Interconnect Solutions
ITT Corporation is a diversified leading manufacturer of highly
engineered critical components and customized technology
solutions for industrial end-markets in energy infrastructure,
electronics, aerospace and transportation. Building on its heritage
of innovation, ITT partners with its customers to deliver enduring
solutions to the key industries that underpin our modern way of
life. Founded in 1920, ITT is headquartered in White Plains, N.Y.,
with employees in more than 30 countries and sales from a total
of 125 countries which generated a 2011 revenue of $2.1 billion.
Our award-winning connector portfolio continues to be an indus-
try innovator, offering a reliable and cost effective range of inter-
connect solutions with the brands of Cannon, VEAM and BIW
Connector Systems. Continuous investment in technology and
research & development have enabled ITT to provide new, innova-
tive
products and solutions to markets including:
• Automotive
• Computer & Consumer Electronics
• Industrial/Instrumentation
• Military & Aerospace
• Oil & Gas
• Telecommunications/Wireless Handheld Devices
• Transportation
When you specify a Cannon, VEAM or BIW Connector Systems
connector, you can rely on products that are designed,
developed, and manufactured to the highest quality and
reliability standards. This tradition of excellence is based on ITT’s
corporate culture of operating its businesses under the principles
of Six Sigma. At ITT, Six Sigma is not just a quality philosophy but
a complete corporate culture that drives the entire business. Our
Value Based Management and Value Based Product Development
systems are two cornerstones that allow for the development of
both leadership and product engineering principles, ensuring our
industry leading products are developed to the accepted market
driven lead times. These principles have allowed ITT to become
the market leader in all of our business portfolios.
RoHS Compliance Information
ITT has implemented a strict parts control plan for all ITT
electronics plants worldwide that allows the Cannon, VEAM, and
BIW Connector Systems product portfolios to meet the
requirements of the European Union Directive 2002/95/EC better
know as the Reduction of Hazardous Substances initiative. As
appropriate, specific Cannon, VEAM, and BIW Connector Systems
products may be ordered with an R prefix number which insures
our customers will receive RoHS compliant parts for their
commercial electronics applications and equipment. Since most
RoHS hazardous substances center around specific metal plating
and lead solder coatings, ITT’s products for RoHS compliance are
available in the following plating finishes: electroless nickel,
Six Sigma Manufacturing
ITT operates manufacturing facilities in the United States,
Germany, Italy, Mexico, China, Japan and the UK, all of which
have particular product area strengths allowing ITT to offer a
truly global footprint to our customers. Our facilities are world
stainless steel, anodize over aluminum and gold plating. It should
be noted that gold plating would be recommended as the
replacement for tin-lead solder when ordering
board mount connectors.
The Custom Difference
As the industry leader in harsh environment interconnect
applications, ITT’s world class engineering teams will work
directly with our customers to design and develop cost effective
solutions for their applications. In many cases we may modify one
of our standard designs to ensure a highly reliable solution where
timing is critical. Yet, in those cases where a complete
custom interconnect solution is required, ITT will work with our
customer’s Engineers to design an interconnect solution which
will be cost effective yet highly reliable. Our Engineering teams
will provide a thorough systems and mechanical analysis of any
proposed solution. These analyses provide our customers with
sophisticated electrical signal and mechanical characterizations to
determine the best solution for their application.
class and accommodate full vertical integration utilizing the latest
manufacturing technologies including: manufacturing cells,
Kanban pull systems, and automated electrical, mechanical, and
optical test and inspection equipment. The combination of our
manufacturing strength and our advanced manufacturing
facilities allows ITT to offer products at market driven prices. Our
capabilities, especially in robotics, computerized precision tooling,
Kaizen Project Management, Six Sigma tools, and testing, give ITT
the most optimized global manufacturing footprint in the inter-
connect industry.
Specifications and dimensions subject to change
Dimensions shown in mm.
www.ittcannon.com
VEAM CIR Series Connectors
Introduction
General Specification
Part Number Generation
Electrical Data
Mechanical Data
Inserts by Contact Quantity
Inserts by Shell Sizes
Insert Rotation - Alternate Positions
Contact Selection Based on Wire Diameter
Contact Dimensions
Coaxial Contacts
PCB Terminations
Insert Arrangements Pictorials
Connector Selection
Class Overview
Reduction Sleeve and Hole Plugs
Connector Mounting Options
Additional CIR Options (CIR020R/00, CIR064PP, CIR05)
Accessories (caps, gaskets, clamps, bushings)
Tools
Additional Connector Series
Page 6
Page 7
Page 10
Page 12
Page 13
Page 26 - 31
Page 32 - 34
Page 35 - 36
Page 14 - 15
Page 16 - 21
Page 22 - 25
Page 70 - 73
Page 37 - 50
Page 74 - 75
Page 76 - 86
Page 193 - 194
Page 195 - 197
Page 198
Page 199 - 202
Page 204 - 209
Page 3 - 5 & 210, 211, 213
While the information in this publication is belived to be accurate and reliable, all data presented is subject to change without notice.
VEAM disclaims responsibility for any damages resulting from application or any incompleteness or inaccuracies presented.
Consult factory for specific information on the latest design specifications.
Specifications and dimensions subject to change
Dimensions shown in mm.
www.ittcannon.com
1
Interconnect Solutions for Transportation
Offering the broadest selection of transportation interconnect
solutions, ITT is the one stop source for design, development,
manufacturing, and testing.
ITT offers Cannon, VEAM, and BIW Connector Systems prod-
uct lines designed specifically for transit applications. These
product lines come in a large style of shell sizes and contact
arrangements to meet the most demanding applications,
both electrical and optical. Inserts to meet low smoke/zero
halogen and RoHS requirements are also available. ITT
provides complete harnessing solutions and junction boxes.
As the industry leader in harsh environment interconnect
applications, ITT’s world class engineering teams will work
directly with our customers to design and develop cost
effective solutions for their applications. In many cases we
may modify one of our standard designs to ensure a reliable
solution where timing is critical. Yet, in those cases where a
complete custom interconnect solution is required, ITT will
work with our customer’s Engineers to design an
interconnect solution which will be cost effective yet
highly reliable.
VEAM VBN
Circular connectors with rigid insert according
to NF F 61030 regulations. Field configurable,
allows easy and quick harnessing. Suitable
both for signal and power.
VEAM CIR High Temperature Connector
The new European standards series CEN/TS
45545 for fire rail safety regulations requires a
connector able to withstand for 15 minutes
when exposed to the ISO 834-1 heating curve
(max Temperature 800°C). The VEAM CIR High
Temp connector meets this standard.
Cannon CA Bayonet
VG/CA-Bayonet signal and power connectors
provide superior performance in extreme
environmental conditions. They offer
exceptional sealing against the ingress of
fluids and will withstand the effects of high
vibration. In accordance to VG95234.
Applications
•Critical control signals
•Fire resistant applications
Applications
•Control panel connections
•Intervehicle applications
•Communications equipment
•CCTV equipment
Specifications and dimensions subject to change
Dimensions shown in mm.
2
www.ittcannon.com
