Low Pass Filter
75Ω
DC to 15 MHz
-55°C to 100°C
-55°C to 100°C
0.5W max.
Plug-In
PLP-15-75+
PLP-15-75
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power Input
Features
• rugged welded case, hermetic
• other standard and custom PLP models available with
wide selection of fco
Permanent damage may occur if any of these limits are exceeded.
CASE STYLE: A01
PRICE: $15.20 ea. QTY (1-9)
Pin Connections
INPUT
OUTPUT
GROUND
CASE GROUND
1
8
2,3,4,5,6,7
2,3,4,5,6,7
Applications
•
•
•
•
test equipment
lab use
transmitters/receivers
military/hi-rel applications
PASSBAND
(MHz)
(loss < 1 dB)
DC-15
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Low Pass Filter Electrical Specifications
fco (MHz)
Nom.
(loss 3 dB)
17
Outline Drawing
STOPBAND
(MHz)
(loss > 20 dB)
23-32
(loss > 40 dB)
32-200
Passband
Typ.
1.7
VSWR
(:1)
Stopband
Typ.
18
typical frequency response
40 dB
AT T E NUAT ION, dB
electrical schematic
R F IN
R F OUT
20 dB
3 dB
1 dB
DC
0.9
1
1.35
1.75
3
F R E QUE NC Y / F co
Typical Performance Data
Outline Dimensions (
inch
)
mm
A
B
.770
.800
19.56 20.32
G
H
.200
.20
5.08
5.08
C
D
.385
.400
9.78 10.16
J
K
.14
.031
3.56
0.79
E
F
.370
.400
9.40 10.16
wt
grams
5.2
Frequency
(MHz)
1.00
3.00
5.00
7.00
9.00
11.00
13.00
15.00
17.00
19.00
19.80
20.60
21.40
22.20
23.00
23.80
25.40
27.10
28.70
30.40
32.00
33.60
54.40
75.20
96.00
116.80
137.60
158.40
179.20
200.00
40
RETURN LOSS (dB)
32
24
16
8
0
at RF level of 0 dBm
Insertion Loss
(dB)
_
x
σ
0.03
0.06
0.09
0.14
0.22
0.25
0.34
0.50
2.82
11.43
15.30
18.94
22.33
25.47
28.41
31.15
36.18
41.00
45.10
48.98
52.36
55.41
74.86
73.58
74.15
73.97
73.54
73.80
74.50
73.86
RETURN LOSS
Return Loss
(dB)
35.82
31.00
34.16
22.80
19.40
22.11
19.32
18.45
6.89
0.98
0.56
0.38
0.29
0.24
0.21
0.19
0.16
0.15
0.13
0.12
0.11
0.10
0.08
0.11
0.14
0.17
0.20
0.22
0.24
0.28
150
GROUP DELAY (nsec)
120
90
60
30
0
0.0
Frequency
(MHz)
1.00
1.13
1.26
1.42
1.59
1.78
1.99
2.25
2.52
2.85
3.19
3.61
4.04
4.57
5.12
5.78
6.48
7.32
8.20
9.26
10.38
11.72
13.14
15.00
17.00
18.79
21.05
23.00
26.65
30.00
at RF level of 0 dBm
Group Delay
(nsec)
52.11
52.17
50.65
50.65
50.11
51.43
51.32
51.21
50.76
51.26
50.32
51.52
51.58
52.49
53.16
53.42
54.00
54.67
56.16
57.17
60.22
65.05
71.10
89.63
116.22
75.17
35.03
23.17
13.67
8.48
100
INSERTION LOSS (dB)
80
60
40
20
0
at RF level of 0 dBm
INSERTION LOSS
0.00
1.00
0.01
0.01
0.04
0.03
0.04
0.06
0.33
0.90
1.06
1.18
1.26
1.33
1.37
1.41
1.48
1.55
1.68
1.74
1.61
1.61
1.20
2.20
0.86
1.20
1.19
1.67
3.05
4.45
GROUP DELAY
1
10
100
1000
FREQUENCY(MHz)
1
10
100
1000
FREQUENCY(MHz)
6.0
12.0
18.0
FREQUENCY (MHz)
24.0
30.0
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
REV. A
M98898
PLP-15-75
071031
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
