SAC5.0
THRU
SAC50
VOLTAGE - 5.0 TO 50 VOLTS
500 WATT PEAK POWER
DO-201AC / DO-15
Plastic package has Underwrites Laboratory
Fiammability Classification 94V-0
500W peak pulse power surge capability at 10/1000us
Excellent clamping capability
Low indremental surge resistance
High temperature soldering guaranteed :
260
/10 seconds/0.375"(9.5mm)
lead length/5lbs(2.3kg) tension
0.140(3.60)
0.104(2.60)
1.00(25.4)
MIN
0.300(7.60)
0.230(5.80)
0.034(0.90)
0.028(0.70)
1.00(25.4)
MIN
Case: Molded plastic
Terminals: Axial leads, Solderable per
MIL-STD-202, Method 208
Polarity: Color band denoted positive end
except Bidirectionals
Mounting Position: Any
Weight: 0.40 grams
Characteristic
Maximum surge reverse power
(Non-repetitive 10/ 1000us)
Maximum leakage current( V
R
=V
RM
)
Maximum reverse recovery time(IF/IR=0.1A/0.3A)
Maximum junction capacitance at 0 voltage
Operating and Storage temperature range
Symbol
P RSM
T.V.S
DIODE
Units
W
500
5.0
-
50
-55 to+150
-
5.0
500
I
R
T
rr
C
j
TJ, Tstg
RATINGS AND CHARACTERISTIC CURVES SAC5.0 THRU SAC50
Stand-off
Voltage
V
WM
Volts
SAC5.0
SAC6.0
SAC7.0
SAC8.0
SAC8.5
SAC10
SAC12
SAC15
SAC18
SAC22
SAC26
SAC30
SAC36
SAC45
SAC50
5.00
6.00
7.00
8.00
8.50
10.0
12.0
15.0
18.0
22.0
26.0
30.0
36.0
45.0
50.0
Breakdown
V
BR
Voltage
at I
T
Volts
7.60
7.90
8.33
8.89
9.44
11.10
13.30
16.70
20.00
24.40
28.90
33.30
40.00
50.00
55.50
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Maximun
Reverse
Leakage
at V
WM
I
R
A
300
300
300
100
50
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Maximmum
Clamping
Voltage
at I
PP
=5.0A
V
C
Volts
10.0
11.2
12.6
13.4
14.0
16.3
19.0
23.6
28.8
35.4
42.3
48.6
60.0
77.0
88.0
Maximun
Peak Pulse
Current
I
PPM
Amps
44
41
38
36
34
29
25
20
15
14
11.1
10.0
8.6
6.8
5.8
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Inverse
Blocking
Leakage
Current
at V
WIB
Working
Blocking
Leakage
Voltage
V
WIB
Volts
75
75
75
75
75
75
75
75
75
75
75
75
75
150
150
Peak
Inverse
Blocking
Voltage( V
PIB)
Volts
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Device
Type
Test
Current
I
T
NOTE1:The SAC series is a low capacitance silicon transient voltage suppressor for data or signal line. It is designed for commercial
and industrial applications. This series offers pricing,size,and capacitance advantages.This series employs a standard TVS in series
with a rectifier which reduces the effective capacitance up through 70MHz with a minimum amount of signal loss or deformation.
If bidirectional transient protection capabliity is required, is required,two low capacitance TVS must be used in parallel,opposite in
polarity for complete AC protection.
NOTE2:The SAC series of low capacitance silicon transient voltage suppressors,rate at 400 watts,provides board level protection for data
or signal lines form the damaging effects of electrostatic discharge(ESD),and electromagnetic pluse(EMP).It will clamp the inductive
overshoot voltage caused by very fast impulse rise times. The low capacitance assures minumum signal attenuation.
NOTE3:A TVS is normally selected according to the reverse"Stand Off Voltage"(V
R
)which should be equal to or greater than the DC or continuoues
peak operating voltage level.
NOTE: EQUIVALENT CIRCUIT
FIGURE.1-AC Line Protection Application
IN
Low
Capacitance
TVS
OUT
T.V.S
DIODE
APPLICATION NOTE : Devices must be used with two units in parallel,
opposite in polarity as shown in circuit for AC signal line protection
3
RATINGS AND CHARACTERISTIC CURVES SAC5.0 THRU SAC50
us
us
us
us
4
S
CURVE
S
COPPER HEAT SINKS
100
6 TYPICAL REVERSE LEAKAGE
CHARACTERISTICS
MEASURED AT DEVICES
STAND-OFF
VOLTAGE,V
WM
200
IR,INSTANTEOUS REVERS LEAKAGE CURRENT,
MICROAMPERES
T
j
=25
10
100
50
1.0
T
A
=25
0.1
0.01
0
100
200
300
400
500
10
V
(BR)
,BREAKDOWN VOLTAGE,VOLTS
3
