mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
ATW
05
Additional Centerline
ATW 05
ATW 06
Voltage
4.3 mm raised base
without wire
protection
ATW
06
Voltage
10
30
10 - 22
4.4
7.3
4.3 mm raised base
with wire protection
Electrical Data
600 V
centerline
8
Current (A)
20
Wire range (AWG)
12 - 22
Screw torque (lbs.-in)
3.5
Wire strip length (mm)
5.3
Electrical Data
600 V
centerline
8
Current (A)
20
Wire range (AWG)
12 - 22
Screw torque (lbs.-in)
3.5
Wire strip length (mm)
5.3
10
30
10 - 22
4.4
7.3
Mechanical Data
Housing
UL 94V-2
Working Temperature 105 °C
Color
natural
Terminal
brass metal alloy, tin plated
centerline
8
10
Screw
M2.6
M3
zinc plated, yellow chromed
Pole sizes
1 to 12
Mechanical Data
Housing
UL 94V-2
Working Temperature 105 °C
Color
natural
Terminal
brass metal alloy, tin plated
centerline
8
10
Screw
M2.6
M3
zinc plated, yellow chromed
Wire protector
stainless spring steel
Pole sizes
1 to 12
Dimensions (mm)
Dimensions (mm)
centerline
A
96.0
117.0
B
16.3
20.2
C
16.9
20.1
D
8.0
10.0
E
2.9
3.6
F
2.8±0.1
3.2±0.1
centerline
A
96.0
117.0
B
16.3
20.2
C
16.9
20.1
D
8.0
10.0
E
2.9
3.6
F
2.8±0.1
3.2±0.1
G
8
10
8
10
Part Numbers
ATW05
centerline 8 mm
Complete the part number
by adding the pole size.
Part Numbers
ATW06
centerline 8 mm
Complete the part number
by adding the pole size.
Part No.
ATW05 D
ATW05
centerline 10 mm
09
01 02 03 04 05 06 07 08
09 10 11 12
01 02 03 04 05 06 07 08
09 10 11 12
Part No.
ATW06 D
ATW06
centerline 10 mm
09
01 02 03 04 05 06 07 08
09 10 11 12
01 02 03 04 05 06 07 08
09 10 11 12
Part No.
ATW05 9
09
Part No.
ATW06 9
09
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
G-4
Subject to technical changes and printing errors.
