ADVANCED
®
INTERCONNECTIONS
®
Surface Mount
PLCC Sockets
5 Energy Way, P.O. Box 1019, West Warwick, RI 02893 USA Tel. 800-424-9850 / 401-823-5200 Fax 401-823-8723 Email advintcorp@aol.com Internet http://www.advintcorp.com
Surface Mount PLCC Sockets for SMD
Surface Mount Type
C
A
Features:
Low height above board .180"
(4.57mm).
Same PCB layout for the socket and
the IC chip.
Solder terminals visible for check
after soldering.
Available with Polarization pins for
orientation.
Diagonal slots for easy extraction of
the IC chip.
Sockets correspond to the JEDEC
norm.
Contacts:
Material: Phosphor Bronze
Plating: Tin over Nickel
Body Material:
Glass filled Polyphenylen sulfide (PPS)
self extinguishing as per U.L. 94V-O
Continuous Heat
-55
°
C to +125
°
C (-131
°
F to 257
°
F)
Solderheat Resistance
260
°
C (500
°
F) for 10 seconds
215
°
C (419
°
F) for 2 minutes
Without
Polarization Pin
With
Polarization Pin
.180
(4.57)
Optional Polarization Pins
.060
(1.52)
.060
(1.52)
.050
(1.27)Typ.
A
.150
(3.81)
D
.185
(4.70)
F
G
Contact Design
Part Numbers
PCB Layout Top View
# of
Pins
20
28
32
44
52
68
84
A
.200
(5.08)
.300
(7.62)
.300
(7.62)
.400
(10.16)
.500
(12.70)
.600
(15.24)
.800
(20.32)
1.000
(25.40)
C
.614
(15.60)
.717
(18.20)
.815
(20.70)
.717
(18.20)
.913
(23.20)
1.015
(25.80)
1.217
(30.90)
1.413
(35.90)
D
.404
(10.27)
.504
(12.81)
.504
(12.81)
.604
(15.34)
.704
(17.89)
.812
(20.62)
1.004
(25.51)
1.204
(30.59)
F
.264
(6.70)
.347
(8.81)
.364
(9.24)
.464
(11.78)
.564
(14.32)
.672
(17.06)
.864
(21.94)
1.047
(26.59)
G
.500
(12.70)
.600
(15.24)
.700
(17.78)
PLC-020-442T PLC-020-442T-P
PLC-028-442T PLC-028-442T-P
PLC-032-442T PLC-032-440T-P
(rectangular)
(rectangular)
Retention Clips are Not
Available With These Models
PLC-044-442T PLC-044-440T-P
PLC-052-442T PLC-052-440T-P
PLC-068-442T PLC-068-442T-P
PLC-084-442T PLC-084-442T-P
.800
(20.32)
.900
(22.86)
1.100
(27.94)
1.300
(33.02)
Page 152
Rev. 14-A
inch/(mm)
