LINE INTERFACE TRANSFORMER
Designed for use with AT&T T7264
Turns Ratio 1:1.5
PARAMETER
*Primary Inductance (Line Side)
(Pins 5 + 7 short 6 + 8)
**Primary Leakage Inductance
(Pins 5 + 7 short 6 + 8 & 1 +2)
**Interwinding Capacitance
Primary DC Resistance
Secondary DC Resistance
Isolation (Hi-Pot)
DC Bias
Longitudinal Balance
70
1000
50
MIN.
72
MAX.
88
UNITS
mHy
µHy
300
Flammability: Materials used in
the production of these units
meet requirements of UL94-VO
and IEC 695-2-2 needle flame
test.
200
5.6
13
pF
ohms
ohms
V
RMS
mA
dB
SCHEMATIC DIAGRAM
SEC
PR I
*Tested at 10kHz 100Mv
**Tested at 100kHz 100Mv
PHYSICAL DIMENSIONS
All dimensions in inches (mm):
TOP VIEW
2
RM-8 Package
1
8
7
5 6
RHOMBUS INDUSTRIES INC.
FSCM NO. 16714
RHOMBUS P/N:
T-13206
CUST P/N:
NAME:
DATE:
6/10/94
SHEET:
1 OF 1
Rhombus
Industries Inc.
Transformers & Magnetic Products
15801 Chemical Lane, Huntington Beach, CA 92649
Phone: (714) 898-0960
FAX: (714) 896-0971
www.rhombus-ind.com
