DB105-BP-HF

Description
Bridge Rectifier Diode, 1A, 600V V(RRM),
CategoryDiscrete semiconductor    diode
File Size407KB,3 Pages
ManufacturerMicro Commercial Components (MCC)
Environmental Compliance
Download Datasheet Parametric Compare View All

DB105-BP-HF Overview

Bridge Rectifier Diode, 1A, 600V V(RRM),

DB105-BP-HF Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerMicro Commercial Components (MCC)
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresUL RECOGNIZED
Minimum breakdown voltage600 V
ConfigurationBRIDGE, 4 ELEMENTS
Diode component materialsSILICON
Diode typeBRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)1.1 V
JESD-30 codeR-PDIP-T4
Humidity sensitivity level1
Maximum non-repetitive peak forward current30 A
Number of components4
Phase1
Number of terminals4
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current1 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)260
Maximum repetitive peak reverse voltage600 V
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationDUAL
Maximum time at peak reflow temperature10
MC C
Micro Commercial Components
TM
  omponents
20736 Marilla
Street Chatsworth

  !"#
$ %    !"#
DB101
THRU
DB107
1 Amp Single Phase
Glass Passivated
Bridge Rectifier
50 to 1000 Volts
DB-1
Notch
Features
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
4-PIN DIP
Package
Glass Passivated Diode Construction
UL Recognized File # E165989
High Surge Current Capability
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
Operating Junction Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
Thermal Resistance : Rthja: 40C/W;RthJL:15C/W.
MCC
Catalog
Number
Device
Marking
Maximum
Recurrent
Peak Reverse
Voltage
50V
100V
200V
400V
600V
800V
1000V
Maximum
RMS
Voltage
Maximum
DC
Blocking
Voltage
50V
100V
200V
400V
600V
800V
1000V
Maximum Ratings
B
-
~
A
+
C
~
DB101
DB102
DB103
DB104
DB105
DB106
DB107
DB101
DB102
DB103
DB104
DB105
DB106
DB107
35V
70V
140V
280V
420V
560V
700V
E
F
G
D
H
Electrical Characteristics @ 25 Unless Otherwise Specified
°C
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
I
F(AV)
1A
T
A
= 40°C
DIMENSIONS
I
FSM
30A
8.3ms, half sine
DIM
A
B
C
D
E
F
G
H
MIN
.316
.245
.300
.236
.102
INCHES
MM
V
F
1.1V
I
FM
= 1.0A;
T
J
= 25°C
MAX
.335
.255
.350
.299
.130
.060
.022
.205
MIN
8.05
6.20
7.60
6.01
2.60
1.50
.41
5.00
MAX
8.51
6.50
8.90
7.60
3.30
.56
5.20
NOTE
I
R
10µA
0.5mA
T
J
= 25°C
T
J
= 125°C
.016
.195
Typ
Typ
C
J
25pF
Measured at
1.0MHz, V
R
=4.0V
Notes:1.High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision:
C
www.mccsemi.com
1 of 3
2014/03/05
