Suppression Chokes
www.schurter.com/pg8_82
Compensated High Inductance Choke, 1-phase
DKLP-
Description
- Current compensated choke
- 1-phase choke
- Flexible wire
- Flange for mounting onto printed circuit board
- Fully potted resign
Applications
- Placed in front of frequency converter
- Stepper motor drives
- UPS-systems
- Inverter
Standards
References
Weblinks
General Product Information
Approvals, RoHS, CHINA-RoHS, e-Store, Distributor-Stock-Check
- EN 60938
- IEC 60950
- EN 55011/55014
- VDE 0871/0875
Technical Data
Rated voltage
Rated voltage
Rated Current
Rated inductance
Power Operating Frequency
Terminal technic
Weight
Material: Housing
Sealing Compound
up to 540 VAC
up to 760 VDC
4 - 20 A @ Ta 40 °C
14 - 60 mH, Tol. -30% +50%
50 - 400 Hz
Flexible wire
145 - 512 g
UL 94V-0
UL 94V-0
Test Voltage
Isolation Voltage
Climatic Category
Allowable Operation Temp.
2.5 kV, 50 Hz, 2 sec, winding to winding
2.5 kV eff., 50 Hz, 2 sec, winding to
ambient
25/100/21 acc. to IEC 60068-1
-25 °C to 100 °C
Dimensions
Case 29-2W
Case 31-2W
48
38.2
5.8
30.8
150
10...20
80
65
6.8
50.8
230
10...20
38.2
48
80
65
3.1
4.3
EMC Products
DKLP-
www.schurter.com/pg8_82
Case 33-2W
Suppression Chokes
120
100
8
70
230
10...20
120
100
5.25
Variants
I
n
[A]
4
6
4
5
7
20
L
n
[mH]
30
14
60
40
20
12
R
cu
[mΩ]
96
46
250
126
62
19
Tripped Power Dissi-
pation [W]
3
3.3
8
6.3
6
15.2
f
RES
[MHz]
0.2
0.3
0.1
0.048
0.18
0.16
Copper ø
[mm]
0.8
1
0.71
0.9
1.12
1.8
Weight [g]
145
145
477
505
512
180
Housing
29-2W
29-2W
31-2W
31-2W
31-2W
33-2W
Packing unit [pcs.]
6
6
2
2
2
1
Order Number
DKLP-0229-0430
DKLP-0229-0614
DKLP-0231-0460
DKLP-0231-0540
DKLP-0231-0720
DKLP-0233-2012
2
The specifications, descriptions and illustrations indicated in this document are based on
EMC Products
current information. All content is subject to modifications and amendments.
