DF005S THRU DF10S
Reverse Voltage - 50 to 1000 Volts
GLASS PASSIVATED BRIDGE RECTIFIERS
Forward Current - 1.0 Ampere
FEATURES
●
DF-S
.047(1.2)
.037(0.95)
.335(8.5)
.307(7.8)
.031(0.8)
.023(0.6)
.256(6.5)
.244(6.2)
.406(10.3)
.391(10.0)
.140(0.35)
.008(0.2)
.323(8.2)
.315(8.0)
.063(1.6)
.055(1.4)
.205(5.2)
.197(5.0)
.134 (3.4)
.094 (2.4)
●
●
●
Plastic package used has Underwriters
Laboratory Flammability Classification 94V-0
Glass passivated chip junction
High surge overload rating of 50 Amperes peak
High temperature soldering guaranteed:
260°C/10 seconds, at 5 lbs. (2.3kg) tension
MECHANICAL DATA
●
●
Case: Molded plastic body over passivated junctions
Terminals: Plated leads solderable per MIL-STD-750
Method 2026
Mounting Position: Any
Weight: 0.014 oz., 0.4 g
●
●
1
2
3
4
Dim ensions in inches and (m illim eters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
CHARACTERISTICS
SYMBOL
V
RRM
V
RMS
V
DC
o
DF005S
50
35
50
DF01S
100
70
100
DF02S
200
140
200
DF04S
400
280
400
1.0
50
1.1
10.0
500
10
25
40
DF06S
600
420
600
DF08S
800
560
800
DF10S
1000
700
1000
UNITS
V
V
V
A
A
V
µA
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Output Current at T
A
= 40 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum DC Forward Voltage Drop per Bridge
Element at 1.0A DC
Maximum Reverse Current at rated
DC Blocking Voltage per element
I
2
t Rating for Fusing (t<8.3ms)
Typical Junction Capacitance ( Note1)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
NOTES : 1. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
@T
A
= 25
o
C
@T
A
= 125 C
o
I
O
I
FSM
V
F
I
R
I
2
t
C
J
R
θJ
A
T
J,
T
STG
A
2
Sec
pF
0
C/W
C
-55 to + 150
0
2. Thermal Resistance from Junction to Ambient and from junction to lead mounted on P.C.B. with 0.5 x 0.5" (13x13mm) copper pads.
DF005S THRU DF10S
RATINGS AND CHARACTERISTIC CURVES
Fig. 1 - Derating Curve Output
Rectified Current
60 H
Z
Resistive or
Inductive Load
Fig. 2 - Maximum Non-Repetitive Peak
Forward Surge Current Per Leg
Average Forward Output Current (A)
60
50
40
30
20
10
0
Average Forward Output Current (A)
1.0
T
J
= 150
°C
Single Sine-Wave
(JEDEC Method)
0.5
P.C.B mounted on
0.51 x 0.51" (13 x 13mm)
Copper pads with 0.06"
(1.5mm) lead length
0
20
40
60
80
100
120
140 150
1.0 Cycle
1
10
100
Ambient Temperature (
°C)
Number of Cycles at 60 Hz
Instantaneous Reverse Current (
µ
A)
10
Fig. 3 - Typical Forward Characteristics
Per Leg
100
Fig. 4 - Typical Reverse Leakage
Characteristics Per Leg
Instantaneous Forward Current (A)
1
10
T
J
= 125
°C
1
0.1
T
J
= 25
°C
Pulse width = 300
µs
1% Duty Cycle
0.01
0.4
0.6
0.8
1.0
1.2
1.4
0.1
T
J
= 25
°C
0.01
0
20
40
60
80
100
Instantaneous Forward Voltage (V)
Percent of Rated Peak Reverse Voltage (V)
Junction Capacitance (pF)
T
J
= 25
°
C
f = 1.0MHz
Vsig = 50mVp-p
Transient Thermal Impedance (
°
C/W)
100
Fig. 5 - Typical Junction Capacitance
Per Leg
100
Fig. 6 - Typical Transient Thermal
Impedance
10
10
1
1
0.1
1
10
100
0.01
0.1
1
10
100
Reverse Voltage (V)
t, Heating Time (sec.)
