RD70HHF1-101 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> RD70HHF1-101

RD70HHF1-101: DescriptionRF Power Field-Effect Transistor, 1-Element, High Frequency Band, Silicon, N-Channel, Metal-Oxide Semiconductor FET, ROHS COMPLIANT PACKAGE-2; CategoryDiscrete semiconductor The transistor; File Size262KB，8 Pages; ManufacturerMitsubishi; Websitehttp://www.mitsubishielectric.com/semiconductors/; Environmental Compliance

Download Datasheet Parametric View All

RD70HHF1-101 Overview

RF Power Field-Effect Transistor, 1-Element, High Frequency Band, Silicon, N-Channel, Metal-Oxide Semiconductor FET, ROHS COMPLIANT PACKAGE-2

RD70HHF1-101 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mitsubishi
package instruction	FLANGE MOUNT, R-CDFM-F2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	SOURCE
Configuration	SINGLE
Minimum drain-source breakdown voltage	50 V
Maximum drain current (Abs) (ID)	20 A
Maximum drain current (ID)	20 A
FET technology	METAL-OXIDE SEMICONDUCTOR
highest frequency band	HIGH FREQUENCY BAND
JESD-30 code	R-CDFM-F2
Number of components	1
Number of terminals	2
Operating mode	DEPLETION MODE
Maximum operating temperature	175 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	150 W
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	AMPLIFIER
Transistor component materials	SILICON

Preview

Download Datasheet

View All

Silicon RF Power Semiconductors

ELECTROSTATIC SENSITIVE DEVICE

OBSERVE HANDLING PRECAUTIONS

RD70HHF1

DRAWING

25.0+/-0.3

7.0+/-0.5 11.0+/-0.3

RoHS Compliance,

DESCRIPTION

Silicon MOSFET Power Transistor 30MHz,70W

OUTLINE

RD70HHF1 is a MOS FET type transistor specifically

designed for HF High power amplifiers applications.

4-C2

24.0+/-0.6

FEATURES

High power and High Gain:

Pout>70W, Gp>13dB @Vdd=12.5V,f=30MHz

High Efficiency: 60%typ.on HF Band

10.0+/-0.3

9.6+/-0.3

R1.6+/-0.15

0.1

-0.01

4.5+/-0.7

6.2+/-0.7

+0.05

APPLICATION

For output stage of high power amplifiers in HF

Band mobile radio sets.

5.0+/-0.3

18.5+/-0.3

RD70HHF1-101

is a RoHS compliant products.

RoHS compliance is indicate by the letter “G” after

the Lot Marking.

3.3+/-0.2

RoHS COMPLIANT

1.DRAIN

2.SOURCE

3.GATE

UNIT:mm

ABSOLUTE MAXIMUM RATINGS

(Tc=25

°C

UNLESS OTHERWISE NOTED)

SYMBOL

DSS

GSS

Pch

Tch

Tstg

Rth j-c

PARAMETER

Drain to source voltage

Gate to source voltage

Channel dissipation

Input power

Drain current

Channel Temperature

Storage temperature

Thermal resistance

CONDITIONS

Vgs=0V

Vds=0V

Tc=25

°C

Zg=Zl=50

Ω

junction to case

RATINGS

+/-20

150

175

-40 to +175

1.0

UNIT

°C

°C/W

Note 1: Above parameters are guaranteed independently.

ELECTRICAL CHARACTERISTICS

(Tc=25deg.C , UNLESS OTHERWISE NOTED)

SYMBOL

DSS

GSS

Pout

ηD

PARAMETER

Drain cutoff current

Gate cutoff current

Gate threshold voltage

Output power

Drain efficiency

Load VSWR tolerance

CONDITIONS

=17V, V

=0V

=10V, V

=0V

=12V, I

=1mA

f=30MHz ,V

=12.5V

Pin=3.5W,Idq=1.0A

=15.2V,Po=70W(Pin Control)

f=30MHz,Idq=1.0A,Zg=50

Ω

Load VSWR=20:1(All Phase)

LIMITS

MIN

TYP MAX.

1.5

4.5

No destroy

UNIT

Note : Above parameters , ratings , limits and conditions are subject to change.

RD70HHF1

17 Aug 2010

1/8
