2SD756E datasheet, PDF - EEWORLD Datasheet

2SD756E: DescriptionSmall Signal Bipolar Transistor, 0.05A I(C), NPN, TO-92MOD, 3 PIN; CategoryDiscrete semiconductor The transistor; File Size29KB，6 Pages; ManufacturerHitachi （Renesas ）; Websitehttp://www.renesas.com/eng/

Download Datasheet Parametric View All

2SD756E Overview

Small Signal Bipolar Transistor, 0.05A I(C), NPN, TO-92MOD, 3 PIN

Parameter Name	Attribute value
Parts packaging code	TO-92
package instruction	CYLINDRICAL, O-PBCY-T3
Contacts	3
Reach Compliance Code	unknow
Maximum collector current (IC)	0.05 A
Configuration	Single
Minimum DC current gain (hFE)	400
JESD-30 code	O-PBCY-T3
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Polarity/channel type	NPN
Maximum power dissipation(Abs)	0.75 W
Certification status	Not Qualified
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Nominal transition frequency (fT)	350 MHz
Base Number Matches	1

2SD755, 2SD756, 2SD756A

Silicon NPN Epitaxial

Application

•

Low frequency high voltage amplifier

•

Complementary pair with 2SB715, 2SB716 and 2SB716A

Outline

TO-92MOD

1. Emitter

2. Collector

3. Base
