Silicon NPN Power Transistor
BDY43
DESCRIPTION
·Collector-Emitter
Breakdown Voltage-
: V
(BR)CEO
= 300V(Min.)
·DC
Current Gain-
: h
FE
=20(Min.)@I
C
= 1A
·Collector-Emitter
Saturation Voltage-
: V
CE(sat
)= 1.5V(Max)@ I
C
= 5A
·High
Switching Speed
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Voltage
regulator
·Inverter
·Switching
mode power supply
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CES
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current
Collector Power Dissipation@T
C
=25℃
Junction Temperature
Storage Temperature
VALUE
600
600
300
7
5
10
3
60
175
-65~175
UNIT
V
V
V
V
A
A
A
W
℃
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
V
CE
(sat)
V
BE
(sat)
I
CBO
h
FE-1
h
FE-2
f
T
PARAMETER
Collector-Emitter Breakdown Voltage
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
DC Current Gain
DC Current Gain
Current Gain-Bandwidth Product
CONDITIONS
I
C
= 30mA; I
B
= 0
I
C
= 1mA; I
E
= 0
I
E
= 1mA; I
C
= 0
I
C
= 5A; I
B
= 1.5A
I
C
= 5A; I
B
= 1.5A
V
CB
= 600V; I
E
= 0
V
CB
= 600V; I
E
= 0, T
C
=150℃
I
C
= 1A; V
CE
= 2V
I
C
= 5A; V
CE
= 2V
I
C
= 0.5A; V
CE
= 10V
20
5
10
MIN
300
600
7
BDY43
MAX
UNIT
V
V
V
1.5
2.0
0.2
2.0
V
V
mA
MHz
Switching times
t
on
t
f
t
off
Turn-on Time
Fall Time
Turn-off Time
I
C
= 2.5A; I
B1
= -I
B2
= 0.5A
0.5
1.0
4.0
μs
μs
μs
