Surface Mount
Toroidal RF Inductor
IN
DU
CT
AN
CE
TO
(µ
LE
H)
RA
NC
E
Q
M
IN
IM
U
M
TE
ST
FR
EQ
.(
SR
M
F
H
z)
M
IN
IM
D
U
C
M
(M
M RE
A S
H
XI IS
z)
M TA
U N
M C
C
(O E
U
R
hm
M RE
A N
s)
XI T
M R
U A
M T
(m IN
A G
)
NU
MB
ER
*
Series
3223R
3223
SERIES 3223
RF INDUCTORS
END
Electrical Schematic:
-00K
-02K
-04K
-06K
-08K
-10K
-12K
-14K
-16K
-18K
-20K
-22K
-24J
-26J
-28J
-30J
-32J
-34J
-36J
-38J
-40J
-42J
-44J
-46J
-48J
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±10%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
±5%
55
60
60
60
65
65
65
65
65
70
70
70
70
60
60
60
60
60
60
60
60
60
60
60
60
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
450
400
350
320
300
280
260
240
220
200
180
160
150
130
120
110
100
90
70
60
50
45
40
37
35
0.05
0.06
0.08
0.10
0.11
0.13
0.15
0.18
0.21
0.25
0.31
0.40
0.45
0.52
0.65
0.90
1.20
1.50
1.70
2.00
2.40
2.70
2.90
3.10
3.30
2200
2000
1800
1600
1500
1400
1300
1200
1100
1000
900
800
750
700
630
530
470
420
390
360
330
310
300
290
280
Optional Tolerances: J = 5%
H = 3%
*Complete part # must include series # PLUS the dash #
Military Specifications:
MS-21422 Ref.
Physical Parameters
Inches
A
0.320 ± 0.020
B
0.230 ± 0.010
C
0.155 ± 0.010
D
0.040 Min.
E
0.045 ± 0.008
F
0.240 (Ref Only)
G
0.125 (Ref Only)
H
0.100 ± 0.010
Millimeters
8.13 ± 0.508
5.84 ± 0.254
3.94 ± 0.254
1.016 Min.
1.143 ± 0.203
6.10 (Ref Only)
3.18 (Ref Only)
2.54 ± 0.254
For further surface finish information,
refer to TECHNICAL section of this catalog.
Current rating at 90ºC Ambient:
35ºC Rise
Operating Temperature Range:
-55ºC to +125ºC
Maximum Power Dissipation at 90ºC:
0.35 W
Core Material:
Powdered Iron
Weight Maximum:
0.50 grams
Packaging:
Tape & Reel (24mm): 13" reel
1000 pieces max.
4/2005
