PC Board Mountable Power Supplies
DESCRIPTION
CALEX produces the highest quality, most dependable power
supplies in the industry. These rugged units are reliable, cost
effective power sources for use with a wide variety of
operational amplifiers, function modules, and data conversion
circuits. All units employ industry standard pin configurations
for system upgrading by replacement of or substitution for
supplies from other manufacturers.
All CALEX power supplies feature a 5 Year Warranty and are
characterized by tight regulation, low noise, and outstanding
stability. The short circuit protection features “foldback”
current limiting, so all units can be shorted indefinitely without
damage.
COMMON SPECIFICATIONS
Input Voltage
100 ±10 VAC (add “-100” to model number)
115 ±10 VAC (add “-115” to model number)
220 ±20 VAC (add “-220” to model number)
230 ±20 VAC (add “-230” to model number)
240 ±20 VAC (add “-240” to model number)
SELECTION CHART
Output
Voltage
VDC
Single Output
5
5
5*
5
5*
9
10
12
12*
12
15
15
18
24
Dual Output
±5
±12
±12
±12*
±12
±15
±15
±15*
±15 **
±15
Triple Output
±12 &
5
±15 &
5
±12 &
5
±15 &
5
Output
Current
mA
500
1000
1000
2000
2000
1000
750
480
480
750
400
600
500
375
±750
±120
±240
±240
±360
±100
±200
±200
±200
±350
±100
600
±100
500
±125
1000
±100
1000
Voltage
Accuracy
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±0.5%
±1.0%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±1.0%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±1.0%
±1.0%
±1.0%
±1.0%
Line & Load
Regulation
Maximum
±0.10%
±0.10%
±0.10%
±0.20%
±0.20%
±0.10%
±0.10%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.10%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.04%
±0.10%***
±0.10%
±0.20%
±0.20%
Noise & Ripple
mV RMS
1
1
1
2
2
2
1
2
2
2
2
2
2
2
1
1
1
1
2
1
1
1
1
2
2
2
2
2
Case Size
Unit Weight
(oz.)
11.2
17.5
17.5
22.2
22.2
22.2
22.2
17.5
17.5
22.2
17.5
22.2
22.2
22.2
22.2
11.2
17.5
17.5
22.2
11.2
17.5
17.5
17.5
22.2
17.5
17.5
22.2
22.2
Model
Number
1.5.500
1.5.1000
1.5.1000-DV
1.5.2000
1.5.2000-DV
1.9.1000
1.10.750
1.12.480
1.12.480-DV
1.12.750
1.15.400
1.15.600
1.18.500
1.24.375
2.5.750
2.12.120
2.12.240
2.12.240-DV
2.12.360
2.15.100
2.15.200
2.15.200-DV
7010
2.15.350
3.12.5
3.15.5
3.12.1000
3.15.1000
B1
B2
B2
B3
B3
B3
B3
B2
B2
B3
B2
B3
B3
B3
B3
B1
B2
B2
B3
B1
B2
B2
B2
B3
B2
B2
B3
B3
A
*Dual AC Input 115/230 VAC
**Recognized to UL 544 (Available in 115 VAC only).
***The +5V output load regulation in the 3.12.5-100 and 3.12.5-115 models is 0.20%
2401 Stanwell Drive • Concord, California 94520 • Ph: 925/687-4411 or 800/542-3355 • Fax: 925/687-3333 • www.calex.com • Email: sales@calex.com
1
3/2001
PC Board Mountable Power Supplies
Specifications
All parameters measured at 25 C, nominal input voltage and full rated
load unless otherwise noted.
MAXIMUM OUTPUT POWER (%)
AC/DC POWER SUPPLY DERATING
120
All Models
Input Frequency Range
Short Circuit Protection
Isolation
Isolation Resistance
Isolation Voltage *
Input to Output
Capacitance *
Environmental
Case Operating Range
No Derating
Storage Range
Temperature Coefficient
C a se
Mounting Kits
MIN
MIN
TYP
50
1200 - 1500
50 - 250
TYP
TYP
50 to 60
Unit
Hz
Foldback Current Limiting
megohm
VRMS
pF
100
80
60
40
SAFE OPERATING
AREA
20
0
MIN
MAX
MIN
MAX
TYP
-25
+50
-25
+85
±0.01
B 1, B 2, & B 3
-30
-20
-10
0
10
20
30
40
50
60
70
80
°C
CASE TEMPERATURE (Deg C)
°C
%/°C
B1, B2, B3 case
MK215-022 & MK215-08BDV
* Contact CALEX for information on exact model, call
(800) 542-3355 or (925) 687-4411
Specifications subject to change without notice.
Single 5 Volt output models have output overvoltage protection
which operates between 5.8V and 6.85 Volts. Power must be
removed to reset the clamp.
Power Supply Mounting Kit Options
Two types of mounting kits are available for convenient
installation of CALEX power supplies. The MK215-022 consists
of a PC card with a 22-pin connector for use in racks. The
alternative, our MK215-08BDV, employs a barrier strip type
connector for chassis mount applications. Two screws hold
the power supply firmly in place on the PC card without need
of soldering.
MK215-022
Bottom View
“A” models have 2" spacing between AC pins. (e.g. 2.15.200A)
Side View
Pin
9
5
7
5
8
6
1 or 1A
4 or 4A
Jumper 2 & 3
Jumper 1 to 3
DV Units - 115 V
& 2 to 4
Mechanical tolerances unless otherwise noted:
X.XX dimensions: 0.020 inches
X.XXX dimensions: 0.005 inches
Pin Assignments
Function
+Output Voltage
-Output Voltage
Common
On Single Output
Common is also connected to Pin 5
On Triple Units 5 V Output
On Triple Units 5 V Common
(Isolated from ± Common)
AC Input 100, 115, 220, 230, 240 VAC
AC Input and DC Units
DV Units - 230 V
A
Case to Mounting Kit Connections
Case Pin
1, 1A
2
3
4, 4A
5
6
7
8
9
MK215-022
X
-
-
Z
K
H
E
C
A
MK215-08BDV
2
-
-
1
6
5
7
4
8
MK215-08BDV
Pins not referenced are not inserted in the case.
2401 Stanwell Drive • Concord, California 94520 • Ph: 925/687-4411 or 800/542-3355 • Fax: 925/687-3333 • www.calex.com • Email: sales@calex.com
2
3/2001
PCB Design
