LA76936Y datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> Consumption circuit> LA76936Y

LA76936Y: DescriptionConsumer Circuit, PDIP64, 0.600 INCH, DIP-64; CategoryOther integrated circuit (IC) Consumption circuit; File Size512KB，6 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric Compare View All

LA76936Y Overview

Consumer Circuit, PDIP64, 0.600 INCH, DIP-64

LA76936Y Parametric

Parameter Name	Attribute value
Maker	SANYO
Parts packaging code	DIP
package instruction	SDIP, SDIP64,.6
Contacts	64
Reach Compliance Code	unknown
Commercial integrated circuit types	CONSUMER CIRCUIT
JESD-30 code	R-PDIP-T64
length	57.2 mm
Number of functions	1
Number of terminals	64
Maximum operating temperature	65 °C
Minimum operating temperature	-10 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Encapsulate equivalent code	SDIP64,.6
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
power supply	5 V
Certification status	Not Qualified
Maximum seat height	5.1 mm
Maximum slew rate	35 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
surface mount	NO
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	1.778 mm
Terminal location	DUAL
width	15.24 mm

Preview

Download Datasheet

View All

Ordering number : ENA1102B

Monolithic Linear IC

LA7693X

Series

Overview

For NTSC/PAL/SECAM Color TVs

Built-in CTV Microcontroller

Video and Sound Processing ICs

(VIF/SIF/Y/C/Deflection/CbCr IN)

The LA7693X series is a single-chip video and sound processor IC with a built-in microcontroller that supports all of the

different worldwide broadcasting systems. The IC provides fully integrated solution to rationalize the design of color TV

sets, increase productivity, and reduce total costs.

Functions

•

C bus control system with a built-in microcontroller

•

VIF/SIF/Y/C/Deflection/CbCr IN

•

Adjustment-free VIF/SIF

•

1X’tal multi-system that supports all broadcasting systems

•

No VCO coil required

•

Internal sound carrier BPF, 4-system sound carrier trap

•

Digital AFT system

•

Supports EW (LA76933J, LA76938Y)

•

Supports SECAM (LA76936Y, LA76938Y)

Line-up

Type name

LA76931J

LA76933J

LA76936Y

LA76938Y

NTSC

PAL

SECAM

Deflection

CbCr input

E/W

Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to

"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,

communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be

intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace

instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety

equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case

of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee

thereof. If you should intend to use our products for applications outside the standard applications of our

customer who is considering such use and/or outside the scope of our intended standard applications, please

consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our

customer shall be solely responsible for the use.

Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate

the performance, characteristics, and functions of the described products in the independent state, and are not

guarantees of the performance, characteristics, and functions of the described products as mounted in the

customer

s products or equipment. To verify symptoms and states that cannot be evaluated in an independent

device, the customer should always evaluate and test devices mounted in the customer

s products or

equipment.

40109 MS / 30409 MS / 31908 MS PC 20070703-S00008 No.A1102-1/6

LA76936Y Related Products

	LA76936Y	LA76938Y	LA76931J	LA76933J
Description	Consumer Circuit, PDIP64, 0.600 INCH, DIP-64	Consumer Circuit, PDIP64, 0.600 INCH, DIP-64	Consumer Circuit, PDIP64, 0.600 INCH, DIP-64	Consumer Circuit, PDIP64, 0.600 INCH, DIP-64
Parts packaging code	DIP	DIP	DIP	DIP
package instruction	SDIP, SDIP64,.6	SDIP, SDIP64,.6	SDIP, SDIP64,.6	SDIP, SDIP64,.6
Contacts	64	64	64	64
Reach Compliance Code	unknown	unknown	unknown	unknown
Commercial integrated circuit types	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT
JESD-30 code	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64
length	57.2 mm	57.2 mm	57.2 mm	57.2 mm
Number of functions	1	1	1	1
Number of terminals	64	64	64	64
Maximum operating temperature	65 °C	65 °C	65 °C	65 °C
Minimum operating temperature	-10 °C	-10 °C	-10 °C	-10 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SDIP	SDIP	SDIP	SDIP
Encapsulate equivalent code	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH
power supply	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	5.1 mm	5.1 mm	5.1 mm	5.1 mm
Maximum slew rate	35 mA	35 mA	35 mA	35 mA
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V
surface mount	NO	NO	NO	NO
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	1.778 mm	1.778 mm	1.778 mm	1.778 mm
Terminal location	DUAL	DUAL	DUAL	DUAL
width	15.24 mm	15.24 mm	15.24 mm	15.24 mm
Maker	SANYO	-	SANYO	SANYO
