series M50 Diode
60-100Amp • Diode Modules
Single- and three-phase diode circuits incorporate highly
efficient thermal management to provide high surge
capability, extended life, and reliable performance. Available
in five circuits, all models come in an industry standard
package, provide 2500 Vrms from all terminals to the
baseplate, and are UL recognized E72445.
#
High Surge Current Rectifier Circuits
#
Up to 1600 Volt Blocking Standard
Mechanical Dimensions
All dimensions are in inches (millimeters)
1 .62 5
(4 1. 2 )
.8 1 5
(2 0.7 )
.87 5
(22 .2 )
1 .0 7 0
(2 7 .2 )
.5 3 5
(1 3.6 )
1.75 0
(44 .4 )
Electrical Specifications
I
D
V
F
T
J
di/dt
Maximum DC Output Current @ Tc = 85˚C (A)
Maximum Voltage Drop @ Amps Peak
Operating Junction Temperature Range
M5060
60
1.35V @60A
M50100
100
1.2V @ 100A
-40˚C to +125˚C
100
500
400 (120Vac)
600 (240Vac)
800 (280Vac)
1000 (380Vac)
1200 (480Vac)
1400 (530Vac)
1600 (600Vac)
800
2650
0.45˚C/W
1500
9350
0.3˚C/W
Critical Rate of Rise of On-State
Current @ TJ=125˚C (A/µs)
dv/dt Critical Rate of Rise of Off-State Voltage
1 .88 0
(4 7.8 )
MOU N T IN G
HOLE /SLO T
0.20 (5 .1) .
DIA
V
RMS
Repetitive Peak Reverse Voltage
(AC Line Input Voltage)
1 0 -32 S CRE W
5 P L CS .
.9 5 1.14 0
(24 .1 ) (28 .9 )
2 .26 5
(5 7.5 )
I
TSM
SB
AC
AC
+
AC
AC
CC
--
+
I
2
T
AC
AC
Maximum Non-Repetitive
Surge Current (A) [ 1/2Cycle, 60Hz]
Maximum I2T for Fusing (A2sec) [t=8.3ms]
Maximum Thermal Resistance Junction to
Ceramic Base per Chip
Isolation Voltage
+
+
R
OJC
V
ISOL
+
--
AC
AC
2500 V
RMS
Mechanical Specifications
TB
AC
AC
AC
+
AC
AC
AC
THC
AC
AC
AC
AC
Weight (Typical)
4.5 oz. (158g)
+
AC
+
AC
--
--
+
Part Number Indentification
Series
M50
Current
60 - 60 Amps
100 - 100 Amps
Circuit Type
(see schematic
diagrams)
Example: SB
Voltage
400 (120 Vac)
600 (240Vac)
1000 (380Vac)
1200 (480Vac)
1400 (530Vac)
1600 (600Vac)
DD
+
AC
AC
--
+
Example: M50100TB1200
--
ISO
9001
C E R T I F I E D
Competitive part number cross-reference available at:
www.cynergy3.com
ASIA - Thailand
Telephone
+66 (0)2 665 2517
Fax
+66 (0)2 665 2588
Cynergy 3 Components, Asia
18/8 Fico Place 12th Floor
Soi Sukhumvit 21 (Asoke)
Klongtoey Nua, Wattana
Bangkok, Thailand 10110
Approvals
UL - E72445
USA
Sales & Tech Support
(866) 258-5057
Email:
sales@cynergy3.com
Cynergy3 Components
2320 Paseo de las Americas, Suite 104
San Diego, CA 92154
EUROPE - UK
Telephone
+44 (0) 1202 897969
Fax
+44 (0) 1202 891918
Email:
sales@cynergy3.com
Cynergy3 Components Ltd.
7 Cobham Road
Ferndown Industrial Estate
Wimborne, Dorset BH21 7PE
© 2006 Cynergy3 components, All Rights Reserved. Specifications are subject to change without prior notice. Cynergy3 components and the Cynergy3 components logo are trademarks of Cynergy3 components Corp.
