MCC
Micro Commercial Components
TM
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
*) #%
6047
*) #'
1 Amp Fast Recovery
Rectifier
400~1000
Volts
DO-41
Features
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Low Leakage Current
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Fast Switching For High Efficiency
High emperature soldering guaranteed:260
o
C /10 seconds
Lead Free Finish/RoHS Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
•
•
Maximum Ratings
•
•
•
Operating Temperature: -65°C to +125°C
Storage Temperature: -65°C to +125°C
Maximum Thermal Resistance; 25°C/W Junction To Lead
MCC
Catalog
Number
Device
Marking
Maximum
Recurrent
Peak
Reverse
Voltage
400V
600V
1000V
Maximum
RMS
Voltage
280V
420V
700V
Maximum
DC
Blocking
Voltage
400V
600V
1000V
D
BA157
BA158
BA159
BA157
BA158
BA159
A
Cathode
Mark
B
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Maximum Reverse
Recovery Time
BA157~BA158
BA159
D
I
F(AV)
I
FSM
V
F
1.0A
35A
T
A
=50°C
8.3ms, half sine
C
1.3V
I
FM
= 1.0A;
T
A
= 25°C*
T
J
= 25°C
DIMENSIONS
INCHES
MIN
.166
.080
.028
1.000
MM
MIN
4.10
2.00
.70
25.40
I
R
5.0µA
T
rr
C
J
150nS
250nS
Typical Junction
Capacitance
15pF
I
F
=0.5A,
I
R
=1.0A,
I
rr
=0.25A
Measured at
1.0MHz,
V
R
=4.0V
DIM
A
B
C
D
MAX
.205
.107
.034
---
MAX
5.20
2.70
.90
---
NOTE
*Pulse test: Pulse width 300
µsec,
Duty cycle 2%
Note:
1.
High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision:
B
www.mccsemi.com
1 of 3
2013/01/01
MCC
TM
Micro Commercial Components
Ordering Information :
Device
Part Number-TP
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel: 5Kpcs/Reel
Ammo Packing: 5Kpcs/Ammo Box
Bulk: 50Kpcs/Carton
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
Revision:
B
www.mccsemi.com
3 of 3
2013/01/01
