Type SF
Motor-Run and Power Supply Capacitors
Oil Filled/Impregnated, AC Rated, Metallized Polypropylene Capacitors
Type SF, AC rated metallized polypropylene capacitors pro-
vide starting torque and power factor correction for split
phase motors typically used in refrigeration and air condi-
tioning motor-run applications. Type SF also may be used
to provide noise suppression, voltage regulation and line
current reduction in power supply applications.
Highlights
♦
♦
♦
♦
♦
♦
Specifications
♦
Self healing
Fault Current Protection up to 10,000 amps AFC
Low energy consumption
4 - tine, 1/4" quick connect lug terminals are standard
Meets EIA Standard EIA-456-A
UL recognized File Number E71645
CSA File Number 223507
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Temperature Range:
Dissipation Factor:
5.0 µF to 120.0 µF
240 Vac to 660 Vac
±10% standard, ± 6% and ±3% available
–40 ºC to 70 ºC standard, 90 º C available
<0.1%
Service Life Objective
The service life objective for this series is 60,000 hours of
operating life with a 94% survival rate when operated at full
voltage, 60 Hz, and rated ambient temperature. AC
capacitors are frequently used at voltages and ambient
temperatures other than rated conditions. Service life may
be estimated under specific conditions of temperature and
voltage by using the curves as shown
below and
to the right.
Capacitance vs. Temperature
The Capacitance vs. Temperature curve may be used to
determine the capacitance change as a function of
temperature. capacitance varies by no more than ±3 % over
the operating temperature range.
Capacitance vs. Temperature
Capacitance Change %
4
2
0
–2
–4
–6
–40
–20
0
20
40
60
80 100
Life vs. Temperature
100000
10000
1000
100
10
0
25
50
75
100
125
% of Rated Life
Temperature °C
Life vs. Voltage
% of Rated Life
% of Rated Temperature
1.002
% of Rated Voltage
Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8564
•
Fax: (508)996-3830
•
www.cde.com
Type SF
Motor-Run and Power Supply Capacitors
Type SF - Oval Case Style
.81 ± .06
Ratings - Oval Case Style
Cap.
(µF)
2.0
2.0
3.0
3.0
4.0
4.0
5.0
5.0
6.0
6.0
7.5
7.5
10.0
12.5
15.0
17.5
20.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
50.0
2.0
2.0
3.0
3.0
4.0
4.0
5.0
6.0
7.5
10.0
12.5
12.5
15.0
15.0
17.5
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
Stock
Catalog
Case
Items
Part Number
Code
370 Vac 70 °C Case Temperature
S
SFA37S2K219B
A
*
SFA37S2K156B
A
S
SFA37S3K219B
A
*
SFA37S3K156B
A
S
SFA37S4K219B
A
*
SFA37S4K156B
A
S
SFA37S5K219B
A
*
SFA37S5K156B
A
S
SFA37S6K219B
A
*
SFA37S6K156B
A
S
SFA37S7.5K219B
A
*
SFA37S7.5K156B
A
S
SFA37S10K288B
A
S
SFA37S12.5K288B
A
S
SFA37S15K288B
A
S
SFC37S17.5K291B
C
S
SFC37S20K291B
C
*
SFA37S20K375B
A
S
SFC37S25K291B
C
S
SFC37S30K291B
C
S
SFC37S35K291B
C
S
SFC37S40K391B
C
S
SFC37S45K391B
C
S
SFC37S50K391B
C
S
SFD37S50K391B
D
440 Vac 70 °C Case Temperature
S
SFA44S2K203B
A
*
SFA44S2K156B
A
S
SFA44S3K209B
A
*
SFA44S3K156B
A
S
SFA44S4K209B
A
*
SFA44S4K156B
A
S
SFA44S5K219B
A
S
SFA44S6K288B
A
S
SFA44S7.5K288B
A
S
SFA44S10K375B
A
*
SFA44S12.5K375B
A
*
SFC44S12.5K291B
C
S
SFA44S15K375B
A
*
SFC44S15K291B
C
*
SFC44S17.5K291B
C
S
SFC44S20K391B
C
S
SFC44S25K391B
C
S
SFC44S30K391B
C
S
SFD44S35K391B
D
S
SFD44S40K391B
D
S
SFD44S45K391B
D
S
SFD44S50K391B
D
S
SFD44S55K391B
D
S
SFD44S60K391B
D
H
Inches
2.19
1.56
2.19
1.56
2.19
1.56
2.19
1.56
2.19
1.56
2.19
1.56
2.88
2.88
2.88
2.91
2.91
3.75
2.91
2.91
2.91
3.91
3.91
3.91
3.91
2.03
1.56
2.09
1.56
2.09
1.56
2.19
2.88
2.88
3.75
3.75
2.91
3.75
2.91
2.91
3.91
3.91
3.91
3.91
3.91
3.91
3.91
3.91
3.91
A ± .06
B ± .06
.50 Max
H + .12
- .06
Dim e ns ions (Inche s )
Cas e Code
A
C
D
A
1.31
1.91
1.97
B
2.16
2.91
3.66
H
see table
see table
see table
Ratings - Oval Case Style
Cap.
(µF)
4.0
5.0
6.0
7.5
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
60.0
70.0
Stock
Catalog
Case
H
Items
Part Number
Code (inches)
240 Vac Oval 70°C Case Temperature
*
SFA24S4K219B
A
2.19
*
SFA24S5K219B
A
2.19
*
SFA24S6K219B
A
2.19
*
SFA24S7.5K219B
A
2.19
*
SFA24S10K219B
A
2.19
*
SFA24S15K263B
A
2.63
*
SFA24S20K303B
A
3.03
*
SFC24S25K269B
C
2.69
*
SFC24S30K269B
C
2.69
*
SFC24S35K269B
C
2.69
*
SFC24S40K303B
C
3.03
*
SFC24S45K303B
C
3.03
*
SFC24S50K303B
C
3.03
*
SFC24S60K388B
C
3.88
*
SFC24S70K388B
C
3.88
Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8564
•
Fax: (508)996-3830
•
www.cde.com
1.003
Type SF
Motor-Run and Power Supply Capacitors
Ratings - Oval Case Style
Cap.
(µF)
1.0
1.0
2.0
2.0
3.0
4.0
5.0
6.0
8.0
8.0
10.0
10.0
12.0
15.0
18.0
20.0
25.0
30.0
35.0
40.0
Stock
Catalog
Case
Items
Part Number
Code
660 Vac 70 °C Case Temperature
S
SFA66S1K156B
A
*
SFA66S1K219B
A
S
SFA66S2K156B
A
*
SFA66S2K219B
A
S
SFA66S3K288B
A
S
SFA66S4K288B
A
S
SFA66S5K375B
A
S
SFA66S6K375B
A
S
SFA66S8K475B
A
*
SFC66S8K291B
C
S
SFA66S10K475B
A
S
SFC66S10K291B
C
S
SFC66S12K391B
C
S
SFC66S15K391B
C
S
SFC66S18K391B
C
S
SFD66S20K391B
D
S
SFD66S25K391B
D
S
SFD66S30K391B
D
S
SFD66S35K491B
D
S
SFD66S40K491B
D
H
Inches
1.56
2.19
1.56
2.19
2.88
2.88
3.75
3.75
4.75
2.91
4.75
2.91
3.91
3.91
3.91
3.91
3.91
3.91
4.91
4.91
Options
Tinplated steel cans are standard. Aluminum
cases are available upon request.
♦
Tighter capacitance tolerances such as ±3% o r
±6% are available.
♦
+90 °C ratings are available for HID lighting and
power supply applications.
♦
♦
♦
Discharge resistors are available.
Special terminal lugs such as 2 tines plus 1 fork
lugs are available.
Dual capacitance values are available for 370
Vac and 440 Vac applications.
♦
Hardware and Brackets:
See Capacitor Hardware, page
5.000
Part Numbering System
SF
Series
SF
C
A
= 1 1/4" Oval
B
= 1 1/2" Oval
C
= 1 3/4" Oval
D
= 2.0" Oval
P
= 1 3/4" Round
S
= 2.0" Round
T
= 2 1/2" Round
37
24
= 240 Vac
37
= 370 Vac
44
= 440 Vac
66
= 660 Vac
X
= Other
S
S
= Steel
35
7
= 7.0 µF
35
= 35.0 µF
K
L
= ±3%
291
Can Height
238
= 2.38"
291
= 2.91"
388
= 3.88"
475
= 4.75"
488
= 4.88"
B
A
= 2 way 70 °C
B
= 4 way 70 °C
C
= 2 way 90 °C
D
= 4 way 90 °C
E
= Dual 2,3,4 70 °C
F
= Forks 70 °C
G
= Forks 90 °C
H
= Forks 100 °C
J
= Forks, 70° Res.
K
= Forks, 90° Res.
L
= Forks, 100° Res.
Z
= Other
Case
AC Volt
Case Material
Cap
Tol. ±%
VAR
T
= Aluminum with
steel cover
A
= All Aluminum
H
= ±6%
K
= ±10%
1.004
Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8564
•
Fax: (508)996-3830
•
www.cde.com
Type SF
Motor-Run and Power Supply Capacitors
Type SF - Round Case Style
Cap
(µF)
.81 ± .06
D ± .06
0.5 Max.
H + .12
- .06
Case Code
Cas e Code
P
S
T
D (Inche s )
1.87
2.12
2.62
H
see table
see table
see table
2.0
3.0
4.0
5.0
6.0
7.5
10.0
12.5
15.0
17.5
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
90.0
100.0
Cap
(µF)
2.0
3.0
4.0
5.0
6.0
7.5
10.0
12.5
15.0
17.5
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
Hardware and Brackets:
See page
5.000
for details
Stock
Catalog
Case
Items
Part Number
Code
370 Vac 70°C Case Temperature
*
SFP37S2K238B
P
*
SFP37S3K238B
P
S
SFP37S4K238B
P
*
SFP37S5K238B
P
*
SFP37S6K238B
P
*
SFP37S7.5K238B
P
S
SFP37S10K238B
P
S
SFP37S12.5K238B
P
S
SFP37S15K238B
P
*
SFP37S17.5K238B
P
S
SFP37S20K238B
P
S
SFP37S25K288B
P
S
SFP37S30K288B
P
S
SFS37S35K288B
S
S
SFS37S40K288B
S
S
SFS37S45K375B
S
S
SFS37S50K375B
S
S
SFS37S55K375B
S
S
SFT37S60K303B
T
*
SFT37S65K303B
T
*
SFT37S70K303B
T
*
SFT37S75K391B
T
S
SFT37S80K391B
T
*
SFT37S90K391B
T
*
SFT37S100K391B
T
Stock
Catalog
Case
Items
Part Number
Code
440 Vac 70 °C Case Temperature
*
SFP44S2K238B
P
*
SFP44S3K238B
P
*
SFP44S4K238B
P
*
SFP44S5K238B
P
*
SFP44S6K238B
P
*
SFP44S7.5K238B
P
S
SFP44S10K238B
P
*
SFP44S12.5K238B
P
S
SFP44S15K288B
P
*
SFP44S17.5K288B
P
S
SFP44S20K288B
P
*
SFS44S25K288B
S
S
SFS44S30K288B
S
*
SFT44S35K303B
T
S
SFT44S40K391B
T
*
SFT44S45K391B
T
S
SFT44S50K391B
T
*
SFT44S55K391B
T
S
SFT44S60K475B
T
H
(Inches)
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.88
2.88
2.88
2.88
3.75
3.75
3.75
3.03
3.03
3.03
3.91
3.91
3.91
3.91
H
(Inches)
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.88
2.88
2.88
2.88
2.88
3.03
3.91
3.91
3.91
3.91
4.75
Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8564
•
Fax: (508)996-3830
•
www.cde.com
1.005
Type SF
Motor-Run and Power Supply Capacitors
Ratings - Round Case Style
Cap
(µF)
2.0
3.0
5.0
7.5
10.0
12.5
15.0
17.5
20.0
25.0
30.0
35.0
40.0
Stock
Catalog
Case
Items
Part Number
Code
660 Vac 70°C Case Temperature
*
SFP66S2K238B
P
*
SFP66S3K238B
P
*
SFP66S5K238B
P
*
SFP66S7.5K288B
P
*
SFP66S10K288B
P
*
SFS66S12.5K288B
S
*
SFS66S15K375B
S
*
SFT66S17.5K388B
T
*
SFT66S20K388B
T
*
SFT366S25K488B
T
*
SFT66S30K488B
T
*
SFT66S35K488B
T
*
SFT66S40K488B
T
Options
♦
Tinplated steel cans are standard. Aluminum
H
(Inches)
cases are available upon request.
2.38
2.38
2.38
2.88
2.88
2.88
3.75
3.88
3.88
4.88
4.88
4.88
4.88
Tighter capacitance tolerances such as ±3% or
±6% are available.
♦
+90 °C ratings are available for HID lighting and
power supply applications.
♦
♦
♦
Discharge resistors are available.
Special terminal lugs such as 2 tines plus 1 fork
lug are available.
Dual capacitance values are available for 370
Vac and 440 Vac applications.
♦
Hardware and Brackets:
See Capacitor Hardware, page
5.000
Part Numbering System
SF
Series
SF
C
A
= 1 1/4" Oval
B
= 1 1/2" Oval
C
= 1 3/4" Oval
D
= 2.0" Oval
P
= 1 3/4" Round
S
= 2.0" Round
T
= 2 1/2" Round
37
24
= 240 Vac
37
= 370 Vac
44
= 440 Vac
66
= 660 Vac
X
= Other
S
S
= Steel
35
7
= 7.0 µF
35
= 35.0 µF
K
L
= ±3%
291
Can Height
238
= 2.38"
291
= 2.91"
388
= 3.88"
475
= 4.75"
488
= 4.88"
B
A
= 2 way 70 °C
B
= 4 way 70 °C
C
= 2 way 90 °C
D
= 4 way 90 °C
E
= Dual 2,3,4 70 °C
F
= Forks 70 °C
G
= Forks 100 °C
H
= Forks 100 °C
J
= Forks, 70° Res.
K
= Forks, 90° Res.
L
= Forks, 100° Res.
Case
AC Volt
Case Material
Cap
Tol. ±%
VAR
T
= Aluminum with
steel cover
A
= All Aluminum
H
= ±6%
K
= ±10%
Z
= Special
1.006
Cornell Dubilier
•
1605 E. Rodney French Blvd.
•
New Bedford, MA 02744
•
Phone: (508)996-8564
•
Fax: (508)996-3830
•
www.cde.com
ARM Technology
京公网安备 11010802033920号
EEWORLD
