PKB 4000 Series
36-75 Vdc DC/DC converter
Output up to 30 A/90 W
Contents
Product Program . . . . . . . . . . . . . . . . . . . . . . 2
Mechanical Information . . . . . . . . . . . . . . . . . 3
Absolute Maximum Ratings . . . . . . . . . . . . . 4
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Qualification Specification . . . . . . . . 5
Safety Specification . . . . . . . . . . . . . . . . . . . 6
PKB 4318 PIOBNB − 1 .2 V Data . . . . . . . . . 7
PKB 4418 PIOANB − 1 .5 V Data . . . . . . . . 10
PKB 4418 PINB - 1 .8 V Data . . . . . . . . . . . 13
PKB 4619 PINB − 2 .5 V Data . . . . . . . . . . . 16
PKB 4610 PINB − 3 .3 V Data . . . . . . . . . . . 19
PKB 4810 PINB − 3 .3 V Data . . . . . . . . . . . 22
PKB 4711 PINB − 5 V Data . . . . . . . . . . . . 25
PKB 4713 PINB − 12 V Data . . . . . . . . . . . 28
PKB 4913 PINB − 12 V Data . . . . . . . . . . . 31
PKB 4715 PINB - 15 V Data . . . . . . . . . . . . 34
EMC Specification . . . . . . . . . . . . . . . . . . . . 37
Operating Information . . . . . . . . . . . . . . . . . 38
Thermal Consideration . . . . . . . . . . . . . . . . 40
Soldering Information . . . . . . . . . . . . . . . . . 41
Delivery Package Information . . . . . . . . . . . 41
Compatibility with RoHS requirements . . . . 41
Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Quality Statement . . . . . . . . . . . . . . . . . . . . 41
Limitation of Liability . . . . . . . . . . . . . . . . . . 41
Sales Offices and Contact Information . . . . 42
Safety Approvals
Key Features
•
Industry standard Eighth-brick
58 .40 x 22 .70 x 8 .10 mm (2 .300 x 0 .896 x 0 .319 in .)
•
RoHS compliant
•
High efficiency, typ . 91 .5 % at 3 .3 Vout half load
•
2250 Vdc input to output isolation .
•
Meets isolation requirements equivalent to basic
insulation according
to IEC/EN/UL 60950
•
More than 3 .5 million hours predicted MTBF at +40 ºC
ambient temperature
The PKB series of high efficiency DC/DC converters are
designed to provide high quality on-board power solu-
tions in distributed power architectures used in Internet-
working equipment in wireless and wired communications
applications . The PKB 4000 series has industry standard
footprint and pin-out and is max 8 .10 mm (0 .319 in) high .
This makes it extremely well suited for narrow board pitch
applications with board spacing down to 15 mm (0 .6 in) .
Included as standard features are output over-voltage
protection, input under-voltage protection, over tempera-
ture protection, soft-start, output short circuit protection,
remote sense, remote control and output voltage adjust
function .
These converters are designed to meet high reliability
requirements and are manufactured in highly automated
manufacturing lines and meet world-class quality levels .
Ericsson Power Modules is an ISO 9001/14001 certified
supplier .
E
Datasheet
Absolute Maximum Ratings
Characteristics
T
pcb
T
S
V
I
V
ISO
V
tr
V
RC
V
adj
Maximum Operating Pcb Temperature (see Thermal Consideration section)
Storage temperature
Input voltage
Isolation voltage (input to output test voltage)
Input voltage transient (T
p
100 ms)
Negative logic (referenced to -In)
Positive logic (referenced to -In)
Maximum input
-0 .5
-0 .5
min
-40
-55
-0 .5
typ
max
+110
+125
+80
2250
100
40
6
2xV
oi
Unit
˚C
˚C
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Stress in excess of Absolute Maximum Ratings may cause permanent damage . Absolute
Maximum Ratings, sometimes referred to as no destruction limits, are normally tested with
one parameter at a time exceeding the limits of Output data or Electrical Characteristics .
If exposed to stress above these limits, function and performance may degrade in an
unspecified manner .
Input
V
I
V
Ioff
V
Ion
C
I
P
Ii
P
RC
T
Pcb
<T
Pcb max
unless otherwise specified
Characteristics
Input voltage range
Turn-off input voltage
Turn-on input voltage
Input capacitance
Input idling power
Input standby power
(turned off with RC)
Conditions
min
36
typ
max
75
Unit
Vdc
Vdc
Vdc
µF
W
W
Ramping from higher voltage
Ramping from lower voltage
30
32
33 .5
34 .5
2 .18
35
36
I
o
= 0, V
I
= 53 V
V
I
= 53 V, RC activated
3
0 .15
Fundamental Circuit Diagram
Chok
e
1
Ress or
it
Capaci
t
or
8
2
Contol
r
4
Contol
r
3
I ol ed
s at
Feedback
5
6
7
PKB 4000 Datasheet
4
EN/LZT 146 033 R9A © Ericsson Power Modules, March 2007
