Couplers
•
•
•
•
1 - 18.0 GHz - Ultrabroadband Performance
High Isolation
Excellent Phase and Amplitude Balance
Rugged Stripline Construction
Meets MIL-E-5400 and MIL-E-16400
3 dB 180
o
Hybrids - Magic T's
Midwest Microwave's series of high performance 180
o
Hybrid Couplers
(Magic T's) provide an important function in any system where power com-
bining or division is required. A signal applied at the sum
(Σ)
port will divide
into two equal amplitude, in phase signals at the output ports. Conversely, a
signal applied at the difference (∅) port will result in two equal amplitude but
180
o
out of phase signals at the output ports. In addition, if two coherent
signals are simultaneously applied at the output ports, the vectoral sum of
those two signals will appear at the sum
(Σ)
port and the vectoral difference
between the two signals will appear at the difference (∅) port.
ELECTRICAL SPECIFICATIONS
FREQUENCY
RANGE (GHZ)
CASE
STYLE
MODEL NUMBER
AMPLITUDE INSERTION
BALANCE
LOSS
(dB)
(dB) max
ISOLATION
(dB) min
VSWR
max
PHASE
BALANCE
2.0-12.4
1.0-12.4
1.0-18.0
2.0-18.0
2.0-8.0
1
3
2
2
3
HYB-5422-T3-SMA-79
HYB-5425-T3-SMA-79
HYB-5427-T3-SMA-79
HYB-5431-T3-SMA-79
HYB-5432-T3-SMA-79
±0.5
±0.7
±1.0
±1.5
±1.0
2.3
2.3
2.5
4.5
4.0
18
15
15
12
12
1.60
2.00
2.00
2.50
2.30
INCHES (mm)
E
F
(Deg)
± 10
± 10
± 15
—
—
Avg
(w)
POWER (In)
30
30
30
20
20
Peak
(w)
3
3
3
2
2
MECHANICAL SPECIFICATIONS
-
C ASE
STYLE
A
3.04 (77.2)
6.13 (155.6)
3.91(99.3)
B
0.093 (2.4)
2.06 (52.4)
1.96 (49.7)
C
N/A
2.00 (50.8)
N/A
D
1.35 (34.3)
2.50 (63.5)
2.50 (63.5)
2
3
1
WEIGH T
Oz
Gr
2.8
9.5
5.4
78
270
152
0.53 (13.5)
0.75 (19.1)
0.75 (19.1)
0.67 (17.0)
0.093 (2.4)
0.093 (2.4)
Note: TNC or Type N output connectors are available by substituting "TNC" or "NNN" for "SMA" in the Model Number.
