AMPSS
®
MICRO REGULATOR
The AA05B DC-DC converter series
is part of Astec's family of advanced
modular power supply components.
Featuring high reliability and small
size, these modules are designed to
reduce product development time and
enhance system performance. The
AA05B offer single and dual outputs
in a compact package. These units
are ideally suited for tele-
communications, industrial, computer
and distributed power system
applications having a widely varying
input voltage.
AA05B Series
6W max
4.5V or 24V or 48V inputs
Single / Dual output
Special Features
•
•
•
•
•
•
•
•
•
6 watts
Singles and duals
110 KHz frequency (typical)
Isolated output
Surface mount internal
construction
Six-sided shielding
Wide 4:1 input range
Small size 2.0" x 1.0 "x 0.40"
5 year warranty
Electrical Specifications
Input
Input Range
4.5 to 5.5VDC
9 to 36 VDC
20 to 72 VDC
80-85% typical
<100 mA p-p
Notes
20% minimum load required.
All specifications are typical at nominal
input and full load unless otherwise noted.
Specifications subject to change without
notice.
Mechanical drawings for reference only.
Efficiency
Input Ripple
Current
Output
Voltage Tolerance
(factory set-point)
Line Regulation
Load Regulation
±1% max
1%
5% (20% to full
load)
5Vdc output
3% (20% to full
load) all others
50mV p-p, under
specified conditions
Zener clamp
Power cycling,
auto- recovery
1500 VDC
Environmental
Operating
Temperature
(ambient)
Storage
Temperature
Cooling
Method
-25°C to +71°C
(no derating)
-25°C to +105°C
Convection
Noise/Ripple
Output Voltage
Protection
Short Circuit
Isolation
Input to Output
5
5
