LV762102F datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> Consumption circuit> LV762102F

LV762102F: DescriptionSPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64; CategoryOther integrated circuit (IC) Consumption circuit; File Size88KB，6 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn

Download Datasheet Parametric Compare View All

LV762102F Overview

SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64

LV762102F Parametric

Parameter Name	Attribute value
Maker	ON Semiconductor
package instruction	DIP, SDIP64,.6
Reach Compliance Code	compliant
Commercial integrated circuit types	CONSUMER CIRCUIT
JESD-30 code	R-PDIP-T64
length	57.2 mm
Number of functions	1
Number of terminals	64
Maximum operating temperature	65 °C
Minimum operating temperature	-10 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	SDIP64,.6
Package shape	RECTANGULAR
Package form	IN-LINE
power supply	5 V
Certification status	Not Qualified
Maximum seat height	5.1 mm
Maximum slew rate	26.5 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
surface mount	NO
technology	BICMOS
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	1.78 mm
Terminal location	DUAL
width	15.24 mm

Preview

Download Datasheet

View All

Ordering number : ENA1447A

LV762XXX Series

Bi-CMOS IC

Video and Sound Processing ICs

Built-in CTV Microcontroller

for NTSC/PAL/SECAM Color TVs

(VIF/SIF/Y/C/Deflection/CbCr IN)

Overview

http://onsemi.com

The LV762XXX series is a single-chip video and sound processor IC with a built-in microcontroller that supports all of

the NTSC, PAL and SECAM broadcasting systems. The IC provides fully integrated solution to rationalize the design

of color TV sets, increase productivity, and reduce total costs.

Functions

•

C bus control system with a built-in microcontroller

•

VIF/SIF/Y/C/Deflection/CbCr IN

•

Adjustment-free VIF/SIF

•

1X’tal multi-system that supports NTSC, PAL and SECAM broadcasting systems

•

No VCO coil required

•

Internal sound carrier BPF, 4-system sound carrier trap

•

Digital AFT system

Semiconductor Components Industries, LLC, 2013

July, 2013

52009 MS No.A1447-1/6

LV762102F Related Products

	LV762102F	TMM-129-05-S-S-SM-TR	LV762113C	LV762113F	LV762233C	LV762233F	LV762102C	LV762232F	LV762232C	LV76233N5F
Description	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	Board Connector, 29 Contact(s), 1 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Black Insulator,	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64	SPECIALTY CONSUMER CIRCUIT, PDIP64, 0.600 INCH, DIP-64
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
Maximum operating temperature	65 °C	125 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C
Minimum operating temperature	-10 °C	-55 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C
Terminal pitch	1.78 mm	2 mm	1.78 mm	1.78 mm	1.78 mm	1.78 mm	1.78 mm	1.78 mm	1.78 mm	1.78 mm
Maker	ON Semiconductor	-	-	-	ON Semiconductor	ON Semiconductor	ON Semiconductor	ON Semiconductor	ON Semiconductor	ON Semiconductor
package instruction	DIP, SDIP64,.6	-	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6	DIP, SDIP64,.6
Commercial integrated circuit types	CONSUMER CIRCUIT	-	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT	CONSUMER CIRCUIT
JESD-30 code	R-PDIP-T64	-	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64	R-PDIP-T64
length	57.2 mm	-	57.2 mm	57.2 mm	57.2 mm	57.2 mm	57.2 mm	57.2 mm	57.2 mm	57.2 mm
Number of functions	1	-	1	1	1	1	1	1	1	1
Number of terminals	64	-	64	64	64	64	64	64	64	64
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	-	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	SDIP64,.6	-	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6	SDIP64,.6
Package shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	-	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
power supply	5 V	-	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	5.1 mm	-	5.1 mm	5.1 mm	5.1 mm	5.1 mm	5.1 mm	5.1 mm	5.1 mm	5.1 mm
Maximum slew rate	26.5 mA	-	26.5 mA	26.5 mA	26.5 mA	26.5 mA	26.5 mA	26.5 mA	26.5 mA	26.5 mA
Maximum supply voltage (Vsup)	5.5 V	-	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	-	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
surface mount	NO	-	NO	NO	NO	NO	NO	NO	NO	NO
technology	BICMOS	-	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS
Temperature level	COMMERCIAL	-	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	-	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal location	DUAL	-	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	15.24 mm	-	15.24 mm	15.24 mm	15.24 mm	15.24 mm	15.24 mm	15.24 mm	15.24 mm	15.24 mm
