	3-STATE	3-STATE
Output polarity	INVERTED	TRUE
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QCCJ	QCCJ
Package shape	SQUARE	SQUARE
Package form	CHIP CARRIER	CHIP CARRIER
Maximum supply current (ICC)	175 mA	175 mA
propagation delay (tpd)	9 ns	9 ns
Certification status	Not Qualified	Not Qualified
Maximum seat height	4.57 mm	4.57 mm
Maximum supply voltage (Vsup)	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V
surface mount	YES	YES
technology	TTL	TTL
Temperature level	COMMERCIAL	COMMERCIAL
Terminal form	J BEND	J BEND
Terminal pitch	1.27 mm	1.27 mm
Terminal location	QUAD	QUAD
width	11.5062 mm	11.5062 mm
