CM2.15.50-100 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> CM2.15.50-100

CM2.15.50-100: DescriptionAC-DC Regulated Power Supply Module, 2 Output, Hybrid; CategoryPower/power management The power supply circuit; File Size105KB，2 Pages; ManufacturerCalex Mfg Co Inc.

Download Datasheet Parametric View All

CM2.15.50-100 Overview

AC-DC Regulated Power Supply Module, 2 Output, Hybrid

CM2.15.50-100 Parametric

Parameter Name	Attribute value
Reach Compliance Code	compli
ECCN code	EAR99
Other features	-15V ADDITIONAL OUTPUT AVAILABLE
Analog Integrated Circuits - Other Types	AC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	110 V
Minimum input voltage	90 V
Nominal input voltage	100 V
JESD-30 code	R-XUFM-X5
Maximum load regulation	0.04%
Number of functions	1
Output times	2
Number of terminals	5
Maximum operating temperature	50 °C
Minimum operating temperature	-25 °C
Maximum output voltage	15.075 V
Minimum output voltage	14.925 V
Nominal output voltage	15 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	UNSPECIFIED
Terminal location	UPPER
Fine-tuning/adjustable output	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Chassis Mountable Power Supplies

Features

Description

The unique CALEX “CM” design creates the most flexible and

well-engineered power supply package on the market today.

These chassis mountable supplies are ideal for use with

dedicated microprocessor systems, instrument design and

test equipment. The CM units can also be used as

supplemental bench or laboratory power supplies.

The special “clamp” type barrier strip secures the wire without

twisting. Note the protected, recessed, barrier strip facing the

top of the case. This allows all connections to be made in tight

quarters while protecting the barrier strip from physical

damage.

Nothing else offers this combination of ruggedness, flexibility

and convenience. All CALEX chassis mount power supplies

are guaranteed to provide at least 5 years of reliable service.

Models CM1.5.500 and CM1.5.1000 have output voltage

protection which operates between 5.8 and 6.85 Volts. Power

must be removed to reset the overvoltage clamp.

Unique “Clamp” Type Barrier Strip

Four Molded-In Threaded Inserts

Four Through Holes for Easy Mounting

Covered Under CALEX 5 Year Warranty

Common Specifications

Input Voltage

100 ±10 VAC (add “-100” to model number)

115 ±10 VAC (add “-115” to model number)

220 ±20 VAC (add “-220” to model number)

230 ±20 VAC (add “-230” to model number)

240 ±20 VAC (add “-240” to model number)

Selection Chart

Output

Voltage

VD C

Single Output

250

Dual Output

Triple Output

12 &

15 &

100

500

1.0%

0.10%

18.2

CM3.12.5

CM3.15.5

120

240

100

200

0.5%

0.04%

17.5

CM2.12.120

CM2.12.240

CM2.15.50

CM2.15.100

CM2.15.200

1000

400

500

400

240

1.0%

0.5%

3.0%

0.10%

0.04%

2.0%

Output

Current

Voltage

Accuracy

Line & Load

Regulation

Maximum

Noise & Ripple

mV RMS

Case Siz e

Unit Weight

(oz .)

Model

Number

2401 Stanwell Drive

Concord, CA 94520-4841

(510) 687-4411 • Fax (510) 687-3333

http://www.calex.com

CALEX

FaxFACTS:

203

STCO #970624

1997

17.5

CM1.5.1000

CM1.10.400

CM1.12.500

CM1.15.400

CM1.24.240

CM1.250.30
