Power Transistors
2SA0885
(2SA885)
Silicon PNP epitaxial planar type
Unit: mm
For low-frequency power amplification
Complementary to 2SC1846
■
Features
•
Output of 3 W can be obtained by a complementary pair with
2SC1846
•
TO-126B package which requires no insulation plate for installa-
tion to the heat sink
8.0
+0.5
–0.1
φ
3.16
±0.1
3.8
±0.3
11.0
±0.5
3.2
±0.2
1.9
±0.1
■
Absolute Maximum Ratings
T
a
=
25°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector current
Peak collector current
Collector power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
j
T
stg
Rating
−45
−35
−5
−1
−1.5
1.2
5.0
*
0.75
±0.1
Unit
4.6
±0.2
0.5
±0.1
0.5
±0.1
2.3
±0.2
3
1.76
±0.1
V
V
V
A
A
W
°C
°C
1
2
150
−55
to
+150
Note) *: With a 100
×
100
×
2 mm Al heat sink
■
Electrical Characteristics
T
a
=
25°C
±
3°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Collector-base cutoff current (Emitter open)
Collector-emitter cutoff current (Base open)
Emitter-base cutoff current (Collector open)
Forward current transfer ratio
Symbol
V
CBO
V
CEO
I
CBO
I
CEO
I
EBO
h
FE1 *
h
FE2
Collector-emitter saturation voltage
Transition frequency
Collector output capacitance
(Common base, input open circuited)
2. *: Rank classification
Rank
h
FE1
Q
85 to 170
R
120 to 240
S
170 to 340
Note) The part number in the parenthesis shows conventional part number.
Publication date: February 2003
SJD00002BED
Conditions
I
C
=
−10 µA,
I
E
= 0
I
C
=
−2
mA, I
B
= 0
V
CB
= −20
V, I
E
=
0
V
CE
= −20
V, I
B
=
0
V
EB
= −5
V, I
C
=
0
V
CE
= −10
V, I
C
= −500
mA
V
CE
= −5
V, I
C
= −1
A
I
C
= −500
mA, I
B
= −50
mA
V
CE
= −10
V, I
E
=
50 mA, f
=
200 MHz
V
CB
=
−10
V, I
E
= 0, f = 1 MHz
Min
−45
−35
Typ
16.0
±1.0
1: Emitter
2: Collector
3: Base
TO-126B-A1 Package
Max
−
0.1
−100
−10
85
50
−
0.5
200
20
30
340
V
CE(sat)
f
T
C
ob
MHz
pF
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
3.05
±0.1
Unit
V
V
µA
µA
µA
V
1
2SA0885
P
C
T
a
6
I
C
V
CE
−1.50
–1.2
I
C
I
B
T
C
=25˚C
I
B
=–10mA
–1.0
V
CE
=–10V
T
C
=25˚C
Collector power dissipation P
C
(W)
5
(1)With a 100
×
100
×
2 mm
Al heat sink
(2)Without heat sink
−1.25
Collector current I
C
(A)
4
(1)
3
−1.00
Collector current I
C
(A)
–9mA
–8mA
–7mA
–6mA
–5mA
–4mA
–3mA
–2mA
–1mA
–0.8
−0.75
–0.6
2
(2)
−0.50
–0.4
1
−0.25
–0.2
0
0
40
80
120
160
200
0
0
−2
−4
−6
−8
−10
0
0
–2
–4
–6
–8
–10
–12
Ambient temperature T
a
(°C)
Collector-emitter voltage V
CE
(V)
Base current I
B
(mA)
V
CE(sat)
I
C
Collector-emitter saturation voltage V
CE(sat)
(V)
–10
V
BE(sat)
I
C
–10
h
FE
I
C
I
C
/I
B
=10
Base-emitter saturation voltage V
BE(sat)
(V)
I
C
/I
B
=10
1 000
T
C
=100˚C
V
CE
=–10V
25˚C
–1
–1
T
C
=–25˚C
100˚C
25˚C
Forward current transfer ratio h
FE
100
–25˚C
T
C
=100˚C
25˚C
–0.1
–25˚C
–0.1
10
–0.01
–0.01
–0.1
–1
–0.01
–0.01
–0.1
–1
1
–0.01
–0.1
–1
Collector current I
C
(A)
Collector current I
C
(A)
Collector current I
C
(A)
f
T
I
E
V
CB
=–10V
f=200MHz
T
C
=25˚C
C
ob
V
CB
Collector output capacitance
C (pF)
(Common base, input open circuited)
ob
50
I
E
=0
f=1MHz
T
C
=25˚C
V
CER
R
BE
–100
I
C
=–10mA
T
C
=25˚C
200
Collector-emitter voltage
(V)
V
(Resistor between B and E)
CER
Transition frequency f
T
(MHz)
160
40
–80
120
30
–60
80
20
–40
40
10
–20
0
1
10
100
0
–1
–10
–100
0
0.1
1
10
100
Emitter current I
E
(mA)
Collector-base voltage V
CB
(V)
Base-emitter resistance R
BE
(kΩ)
2
SJD00002BED
