Ordering number : ENN*7954
Monolithic Linear IC
LA72670M
Overview
Hi-Fi Signal Processing
HiFi Processing with Built-in Audio
Multiplex Decoder for US Market Products
The LA72670M is a system IC that adds SIF and US standard multi channel television sound (MTS) signal decoding
functions to the Hi-Fi audio signal-processing functions of earlier devices. All adjustments have been implemented in the
IC chip by either automatic adjustment, trimming, or some other technique, making this device is fully adjustment free.
Features
•
Hi-Fi audio signal record and playback processing.
•
Head amplifier for Hi-Fi Audio signal.
•
SIF demodulation.
•
US standards compliant audio multiplex decoder.
Package Dimensions
unit : mm
3255
Any and all SANYO Semiconductor products described or contained herein do not have specifications
that can handle applications that require extremely high levels of reliability, such as life-support systems,
aircraft's control systems, or other applications whose failure can be reasonably expected to result in
serious physical and/or material damage. Consult with your SANYO Semiconductor representative
nearest you before usingany SANYO Semiconductor products described or contained herein in such
applications.
SANYO Semiconductor assumes no responsibility for equipment failures that result from using products
at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition
ranges, or other parameters) listed in products specifications of any and all SANYO Semiconductor
products described or contained herein.
71504 JO IM No.7954-1/2
LA72670M
Block Diagram
