Power Inductors - Unshielded
ctparts.com
CTCR54 Series
From 10 µH to 220 µH
Part
Number
CTCR54_-100M
CTCR54_-120M
CTCR54_-150M
CTCR54_-180M
CTCR54_-220M
CTCR54_-270M
CTCR54_-330M
CTCR54_-390M
CTCR54_-470M
CTCR54_-560M
CTCR54_-680M
CTCR54_-820M
CTCR54_-101M
CTCR54_-121M
CTCR54_-151M
CTCR54_-181M
CTCR54_-221M
Not shown at actual size.
SPECIFICATIONS
Parts are only available in ±20% inductance tolerance.
CTCR54F
Please specify “F” for RoHS Compliant
L Test
Freq.
(_Hz)
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
1.0k
1.0k
1.0k
1.0k
1.0k
DCR
Max.
Ω
(Ω)
0.1
0.12
0.14
0.15
0.18
0.2
0.23
0.32
0.37
0.42
0.46
0.60
0.70
0.93
1.1
1.38
1.57
Rated
DC
(A)
1.44
1.4
1.3
1.23
1.11
0.97
0.88
0.80
0.72
0.68
0.61
0.58
0.52
0.48
0.40
0.38
0.35
Inductance
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
5.6
0.220
B
Max.
6.1
0.240
C
Max.
4.85
0.191
D
4.7
0.185
E
2.5
0.098
F
5.8
0.228
G
1.4
0.055
CHARACTERISTICS
Description:
SMD power inductor
Applications:
VTR power supplies, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4284A or HP4285A at
specified frequency
Packaging:
Tape & Reel
Marking:
Marked with inductance code
Rated DC:
This indicates the value of current when the
inductance is 10% lower than its initial value at D.C.
superimposition or D.C. current when at
∆T=40°C,
whichever is
lower.
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
A
C
XXX
D
B
Marking: Inductance Code
1
2
G
E
F
4
3
