2026-6010-10: Description500MHz - 18000MHz RF/MICROWAVE DIRECTIONAL COUPLER, 1.44dB INSERTION LOSS-MAX; CategoryWireless rf/communication Radio frequency and microwave; File Size109KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

2026-6010-10 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	2026-6010-10	-	-	View	Buy Now

2026-6010-10 Overview

500MHz - 18000MHz RF/MICROWAVE DIRECTIONAL COUPLER, 1.44dB INSERTION LOSS-MAX

2026-6010-10 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	1439760290
Reach Compliance Code	unknown
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum input power (CW)	46.99 dBm
Maximum insertion loss	1.44 dB
Maximum operating frequency	18000 MHz
Minimum operating frequency	500 MHz
Maximum operating temperature	125 °C
Minimum operating temperature	-54 °C
RF/Microwave Device Types	DIRECTIONAL COUPLER
Maximum voltage standing wave ratio	1.5
