223891616641 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 223891616641

223891616641: DescriptionCAPACITOR, CERAMIC, MULTILAYER, 25V, X7R, 0.022uF, SURFACE MOUNT, 0603, CHIP, ROHS COMPLIANT; CategoryPassive components capacitor; File Size73KB，2 Pages; ManufacturerYAGEO; Websitehttp://www.yageo.com/; Environmental Compliance; Related ProductsFound19parts with similar functions to 223891616641

Download Datasheet Parametric Compare View All

223891616641 Overview

CAPACITOR, CERAMIC, MULTILAYER, 25V, X7R, 0.022uF, SURFACE MOUNT, 0603, CHIP, ROHS COMPLIANT

223891616641 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	, 0603
Reach Compliance Code	unknow
ECCN code	EAR99
capacitance	0.022 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
JESD-609 code	e3
Manufacturer's serial number	X7R
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR, PAPER, 7 INCH
positive tolerance	10%
Rated (DC) voltage (URdc)	25 V
size code	0603
surface mount	YES
Temperature characteristic code	X7R
Temperature Coefficient	15% ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrie
Terminal shape	WRAPAROUND
Base Number Matches	1

Preview

Download Datasheet

View All

print-friendly v ersion

Product Detail Information

Product Group

Ordering Code

Unified CTC

Additional Product Code

Description

Status

Multilayer Capacitor Chips and Arrays

CC0603KRX7R8BN223

223891616641

C0603KRX7R8BN223

06032R223K8B200

General purpose, 0603, X7R-NME, 22nF, 10%, 25V, 7" paper

Obsolete, the following alternative is proposed (click to view):

223891615641

Series

Size Code

Capacitance Tolerance

Packing Style

Dielectric Material (TC)

Rated Voltage

Capacitance

General Purpose

0603

+-10%

Paper Tape & 180mm (7") Reel

X7R

25V

22 nF

Related Data Sheets, Catalogs and Application Notes:

Datasheet - General purpose & High Cap MLCC, X7R 6.3V to 50V, Rev.2 [434 kb]

Datasheet - MLCC introduction, Rev.10 [275 kb]

Datasheet - MLCC general data of packing, labelling, mounting, tests & requirements; Rev.10 [415

kb]

Datasheet - MLCC quality flowchart, Rev.5 [119kb]

Yageo Passive Components 2009 [3.86 mb]

Product Selection Guide 2009 [1.74 MB]

Material declaration MLCCs type X7R, [85 kb]

Environmental declaration

Note - What is NME. [261 b]

Appl. note - DC, AC and Pulse load of Multilayer Ceramic Capacitors [308 kb]

MLCC sample kits [177 kb]

Appl. manual - MLCC application manual [577 kb]

Calculation tool - MLCC Spice Data

General info - Standard Values in a Decade [8.39 kb]

Requirements, Rev.7 [158 kb]

For optimal printing of Data sheets print from page 2 of the PDF.

Note Clear Text Codes in the data sheets can differ from the Clear Text Codes displayed above. The CTC

displayed above is a new code which has been introduced to align product codes in the complete Yageo

organisation. You can search products with the CTC displayed in the data sheet by using the competitor

part number search function.

Documents are in PDF format so to view and print them you will need

Adobe Acrobat Reader

installed on

your computer. This is available free of charge.

223891616641 Related Products

	223891616641	CC0603KRX7R8BN223
Description	CAPACITOR, CERAMIC, MULTILAYER, 25V, X7R, 0.022uF, SURFACE MOUNT, 0603, CHIP, ROHS COMPLIANT	CAPACITOR, CERAMIC, MULTILAYER, 25V, X7R, 0.022uF, SURFACE MOUNT, 0603, CHIP, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	, 0603	, 0603
Reach Compliance Code	unknow	unknown
ECCN code	EAR99	EAR99
capacitance	0.022 µF	0.022 µF
Capacitor type	CERAMIC CAPACITOR	CERAMIC CAPACITOR
dielectric materials	CERAMIC	CERAMIC
JESD-609 code	e3	e3
Manufacturer's serial number	X7R	X7R
Installation features	SURFACE MOUNT	SURFACE MOUNT
multi-layer	Yes	Yes
negative tolerance	10%	10%
Number of terminals	2	2
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
method of packing	TR, PAPER, 7 INCH	TR, PAPER, 7 INCH
positive tolerance	10%	10%
Rated (DC) voltage (URdc)	25 V	25 V
size code	0603	0603
surface mount	YES	YES
Temperature characteristic code	X7R	X7R
Temperature Coefficient	15% ppm/°C	15% ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrie	Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND	WRAPAROUND
