LPD10 SERIES
Single, dual and triple output
•
•
•
•
•
•
4:1 wide input voltage range
16 models available including 3.3V outputs
Input reflected ripple according to CEPT
Continuous short circuit protection
EN55022 conducted emissions level B
Designed to meet EN60950 and IEC950
The LPD10 series of DC/DC converters offer 10 Watts output power in a 2 x 2
inch package. 3.3V single outputs are available along with standard single, dual
and triple outputs. All models feature short circuit protection as standard. The
dual and triple output models of the LPD series provide undervoltage lockout.
The LPD10 series complies with the rigorous EN55022 level B conducted
emissions. The optimized thermal design and the copper case allow operation
in ambient temperatures up to +70°C without derating or an additional heatsink.
[ 2 YEAR WARRANTY ]
SPECIFICATION
OUTPUT SPECIFICATIONS
Line regulation
Load regulation
All specifications are typical at nominal input, full load at 25°C unless otherwise stated
EMC CHARACTERISTICS
±0.1%
±1.0%
±0.1%
±3.0%
4.0% max.
5.0% max.
±2.0%
±3.0%
Conducted noise
Radiated noise
EN55022, FCC part 15
EN55022, FCC part 15
Level B
Level B
LL to HL, singles and duals
LL to HL, triple output
Singles and duals:
10% to 100% FL
Triples: 10% to 100% FL
Duals: asymmetrical load
10% to 100% FL
Triples: asymmetrical load
10% to 100% FL
Singles
Duals
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Isolation resistance
Isolation capacitance
Input/output
Input/output
Input/output
Fixed
Safety
See table
500VDC
10
8
Ω
1nF
180 to 220kHz
VDE0805, EN60950, IEC950
UL1950, CSA C22.2 No. 950
Black coated, metal case
UL94V-0
65g (2.29oz)
MIL-HDBK-217F
300,000 hours
Cross regulation
(See Note 1)
Voltage accuracy
Minimum load
Switching frequency
Approvals and
standards (pending)
Case material
Material flammability
Weight
MTBF
3.3V, 5V
50mA max.
Single 12V, 15V
20mA max.
Duals & triples, each output
10% FL
At start-up
20MHz bandwidth
3.0% max.
1.0% pk-pk, max.
20mV rms
±0.02%/°C
Hiccup mode
Continuous
automatic recovery
Overshoot
Ripple and noise
Temperature coefficient
Short circuit protection
(See Note 2)
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
Operating ambient
-10°C to +70°C
(See derating curve)
Non-operating amb.
-25°C to +95°C
Case
+95°C max.
Derating
See derating curve
Cooling
Free air convection cooled
Non-condensing
Operating
Non operating
5Hz to 500Hz
30% to 95%
10,000 feet max.
40,000 feet max.
2.5G rms (approx.)
INPUT SPECIFICATIONS
Input voltage range
Input current
Undervoltage lockout
24VDC nominal, FL
48VDC nominal, FL
10 to 36VDC
20 to 72VDC
See table
Dual and triple outputs
24V nominal
9.5VDC max.
48V nominal
18.5VDC max.
200ms
Relative humidity
Altitude
Vibration
Start-up time
Data Sheet © Artesyn Technologies® 2000
The information and specifications contained in this data sheet are believed to be correct at
time of publication. However, Artesyn Technologies accepts no responsibility for consequences
arising from printing errors or inaccuracies. Specifications are subject to change without notice.
No rights under any patent accompany the sale of any such product(s) or information contained
herein.
PAGE 108
DC/DC CONVERTERS
|
10W DC/DC
10 Watt
Wide input DC/DC converters
INPUT
VOLTAGE
10-36VDC
10-36VDC
10-36VDC
10-36VDC
10-36VDC
10-36VDC
10-36VDC
10-36VDC
20-72VDC
20-72VDC
20-72VDC
20-72VDC
20-72VDC
20-72VDC
20-72VDC
20-72VDC
OUTPUT
VOLTAGE
3.3V
5.0V
12V
15V
±12V
±15V
5V/±12V
5V/±15V
3.3V
5.0V
12V
15V
±12V
±15V
5V/±12V
5V/±15V
OUTPUT
CURRENT
2000mA
2000mA
800mA
660mA
±400mA
±300mA
1000mA/±200mA
1000mA/±160mA
2000mA
2000mA
800mA
660mA
±400mA
±300mA
1000mA/±200mA
1000mA/±160mA
INPUT
CURRENT
381mA
540mA
512mA
512mA
512mA
512mA
510mA
510mA
190mA
267mA
253mA
253mA
253mA
253mA
255mA
255mA
TYPICAL
EFFICIENCY
72%
77%
78%
78%
78%
78%
80%
80%
72%
78%
79%
79%
79%
79%
80%
80%
REGULATION (TYP.)
MODEL NUMBER
LINE
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±1.0%
±1.0%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±1.0%
±1.0%
LOAD
±0.2%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±3.0%
±3.0%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±3.0%
±3.0%
LPD10-24S3V3-C
LPD10-24S05-C
LPD10-24S12-C
LPD10-24S15-C
LPD10-24D12-C
LPD10-24D15-C
LPD10-24T05-12
LPD10-24T05-15
LPD10-48S3V3-C
LPD10-48S05-C
LPD10-48S12-C
LPD10-48S15-C
LPD10-48D12-C
LPD10-48D15-C
LPD10-48T05-12
LPD10-48T05-15
Notes
1
Cross regulation:
Duals: output 1, full load, 4.0%; output 2, minimum load, 4.0%.
Triples: output 1, full load, 2.0%; output 2 vs. output 3, 2.0%;
Triples: outputs 2 and 3 vs. output 1, 5.0%.
All 3V3 outputs, 1 minute max.
DERATING CURVE
Output Power (Watts)
2
10W
Output Power
(Watts)
70°C
5
95°C
0W
-10°C 0°C 20°C 40°C
60°C 80°C 100°C
Ambient Temperature (°C)
Pinout (Single, Dual)
0.24
(6.00)
0.42
(10.70)
0.90
(22.85)
2.00
(50.80)
0.20
(5.10)
0.90
(22.85)
0.24
(6.00)
0.50
(12.70)
0.10
(2.54)
Pinout (Triple)
2.0
(50.80)
0.90
(22.85)
0.20
(5.10)
0.90
(22.85)
-
0.60
(15.25)
Ø 0.04 Dia.
(1.00)
+
Input
-
Ø 0.04 Dia.
(1.00)
2.00
(50.80)
0.80
(20.30)
Input
+
2.00
(50.80)
1.80
(45.72)
BOTTOM VIEW
BOTTOM VIEW
-
COM/N.C.
+
Output
-
0.10
(2.54)
0.60
(15.25)
COM 5V
Output
0.60
(15.25)
0.80
(20.30)
0.60
(15.25)
0.39
(10.10)
+
0.40
(10.20)
0.40
(10.20)
0.40
(10.20)
0.39
(10.10)
DS_LPD10_20000101.PDF
ALL DIMENSIONS IN INCHES (mm)
Tolerance
:
±0.008
(0.2) max. on pin placement
±0.02
(0.5) max. on outer dimensions
ALL DIMENSIONS IN INCHES (mm)
Tolerance
:
±0.008
(0.2) max. on pin placement
±0.02
(0.5) max. on outer dimensions
http://www.artesyn.com
PAGE 109
