2x5mm RECTANGULAR LED LAMPS
L-233HDT-12.5 BRIGHT RED
L-233EDT-12.5 ORANGE
L-233GDT-12.5 GREEN
L-233YDT-12.5 YELLOW
L-233IDT-12.5 HIGH EFFICIENCY RED
L-233ADT-12.5 YELLOW
Features
!
LOW
Description
The Bright Red source color devices are made with
Gallium Phosphide Red Light Emitting Diode.
The High Efficiency Red and Orange source color devices
are made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
AND RUGGED.
UNIFORMITY OF LIGHT OUTPUT.
POWER CONSUMPTION.
RECTANGULAR LED LAMP WITH STOPPER.
FOR LEVEL INDICATOR.
!
RELIABLE
!
2x5MM
!
EXCELLENT
!
SUITABLE
!
LONG
LIFE - SOLID STATE RELIABILITY.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0287
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 1 OF 5
Selection Guide
Par t No .
Dic e
L en s Ty p e
Iv (m c d )
@ 10 m A
Min .
L-233HDT-12.5
L-233IDT-12.5
L-233EDT-12.5
L-233GDT-12.5
L-233YDT-12.5
L-233ADT-12.5
BRIGHT RED (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
ORANGE (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
YELLOW (GaAsP/GaP)
RED DIFFUSED
RED DIFFUSED
ORANGE DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
AMBER DIFFUSED
0.5
3
3
2
2
2
Ty p .
1
5
5
3
3
3
V i ew i n g
An g l e
2θ1/2
110°
110°
110°
110°
110°
110°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par am et er
D ev i c e
Bright Red
High Efficiency Red
Orange
Green
Yellow
Bright Red
High Efficiency Red
Orange
Green
Yellow
Ty p .
700
627
627
565
590
660
625
625
568
588
45
45
45
30
35
40
15
15
15
20
2.25
2.0
2.0
2.2
2.1
2.5
2.5
2.5
2.5
2.5
10
Max .
Un it s
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
IF=20mA
λ
D
Dominate Wavelength
nm
IF=20mA
∆λ
1/2
Bright Red
High Efficiency Red
Spectral Line Halfwidth Orange
Green
Yellow
Bright Red
High Efficiency Red
Orange
Green
Yellow
Bright Red
High Efficiency Red
Orange
Green
Yellow
All
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
V R = 5V
SPEC NO: KDA0287
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 2 OF 5
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
B r i g h t R ed
120
25
120
5
Hig h
E f f i c i en c y
R ed
105
30
160
5
Or an g e
105
30
160
5
Gr een
105
25
140
5
Yello w
105
30
140
5
Un it s
mW
mA
mA
V
-40
°
C To +85
°C
260
°
C For 5 Seconds
Bright Red L-233HDT-12.5
SPEC NO: KDA0287
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/15/2001
DRAWN: J.X.FU
PAGE: 3 OF 5
