105 °C
Central mounting
SH
Features
•
•
•
•
•
•
•
RoHS compliant
REACH compliant
Different case sizes, voltages and
capacitance combinations
are available on request.
Also in small lots.
All contacts welded
Central mounting
Soldering lug terminals
High reliability
HiFi
Signalization
Industrial
Applications
General specifications
Items
Rated capacitance range C
R
Capacitance tolerance
Rated voltage range U
R
Surge voltage U
S
Max. reverse voltage
Ctegory temperature range S, SZ
Leakage current I
L
after 5 min @ U
R
Useful life
3000 h @ 105 °C ; U
R
; I
R~
Characteristics
22 … 22.000 µF
-10; +30 %
16 … 450 V
U
R
≤ 315 V: U
S
= 1,15 U
R
U
R
> 315 V: U
S
= 1,10 U
R
2V
- 40°C ... + 105°C
≤ 0,008 * C
R
[µF] * U
R
[V] + 6 µA [µA]
Requirements
Δ C/C ≤ 30 % of initial value
ESR ≤ 300 % of specified limit
I
L
≤ specified limit
Requirements
Δ C/C ≤ 20
% of initial value
ESR ≤ 130 % of specified limit
I
L
≤ specified limit
40/105/56
≥ 2500 V AC
IEC 60384-4
Endurance test
2000 h @ 105 °C , U
R
Climatic category IEC 60068
Voltage proof of the external insulation
Sectional specification
Leclanché Capacitors
1400 Yverdon, Switzerland
Tel. +41 24 445 66 88
Fax +41 24 445 66 89
www.Lcap.ch
capinfo@Lcap.ch
101
105 °C
Drawings for series SH
SH
Electrical data and ordering code for series SH
Rated
voltage
U
R
[V]
Rated
cap.
C
R
[µF]
Case
size
DxL
[mm]
Typ.
ESR
100
Hz,
20°C
[mΩ]
30
20
32
30
27
17
50
45
40
23
113
93
63
37
21
233
167
140
tan
δ
100Hz
20°C
max.
[%]
Ripple
current
IR~
100
Hz,
105°C
[A]
1,9
2,8
1,7
1,7
2,2
3,0
1,3
1,4
1,6
2,6
0,9
1,0
1,2
1,9
3,1
0,6
0,7
0,8
Order code
SH...
Rated
voltage
U
R
[V]
Rated
cap.
C
R
[µF]
Case
size
DxL
[mm]
Typ.
ESR
100
Hz,
20°C
[mΩ]
107
60
500
400
200
93
493
347
167
1267
1000
387
187
1600
1200
1000
547
213
tan
δ
100Hz
20°C
max.
[%]
Ripple
current
IR~
100
Hz,
105°C
[A]
1,0
1,6
0,7
0,8
1,4
2,5
0,7
1,0
1,7
0,5
0,5
0,9
1,8
0,4
0,5
0,5
0,8
1,5
Order code
SH...
16
25
40
10000
22000
2200
4700
10000
22000
1000
2200
4700
10000
470
1000
2200
4700
10000
220
470
560
30 x 40
35 x 54
25 x 40
25 x 40
30 x 54
35 x 54
25 x 40
25 x 40
30 x 40
35 x 54
25 x 40
25 x 40
25 x 40
30 x 54
35 x 70
25 x 40
25 x 40
25 x 40
30
36
15
18
22
30
11
12
14
20
10
10
12
13
14
8
9
10
10301630040
22301635054
22202525040
47202525040
10302530054
22302535054
10204025040
22204025040
47204030040
10304035054
47106325040
10206325040
22206325040
47206330054
10306335070
22110025040
47110025040
56110025040
100
160
250
350
1000
2200
100
220
470
1000
100
220
470
47
100
220
470
22
33
47
100
220
25 x 54
35 x 54
25 x 40
25 x 40
30 x 54
35 x 70
25 x 40
25 x 54
35 x 54
25 x 40
25 x 40
25 x 54
35 x 70
25 x 40
25 x 40
25 x 40
30 x 54
35 x 54
10
12
8
9
9
10
7
8
8
7
7
7
8
8
8
8
8
8
10210025054
22210035054
10116025040
22116025040
47116030054
10216035070
10125025040
22125025054
47125035054
47035025040
10135025040
22135025054
47135035070
22045025040
33045025040
47045025040
10145030054
22145035054
63
100
450
