6A05 THRU 6A100
Reverse Voltage - 50 to 1000 Volts
GENERAL PURPOSE SILICON RECTIFIER
Forward Current - 6.0 Ampere
FEATURES
●
The plastic package carries Underwriters Laboratory
Flammability Classification 94V-0
●
Construction utilizes void-free
molded plastic technique
●
Low reverse leakage
●
High forward surge current capability
●
High temperature soldering guaranteed:
250 C/10 seconds,0.375
”
(9.5mm) lead length,
5 lbs. (2.3kg) tension
R-6
1.0 (25.4)
MIN.
0.360 (9.1)
0.340(8.6)
DIA.
0.360(9.1)
0.340(8.6)
MECHANICAL DATA
Case
: R-6 molded plastic body
Terminals
: Plated axial leads, solderable per MIL-STD-750,
Method 2026
Polarity
: Color band denotes cathode end
Mounting Position
: Any
Weight
:0.072 ounce, 2.05 grams
1.0 (25.4)
MIN.
0.052 (1.3)
0.048 (1.2)
DIA.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
Characteristic
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375”(9.5mm) lead length at T
A
=60 C
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at 6.0A
Maximum DC reverse current
T
A
=25 C
at rated DC blocking voltage
T
A
=100 C
Typical junction capacitance (NOTE 1)
Typical thermal resistance (NOTE 2)
Operating junction and storage temperature range
SYMBOLS
6A05
6A10
6A20
6A40
6A60
6A80
6A100
UNITS
V
V
V
A
A
V
µA
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
R
JA
T
J
,
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
6.0
400
0.95
10.0
400
600
420
600
800
560
800
1000
700
1000
150
10.0
-65 to +150
pF
C/W
C
Note:1.Measured
at 1MHz and applied reverse voltage of 4.0V D.C.
2.Thermal resistance from junction to ambient at 0.375” (9.5mm)lead length,P.C.B. mounted
6A05 THRU 6A100
RATINGS AND CHARACTERISTIC CURVES
AVERAGE FORWARD RECTIFIED CURRENT,
AMPERES
FIG. 1- FORWARD CURRENT DERATING CURVE
PEAK FORWARD SURGE CURRENT,
AMPERES
6.0
FIG. 2-MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT
400
4.8
320
3.6
240
2.4
Single Phase
Half Wave 60Hz
Resistive or
inductive Load
160
1.2
80
8.3ms SINGLE HALF SINE-WAVE
(JEDEC Method)
0
0
25
50
75
100
125
150
175
0
1
10
100
AMBIENT TEMPERATURE, C
NUMBER OF CYCLES AT 60 Hz
FIG. 3-TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
200
FIG. 4-TYPICAL REVERSE CHARACTERISTICS
1,000
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
INSTANTANEOUS FORWARD
CURRENT,AMPERES
100
100
TJ=150 C
10
10
TJ=100 C
1
1
T
J
=25 C
PULSE WIDTH=300
ms
1%DUTY CYCLE
0.1
0.1
TJ=25 C
0.01
0.5
0.7
0.9
1.1
1.3
1.4
INSTANTANEOUS FORWARD VOLEAGE,
VOLTS
0
20
40
60
80
100
PERCENT OF PEAK REVERSE VOLTAGE,%
FIG. 5-TYPICAL JUNCTION CAPACITANCE
TRANSIENT THERMAL IMPEDANCE,
C/W
2000
1000
T
J
=25 C
100
FIG. 6-TYPICAL TRANSIENT THERMAL IMPEDANCE
JUNCTION CAPACITANCE, pF
10
100
1
0.1
10
0.01
0.1
1
10
100
0.1
1.0
10
100
REVERSE VOLTAGE,VOLTS
t,PULSE DURATION,sec.
