CD4099 thru CD4135
Zener Diode Chip Series
Rev. V4
Features
•
0.5 W Capability with Proper Heat Sinking
•
Electrically Equivalent to 1N4099
-
1N4135
Die
Description
These 0.5 W zener diodes are electrically equivalent
to the 1N4099
-
1N4135 series diodes. They are
compatible with all wire bonding and die attach
techniques with the exception of solder reflow.
These diodes are available in JANHC and JANKC
per MIL-PRF-19500/435
Electrical Specifications: Zener Test Current = 250 µA, T
A
= +25°C
Zener Voltage
1
V
Z
@ 250 µA
Nominal
V
CD4099
CD4100
CD4101
CD4102
CD4103
CD4104
CD4105
CD4106
CD4107
CD4108
CD4109
CD4110
CD4111
CD4112
CD4113
CD4114
CD4115
CD4116
CD4117
CD4118
CD4119
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
28
Zener Impedance
2
Z
ZT
@ 500 µA
Maximum
Ω
200
200
200
200
200
200
200
200
200
200
100
100
100
100
150
150
150
150
150
150
200
µA
10
10
1
1
1
1
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.01
0.01
0.01
0.01
0.01
0.01
Reverse Voltage
I
R
@ V
R
Maximum
V
5.17
5.70
6.24
6.61
6.92
7.60
8.44
9.12
9.87
10.65
11.40
12.15
12.92
13.67
18.25
15.20
16.72
18.25
19.00
20.45
21.28
Part #
(Continued next page)
* Restrictions on Hazardous Substances, European Union Directive 2011/65/EU.
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
1
CD4099 thru CD4135
Zener Diode Chip Series
Rev. V4
Electrical Specifications: Zener Test Current = 250 µA, T
A
= +25°C
Zener Voltage
1
V
Z
@ 250 µA
Nominal
V
CD4120
CD4121
CD4122
CD4123
CD4124
CD4125
CD4126
CD4127
CD4128
CD4129
CD4130
CD4131
CD4132
CD4133
CD4134
CD4135
30
33
36
39
43
47
51
56
60
20
68
75
82
87
91
100
Zener Impedance
2
Z
ZT
@ 500 µA
Maximum
Ω
200
200
200
200
250
250
300
300
400
500
700
700
800
1000
1200
1500
µA
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
Reverse Voltage
I
R
@ V
R
Maximum
V
22.80
25.08
27.38
29.65
32.56
35.75
38.76
42.60
45.60
47.10
51.68
57.00
62.32
66.12
69.16
76.00
Part #
1. Zener voltage range equals nominal voltage ±5% for “A” suffix. No suffix denotes ±10%, “C” suffix = ±2% and “D” suffix = ±1%.
2. Zener impedance is derived by superimposing on I
ZT
at 60 HZ RMS AC current equal to 10% of I
ZT
.
2
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
CD4099 thru CD4135
Zener Diode Chip Series
Rev. V4
Absolute Maximum Ratings
3.4
Forward Voltage
Operating Temperature
Storage Temperature
1.5 V @ 200 mA
-65°C
to +175°C
-65°C
to +175°C
Zener Impedance vs. Operating Current
3. Exceeding any one or combination of these limits may cause
permanent damage to this device.
4.
VPT Components does not recommend sustained operation
near these survivability limits.
Die
Top: (anode) AL
Back: (cathode) Au
AL Thickness:
25,000 Å Minimum
Gold Thickness:
4,000 Å Minimum
Chip Thickness:
10 mils
Circuit Layout Data: For Zener operation, cathode must be
operated positive with respect to anode.
Metallization:
3
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
CD4099 thru CD4135
Zener Diode Chip Series
Rev. V4
VPT COMPONENTS. ALL RIGHTS RESERVED.
Information in this document is provided in connection with VPT Components products. These materials are provided by
VPT Components as a service to its customers and may be used for informational purposes only. Except as provided in VPT
Components Terms and Conditions of Sale for such products or in any separate agreement related to this document, VPT
Components assumes no liability whatsoever. VPT Components assumes no responsibility for errors or omissions in these
materials. VPT Components may make changes to specifications and product descriptions at any time, without notice. VPT
Components makes no commitment to update the information and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to its specifications and product descriptions. No license, express or implied,
by estoppels or otherwise, to any intellectual property rights is granted by this document.
THESE MATERIALS ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, RELATING TO
SALE AND/OR USE OF VPT COMPONENTS PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A
PARTICULAR PURPOSE, CONSEQUENTIAL OR INCIDENTAL DAMAGES, MERCHANTABILITY, OR INFRINGEMENT OF ANY PA-
TENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. VPT COMPONENTS FURTHER DOES NOT WARRANT THE
ACCURACY OR COMPLETENESS OF THE INFORMATION, TEXT, GRAPHICS OR OTHER ITEMS CON-TAINED WITHIN THESE
MATERIALS. VPT COMPONENTS SHALL NOT BE LIABLE FOR ANY SPECIAL, IN-DIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, INCLUDING WITHOUT LIMITATION, LOST REVE-NUES OR LOST PROFITS, WHICH MAY RESULT FROM THE USE
OF THESE MATERIALS.
VPT Components products are not intended for use in medical, lifesaving or life sustaining applications. VPT Components
customers using or selling VPT Components products for use in such applications do so at their own risk and agree to fully
indemnify VPT Components for any damages resulting from such improper use or sale.
4
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
