Dual Voltage Comparator
AVAILABLE AS MILITARY
SPECIFICATIONS
• M38510/10305B
• MIL-STD-883, 1.2.1
oltag
Dual Volta g e
Comparator
AS2111
PIN ASSIGNMENT
(Top View)
FEATURES
• Wide operating supply range: ±15V to a single +5V
• Low input current: 6 nA
• High sensitivity: 10µV
• Wide differential input range: ±30V
• High output drive: 50mA, 50V
16 Pin Ceramic DIP (C)
16 Pin Flatpack (F)
V+ -A
GND/EMITTER A
NON INVERTING INPUT A
INVERTING INPUT A
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
NC
COLLECTOR OUTPUT A
BALANCE/STROBE A
BALANCE -A
INVERTING INPUT B
NON INVERTING INPUT B
GND/EMITTER B
V+ -B
OPTIONS
• Packages
16 pin Ceramic DIP
16 pin Flatpack
• Temperature Ranges
Extended (-55
o
C to +125
o
C)
MIL-STD-883 paragraph 1.2.1
(-55
o
C to +125
o
C)
MARKINGS
C
F
V-
BALANCE B
BALANCE/STROBE -B
COLLECTOR OUTPUT B
XT
/883
GENERAL DESCRIPTION
The AS2111 dual voltage comparator is two AS111
type comparators in a single hermetic package.
CONNECTION DIAGRAM
Featuring all the same performance characteristics of the
single, these duals offer in addition closer thermal
tracking, lower weight, reduced insertion cost and smaller
size than two singles. For additional information, see
the AS111 data sheet.
The AS2111 is specified for operation over the
-55°C to +125°C military temperature range.
For more products and information
please visit our web site at
www.austinsemiconductor.com
AS2111
Rev. 1.0 6/03
Austin Semiconductor, Inc. reserves the right to change products or specifications without notice.
1
Austin Semiconductor, Inc.
ABSOLUTE MAXIMUM RATINGS*
Total Supply Voltage (V+ -- V-) .....................................................36V
Output to Negative Supply Voltage (V
OUT
--V-)..........................50V
Ground to Negative Supply Voltage (GND -- V-)........................30V
Differential Input Voltage.............................................................±30V
Input Voltage
1
................................................................................±15V
Power Dissipation
2
...................................................................500mW
Output Short Circuit Duration....................................................10sec
Operating Temperature Range.................................-55°C to +125°C
Storage Temperature Range........................................-65°C to 150°C
Lead Temperature (Soldering, 10sec).......................................300°C
oltag
Dual Volta g e
Comparator
AS2111
*Stresses greater than those listed under "Absolute Maximum
Ratings" may cause permanent damage to the device. This is
a stress rating only and functional operation of the device at
these or any other conditions above those indicated in the
operation section of this specification is not implied. Exposure
to absolute maximum rating conditions for extended periods
may affect reliability.
ELECTRICAL CHARACTERISTICS: Each Side
3
PARAMETER
Input Offset Voltage
Input Offset Current
Input Bias Current
Voltage Gain
Response Time
5
4
4
CONDITIONS
T
A
= 25°C, R
S
< 50k
T
A
= 25°C
T
A
= 25°C
T
A
= 25°C
T
A
= 25°C
V
IN
< -5mV, I
OUT
= 50mA, T
A
= 25°C
T
A
= 25°C
V
IN
> 5mV, I
OUT
= 35V, T
A
= 25°C
R
S
< 50k
TYP
MAX
3.0
10
100
UNITS
mV
nA
nA
V/mV
ns
200
200
1.5
3.0
10
4.0
20
150
±14
Saturation Voltage
Strobe On Current
Output Leakage Current
Input Offset Voltage
4
V
mA
nA
mV
nA
nA
V
V
mA
mA
Input Offset Current
Input Bias Current
Input Voltage Range
Saturation Voltage
4
V+ > 4.5V, V- = 0, V
IN
< -5mV, I
SINK
< 8mA
T
A
= 25°C
T
A
= 25°C
0.4
6.0
5.0
Positive Supply Current
Negative Supply Current
NOTES:
1. This rating applies for ±15V supplies. The positive input voltage limit is 30V above the negative supply. The negative input voltage limit is equal
to the negative supply voltage or 30V below the positive supply, whichever is less.
2. The maximum junction temperature is 150°C. For operating at elevated temperatures, devices in the flat package, the derating is based on a
thermal resistance of 185°C/W when mounted on a 1/16-inch-thick epoxy glass board with 0.03-inch-wide, 2 ounce copper conductor. The thermal
resistance of the dual-in-line package is 100°C/V, junction to ambient.
3. These specifications apply for V
S
= ±15V and -55°C < T
A
< 125°C, unless otherwise stated. The offset voltage, offset current and bias current
specifications apply for any supply voltage from a single 5V supply up to ±15V supplies.
4. The offset voltages and offset currents given are the maximum values required to drive the output within a volt of either supply with a 1mA load.
Thus, these parameters define an error band and take into account the worst case effects of voltage gain and input impedance.
5. The response time specified is for a 100mV input step with 5mV overdrive.
AS2111
Rev. 1.0 6/03
Austin Semiconductor, Inc. reserves the right to change products or specifications without notice.
2
